Page 191 - Fullerton Tool Catalog

Burr SC/SD

1/4” Shank Diameter
SC Cylindrical Ball Nose

Approx. Tool EDP Number
Cutting
Cutting Diameter Overall
Length Number
Length #1 Cut #3 Cut #5 Cut
1/8 5/8 2 SC-12 42132 42134
3/16 5/8 2 SC-14 42139 42141
5/8 2 SC-1 42125 42127 42129
1/4
1 2 SC-1A 42146 42148
3/4 2 1/2 SC-2 42160 42162
5/16
1 2 3/4 SC-2A 42189 42191
3/4 2 1/2 SC-3 42197 42199 42201
3/8 1 2 3/4 SC-3A 42204 42206
1 1/2 3 1/4 SC-3B 42211 42213
7/16 1 2 3/4 SC-4 42225 42227
1/2 1 2 3/4 SC-5 42232 42234 42236
5/8 1 2 3/4 SC-6 42171 42173 42175
3/4 1 2 3/4 SC-7 42178 42180 42182
Extended Shank
1/4 1/2 6 1/2 SC-1X6 42153 42155
3/8 3/4 6 3/4 SC-3X6 42218 42220
1/2 1 7 SC-5X6 42164 42166

SD Ball Shape

Approx. EDP Number
Tool
Cutting Diameter Cutting Overall Number
Length
Length #1 Cut #3 Cut #5 Cut
1/8 1/8 2 SD-12 43132 43134
3/16 3/16 2 SD-14 43139 43141
1/4 1/4 2 SD-1 43125 43127 43129
5/16 5/16 2 1/4 SD-2 43153 43155
3/8 3/8 2 1/8 SD-3 43160 43162 43164
7/16 7/16 2 1/8 SD-4 43174 43176
1/2 1/2 2 1/4 SD-5 43181 43183 43185
5/8 5/8 2 1/4 SD-6 43195 43197 43199
3/4 3/4 2 1/2 SD-7 43202 43204
1 1 2 3/4 SD-9 43100 43102
Extended Shank
1/4 1/4 6 1/4 SD-1X6 43146 43148
3/8 3/8 6 3/8 SD-3x6 43167 43169
1/2 1/2 6 1/2 SD-5X6 43188 43190

All above Burrs available with #4 Diamond Cut. Add 20% to list price of #1 Cut.
All Burrs 5/16” diameter and larger furnished with 1/4” x 1 3/4” steel shanks.

Metric Sized Shanks
All burrs on page 188-194 with a head diameter of 5/16” or larger, with the exception of extended shanks, are
available with a 6mm diameter shank. They will retain standard fractional cutting diameters and cutting length.
Add $2.50 to the list price.

Visit fullertontool.com for the most up to date information. 189
