Features
- Quick-change - push back on the holder sleeve and the adapter with tool is removable
- Press on the end of the adapter nose and the tool is removable - all in a few seconds
- Smooth stroke - even under full torque load, the tension-compression stroke is full and free
- Interchangeability - this adapters and holders are interchangeable with Universal-Bilz quick change holders and adapters
Product Specifications
| Manufacturer Part Number | 532268 |
| Shank Type | Taper Shank |
| Taper Size | BT40 |
| Projection (Decimal Inch) | 4.5" |
| Tapping Style | Tension/Compression |
| Nose Diameter (Decimal Inch) | 2.09" |
| ANSI Tap (Inch) | 13/16-1-3/8" |
| System | #2 |
| Tension/Compression (Inch) | 0.49/0.49" |
| NPT (Inch) | 1/4-1/2" |
| Product Type | Tapping Chuck |
