Product Specifications
| Mill Diameter (Decimal Inch) | 0.2500" |
| Mill Diameter (Inch) | 1/4" |
| Neck Diameter (Decimal Inch) | 0.1250" |
| Neck Diameter (Inch) | 1/8" |
| Cutter Width (Decimal Inch) | 0.0470" |
| Cutter Width (Inch) | 3/64" |
| Neck Length (Decimal Inch) | 0.7500" |
| Neck Length (Inch) | 3/4" |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (Inch) | 2-1/2" |
| Radial Depth Of Cut (Decimal Inch) | 0.0530" |
| Corner Radius (Decimal Inch) | 0.0050" |
| Number of Flutes | 6 |
| Reach Multiple | (3x) |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Shank Diameter (Inch) | 1/4" |
| Coating | AlTiN |
| Top Corner Radius | 0.005 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Milling Diameter (Inch):
1/4"
Milling Diameter (Decimal Inch):
0.2500"
Cutting Width (Inch):
3/64"
Cutting Width (Decimal Inch):
0.0470"
Corner Radius:
0.0050"
Neck Length (Inch):
3/4"
Neck Length (Decimal Inch):
0.7500"
Material:
Solid Carbide
Finish/Coating:
AlTiN
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Tooth Configuration:
Staggered Tooth
Ships:
From Partner Facility
