Page 153 - Fullerton Tool Catalog

Cutting Diameter Flute Shank Overall EDP Number
Length Diameter Length UC
.0292 69 5/16 .0292 1 1/4 15013
.0310 68 5/16 .0310 1 1/4 15014
.0312 1/32 5/16 .0312 1 1/4 15015
.0320 67 5/16 .0320 1 1/4 15016
.0330 66 5/16 .0330 1 1/4 15017
.0350 65 5/8 .0350 1 1/2 15018
.0360 64 5/8 .0360 1 1/2 15019
.0370 63 5/8 .0370 1 1/2 15020
.0380 62 5/8 .0380 1 1/2 15021
.0390 61 5/8 .0390 1 1/2 15022
.0400 60 3/4 .0400 1 1/2 15024
.0410 59 3/4 .0410 1 1/2 15025
.0420 58 3/4 .0420 1 1/2 15026
.0430 57 3/4 .0430 1 1/2 15027
.0465 56 3/4 .0465 1 1/2 15028
.0469 3/64 3/4 .0469 1 1/2 15029
.0520 55 3/4 .0520 1 1/2 15030
.0550 54 3/4 .0550 1 1/2 15031
.0595 53 3/4 .0595 1 1/2 15033
.0625 1/16 3/4 .0625 1 1/2 15034
.0635 52 3/4 .0635 1 1/2 15035
.0670 51 3/4 .0670 1 1/2 15036
.0700 50 7/8 .0700 1 3/4 15037
.0730 49 7/8 .0730 1 3/4 15038
.0760 48 7/8 .0760 1 3/4 15039
.0781 5/64 7/8 .0781 1 3/4 15040
.0785 47 7/8 .0785 1 3/4 15041
.0810 46 7/8 .0810 1 3/4 15043
.0820 45 7/8 .0820 1 3/4 15044
.0860 44 1 .0860 2 15045
.0890 43 1 .0890 2 15046
.0935 42 1 .0935 2 15047
.0938 3/32 1 .0938 2 15048
.0960 41 1 .0960 2 15049
.0980 40 1 .0980 2 15050
.0995 39 1 1/4 .0995 2 1/4 15052
.1015 38 1 1/4 .1015 2 1/4 15053
.1040 37 1 1/4 .1040 2 1/4 15054
.1065 36 1 1/4 .1065 2 1/4 15055
.1094 7/64 1 1/4 .1094 2 1/4 15056
.1100 35 1 1/4 .1100 2 1/4 15057
.1110 34 1 1/4 .1110 2 1/4 15058
.1130 33 1 1/4 .1130 2 1/4 15059
.1160 32 1 1/4 .1160 2 1/4 15060
.1200 31 1 1/4 .1200 2 1/4 15062
.1250 1/8 1 1/4 .1250 2 1/4 15063
.1285 30 1 3/8 .1285 2 1/2 15064
.1360 29 1 3/8 .1360 2 1/2 15065
.1405 28 1 3/8 .1405 2 1/2 15067
.1406 9/64 1 3/8 .1406 2 1/2 15068
.1440 27 1 3/8 .1440 2 1/2 15069
.1470 26 1 3/8 .1470 2 1/2 15070
.1495 25 1 3/8 .1495 2 1/2 15071

151
