Page 186 - Fullerton Tool Catalog

KEYSEAT CUTTERS

4375

Straight Flutes
1/2” Diameter Steel Shank
1 1/8” - 1 1/2” Cutter Diameter are Solid Carbide
Dura Carb III
Speeds and Feeds, see fullertontool.com

Tolerance:
1/2” Diameter Shank: +.0000” -.0005”
+0.0mm -0.013mm
Cutting Head Diameter:
3/8” - 3/4” DIA +.010” -.015”
7/8” - 1 1/2” DIA +.012” -.017”
Face Width: +.0000” -.0005”
Neck Length: 1/4”

American Solid EDP Number
Face
Neck
Overall Number
Shank
Cutting Diameter Standards Width Diameter Diameter Length of Flutes Carbide
Number Shank UC
1/32 .2030 1/2 2 1/32 8 43900
3/64 .2030 1/2 2 3/64 8 43901
3/8 203 1/16 .2030 1/2 2 1/16 8 43302
303 3/32 .2030 1/2 2 3/32 8 43303
403 1/8 .2030 1/2 2 1/8 8 43403
1/32 .2500 1/2 2 1/32 10 43902
3/64 .2500 1/2 2 3/64 10 43903
204 1/16 .2500 1/2 2 1/16 10 43240
1/2 5/64 .2500 1/2 2 5/64 10 43904
UNCOATED 304 3/32 .2500 1/2 2 3/32 10 43304
I 404 7/64 0.2500 1/2 2 7/64 10 43905
2 1/8
1/2
43404
10
1/8
.2500
IMPERIAL 1/32 .2810 1/2 2 1/32 10 43906
3/64 .2810 1/2 2 3/64 10 43907
1/16 .2810 1/2 2 1/16 10 43908
5/64 .2810 1/2 2 5/64 10 43909
305 3/32 .2810 1/2 2 3/32 10 43305
5/8
7/64 .2810 1/2 2 7/64 10 43910
405 1/8 .2810 1/2 2 1/8 10 43405
9/64 .2810 1/2 2 9/64 10 43911
505 5/32 .2810 1/2 2 5/32 10 43505
605 3/16 .2810 1/2 2 3/16 10 43605
1/32 .2810 1/2 2 1/32 10 43912
3/64 .2810 1/2 2 3/64 10 43913
1/16 .2810 1/2 2 1/16 10 43914
5/64 .2810 1/2 2 5/64 10 43915
3/32 .2810 1/2 2 3/32 10 43916
3/4
7/64 .2810 1/2 2 7/64 10 43917
406 1/8 .2810 1/2 2 1/8 10 43406
9/64 .2810 1/2 2 9/64 10 43918
506 5/32 .2810 1/2 2 5/32 10 43506
606 3/16 .2810 1/2 2 3/16 10 43606

184 Visit fullertontool.com for the most up to date information.
