Page 905 - Tungaloy Catalog

d TPMPuuZDS, TPMMuuZERD
Stocked grades
Accuracy Honing T313W drill diameters drills (Page)
Shape Cat. No. coated Applicable Applicable TAC

TPMP83ZDS d ø18.0 ~ ø19.5
TPMP04ZERD d ø20.0 ~ ø28.5
M With TDRU
TPMM32ZERD d ø29.0 ~ ø34.5 (1st Generation)
TPMM43ZERD d ø35.0 ~ ø54.0

d WCMTuuuu08-Du
Stocked grades
coated
Accuracy Honing AH120 AH140 T313W drills (Page)
Shape Cat. No. Applicable TAC

WCMT050308-DC d
WCMT050308-D4 d d d
WCMT06T308-DC M With d TDWU
WCMT06T308-D4 d d d (1st Generation)
WCMT080412-DC d
WCMT080412-D4 d

d XPMTuuuuuuR-DJ

Stocked grades
coated
Accuracy Honing AH725 AH740 T1115 drill diameters drills (Page)
Shape Cat. No. Applicable Applicable TAC 11

(in)

XPMT040104R-DJ d d d ø.500 ~ ø.562 Drilling Tools
XPMT050204R-DJ d d d ø.625
XPMT06X308R-DJ d d d ø.687 ~ ø.812 TDXU
XPMT07H308R-DJ M With d d d ø.875 ~ ø1.00
XPMT08T308R-DJ d d d ø1.062 ~ ø1.250
XPMT110412R-DJ d d d ø1.312 ~ ø1.562

XPMT150512R-DJ d d d ø1.625 ~ ø2.00

d : Stocked items.

Most unmarked items are available on a RFQ basis, contact your sales rep for more information.
Most unmarked items are available on a RFQ basis, contact your sales rep for more information.
11–89
