END MILLS • Metric Assorted # Of Flutes
90
6 Flute 45° Helix Metric Superceed Solid Carbide Corner Radius
®
X-RoC Coated Single End Mills
®
Deep Slotting With Reduced Neck Size
Machine material up to 70 Rc
with excellent workpiece finishes
APPLICATIONS: FeATureS:
• Designed to machine high • Deep slotting is possible by CoRnER SHank FluTE nECk ovERall nECk oRDER PRiCE
hardened materials. reduced neck. SizE RaDiuS DiaMETER lEngTH lEngTH lEngTH DiaMETER # EaCH
• Suitable for dry cutting, high speed • Corner radius against chipping in 6mm .500mm 6mm 6mm 14mm 50mm 5.7mm 20-102-340 $52.72
cutting due to newly developed raw high speed machining. 8mm .500mm 8mm 8mm 24mm 60mm 7.65mm 20-102-342 62.88
material and new coating. • Higher wear resistance. 10mm 1.000mm 10mm 10mm 30mm 70mm 9.65mm 20-102-344 91.42
• For mold & die. 12mm 1.000mm 12mm 12mm 30mm 75mm 11.6mm 20-102-346 109.21
6mm .500mm 6mm 13mm — 70mm — 20-102-348 55.70
4 Flute X-Roc Coated Single End Mills 8mm .500mm 8mm 19mm — 90mm — 20-102-350 69.88
See Page 88 10mm .500mm 10mm 22mm — 100mm — 20-102-352 105.45
12mm .500mm 12mm 26mm — 110mm — 20-102-354 143.84
collet chucks & collets
PAGES 804-816
TolERanCES:
Cutting Diameter: 0 / -0.020mm
Shank Diameter: h6
Metric Solid Carbide 4 Flute naCRo Coated Roughing &
Finishing Single End Mills
Center Cutting • Corner Radius • 40° Helix
BeNeFITS: APPLICATIONS:
Roughs and finishes at the same time • Relieves tool pressure during machining. • Roughing and finishing applications in
while leaving a surprisingly great finish • Corner radius is standard for corner Inconel, titanium and stainless steel.
protection.
• Proven over time to be the ideal tool FeATureS:
for machining Inconel, titanium and • Standard with incredibly heat and
®
stainless steel. scratch resistant nACRo coating
• Standard with corner radius for
corner protection.
[SERIES 420]
TolERanCES: SHank FluTE ovERall CoRnER oRDER PRiCE
Shank Diameter: -.0001" / -.0004" SizE DiaMETER lEngTH lEngTH RaDiuS # EaCH
Cutting Diameter: 6mm 6mm 19mm 63mm .508mm 20-452-400 $44.72
3mm thru 6mm: +.000" / -.002" 8mm 8mm 20mm 63mm .508mm 20-452-401 51.54
7mm thru 25mm: +.000" / -.002" Sizes 10mm Thru 125mm 10mm 10mm 25mm 70mm .508mm 20-452-402 58.29
Radius: Coolant Slots & Set Screw 12mm 12mm 32mm 76mm .508mm 20-452-403 75.13
3mm thru 25mm: +.002" /- .001" Flats Available, Please Call 16mm 16mm 38mm 89mm .762mm 20-452-404 121.54
Metric Single Flute Carbide Routers For aluminum
Right Hand Spiral • Right Hand Cut
SHank ovERall FluTE MoDEl oRDER PRiCE
SizE
DiaMETER lEngTH lEngTH # # EaCH
2mm 6mm 57mm 6mm SFAM-020020 21-101-250 $30.51
3 6 57 12 SFAM-030020 21-101-251 30.51
4 6 57 16 SFAM-040020 21-101-252 30.51
5 6 57 20 SFAM-050025 21-101-253 30.51
BeNeFITS: APPLICATIONS: 6 6 57 25 SFAM-060030 21-101-254 30.51
• Optimized rake and clearance angles • High speed, solid carbide routers 6 6 100 20 SFAM-060100 21-101-255 45.71
produce highest material removal rates for aluminum and non-ferrous 8 8 75 30 SFAM-080040 21-101-256 46.81
and improved surface finishes. cutting applications. 8 8 100 20 SFAM-080100 21-101-257 58.40
• Innovative single flute end mill 10 10 90 35 SFAM-100050 21-101-258 62.22
geometry avoids chip melting and chip FeATureS: 10 10 120 25 SFAM-100100 21-101-259 71.15
rewelding problems. • Unique open flute design with polished, 12 12 90 40 SFAM-120050 21-101-260 77.16
mirror-like flute finish. 12 12 120 25 SFAM-120100 21-101-261 91.37
