END MILLS • Metric Assorted # Of Flutes
86

2 & 4 Flute Metric Solid Carbide double End Mills
Right Hand • Center Cutting • 30° Helix

BeneFits: aPPLiCatiOns:
• Double end provides twice the cutting ends 4 Flute 2 Flute
and offers convenience to always have a • Cost effective & most commonly • Cast irons and
spare tool on hand. used in profiling applications on non-ferrous metals.
2 flute
2 Flute harder materials than 2 flute 4 Flute
• General purpose designed with maximum end mills. • Steel, stainless steel, cast irons,
clearance, giving you a cost effective high • Provide good wear resistance & non-ferrous materials & high
quality tool. are used for excellent size control. temp alloys.
• Large flute area enables excellent chip
4 flute
evacuation; can be used for plunging & slotting.
2 FluTE 4 FluTE
Shank FluTE ovErall ordEr PriCE ordEr PriCE
SizE diaMETEr lEngTh lEngTh # EaCh # EaCh
Other Sizes & Coatings 3mm 3mm 9mm 50mm 20-501-750 $17.75 20-501-760 $17.75
Available, Please Call 4mm 4mm 10mm 63mm 20-501-751 25.78 20-501-761 25.78
5mm 5mm 12mm 63mm 20-501-752 21.62 20-501-762 21.62
6mm 6mm 16mm 63mm 20-501-753 27.73 20-501-763 27.73
TolEranCES: 8mm 8mm 18mm 75mm 20-501-754 34.11 20-501-764 34.11
Cutting Edge: +0.000 / -0.0508mm 10mm 10mm 18mm 75mm 20-501-755 43.24 20-501-765 43.24
Shank: H6 12mm 12mm 25mm 100mm 20-501-756 70.29 20-501-766 70.29
2 Flute Metric Micrograin Solid Carbide Single End Mills
Right Hand Cutting • Right Hand Spiral • Square End • Straight Shank • Center Cutting • 30° Helix

Features: [121]
M.A. Ford Shank FluTE ovErall ordEr PriCE FluTE ovErall ordEr PriCE
• High cobalt content of carbide permits SizE diaMETEr lEngTh lEngTh # EaCh lEngTh lEngTh # EaCh
increased feed rates. 2mm 3mm 6.3mm 38mm 20-504-220 $8.95 9mm 38mm 20-412-141 $17.02
• Micrograin 10% cobalt grade. 2.5 3 9.5 38 20-504-225 8.64 12 38 20-412-148 17.02
3 3 12 38 20-504-230 8.69 12 38 20-412-152 15.92
3.5 4 12 50 20-504-235 10.93 12 51 20-412-156 22.65
TolEranCES: 4 4 14 50 20-504-240 11.73 14 51 20-412-158 22.17
M.a. Ford 4.5 5 15 50 20-504-245 14.41 — — — —
Cutting Diameter (h10) 5 5 15 63 20-504-250 19.67 20 51 20-412-161 23.50
2mm thru 3mm: +.000mm / -.040mm 6 6 19 63 20-504-260 15.95 20 64 20-412-164 27.05
3.5mm thru 6mm: +.000mm / -.048mm 7 8 19 63 20-504-270 22.44 — — — —
7mm thru 10mm: +.000mm / -.058mm 8 8 20 63 20-504-280 22.44 20 64 20-412-169 31.57
11mm thru 18mm: +.000mm / -.070mm 9 10 22 63 20-504-290 30.89 — — — —
20mm: +.000mm / -.084mm 10 10 22 63 20-504-300 33.98 25 70 20-412-172 55.21
Shank Diameter (h6) 11 12 25 76 20-504-310 48.70 25 70 20-412-173* 58.79
2mm thru 3mm: +.000mm / -.006mm 12 12 25 76 20-504-315 46.34 25 76 20-412-175 67.68
3.5mm thru 6mm: +.000mm / -.008mm 14 14 31 88 20-504-320 77.24 30 89 20-412-177* 94.69
7mm thru 10mm: +.000mm / -.009mm 16 16 — — — — 30 89 20-412-180 121.79
11mm thru 18mm: +.000mm / -.011mm 18 18 38 100 20-504-330 115.35 — — — —
20mm: +.000mm / -.013mm
*Limited Supply.
2 & 4 Flute Metric Solid Carbide Square End Extended reach End Mills
Center Cutting • For Die & Mold Industry • 30° Helix

2 flute
BeneFits:
• Neck diameter reduced .020" for long 2 FluTE 4 FluTE
reach applications. Shank FluTE ovErall nECk ModEl ordEr PriCE ModEl ordEr PriCE
SizE diaMETEr lEngTh lEngTh diaMETEr rEaCh
aPPLiCatiOns: d1 d2 l2 l1 d3 l3 # # EaCh # # EaCh
• Use 2 fluted tools in softer materials 2mm 6mm 5mm 57mm 1.5mm 15mm GLRM-020-2 21-101-540 $26.75 GLRM-020-4 21-101-550 $26.75
and 4 fluted in harder materials. 3 6 8 75 2.5 30 GLRM-030-2 21-101-541 34.63 GLRM-030-4 21-101-551 34.63
4 6 8 75 3.5 30 GLRM-040-2 21-101-542 34.63 GLRM-040-4 21-101-552 34.63
Features: 5 6 10 100 4.5 50 GLRM-050-2 21-101-543 36.31 GLRM-050-4 21-101-553 36.31
• Tool geometry supports soft to 6 6 12 100 5.5 50 GLRM-060-2 21-101-544 36.31 GLRM-060-4 21-101-554 36.31
hard materials. 8 8 14 100 7.5 50 GLRM-080-2 21-101-545 49.47 GLRM-080-4 21-101-555 49.47
• Slightly increased flute and overall 10 10 18 120 9.5 65 GLRM-100-2 21-101-546 55.58 GLRM-100-4 21-101-556 55.58
length offers the greatest versatility. 12 12 22 130 11.5 80 GLRM-120-2 21-101-547 77.94 GLRM-120-4 21-101-557 77.94
