END MILLS • 5 Flute
82

5 Flute 45° Helix SuperCEED Solid Carbide
®
Coated Stub & Regular Length Single End Mills
TiN Or TiCN Coated • Center Cutting • Right Hand

Tin CoaTED TiCn CoaTED
Benefits: SHank FLuTE ovERaLL oRDER PRICE oRDER PRICE
TiN CoaTed STub leNgTh • 5 flute & 45° helix allow SIzE DIaMETER LEngTH LEngTH # EaCH # EaCH
harmonic balance and 1/8" 1/8" 1/4" 1-1/2" 20-102-150 $18.82 20-104-300 $18.82
smooth cutting. 1/8" 1/8" 1/2" 1-1/2" 20-102-152 20.23 20-104-302 20.23
3/16" 3/16" 5/16" 2" 20-102-154 22.69 20-104-304 22.69
APPLiCAtiOns: 3/16" 3/16" 9/16" 2" 20-102-156 24.50 20-104-306 24.50
TiN CoaTed RegulaR leNgTh
• Designed to machine 1/4" 1/4" 3/8" 2" 20-102-158 24.22 20-104-308 24.22
stainless steels, inconels 1/4" 1/4" 3/4" 2-1/2" 20-102-160 25.53 20-104-310 25.53
and other alloys. 5/16" 5/16" 7/16" 2" 20-102-162 31.21 20-104-312 31.21
5/16" 5/16" 13/16" 2-1/2" 20-102-164 36.31 20-104-314 33.01
TiCN CoaTed STub leNgTh feAtures: 3/8" 3/8" 1/2" 2" 20-102-166 38.31 20-104-316 38.31
• The design of stub length 3/8" 3/8" 1" 2-1/2" 20-102-168 40.46 20-104-318 40.46
allows cutting at maximum 7/16" 7/16" 9/16" 2-1/2" 20-102-170 51.51 — —
speeds & feeds with 7/16" 7/16" 1" 2-3/4" — — 20-104-322 51.09
TiCN CoaTed RegulaR leNgTh minimum deflection. 1/2" 1/2" 5/8" 2-1/2" 20-102-174 56.76 20-104-324 56.76
62.81
ToLERanCES: • 3/16" & smaller are 1/2" 1/2" 1-1/4" 3" 20-102-176 141.91 20-104-326 62.81
—
3/4"
3"
5/8"
20-102-178
5/8"
—
Cutting Diameter: +.000" / - .0012" non-center cutting. 5/8" 5/8" 1-5/8" 3-1/2" 20-102-180 157.61 20-104-330 150.11
ELITE Series 5 Flute 45° Helix Tialn/alTin Coated Solid Carbide
High Performance Single End Mills
For Titanium, Stainless Steel & High Temperature Alloys • Center Cutting • Square End
[SERIES S545]
SHank FLuTE ovERaLL oRDER PRICE
SIzE
DIaMETER LEngTH LEngTH # EaCH
1/8" 1/8" 1/4" 1-1/2" 16-061-983 $26.00
1/8" 1/8" 1/2" 1-1/2" 16-061-984 28.60
APPLiCAtiOns: Other Sizes, Corner Radius & 5/32" 3/16" 5/16" 2" 16-061-985 31.80
• Designed for steel, stainless Coatings Available, Please Call 3/16" 3/16" 5/16" 2" 16-061-987 28.50
steel and exotic alloys. 3/16" 3/16" 9/16" 2" 16-061-988 31.80
• Excellent in peripheral and finish milling. 1/4" 1/4" 3/8" 2" 16-061-991 30.70
16-061-992
2-1/2"
1/4"
34.30
3/4"
1/4"
feAtures: 5/16" 5/16" 13/16" 2-1/2" 16-061-997 43.00
• Niagara Microshield TiAlN coating. 3/8" 3/8" 1/2" 2" 16-062-002 47.80
• Ultra high transverse rupture strength. 3/8" 3/8" 1" 2-1/2" 16-062-003 53.40
• Eccentric primary relief. 3/8" 3/8" 1-1/2" 4" 16-062-004 82.00
16-062-009
7/16"
66.60
7/16"
1"
2-3/4"
• TiAlN coating will evolve to AlTiN as 1/2" 1/2" 5/8" 2-1/2" 16-062-013 73.70
stock rotates. 1/2" 1/2" 1-1/4" 3" 16-062-014 82.00
1/2" 1/2" 2" 4" 16-062-015 117.00
ToLERanCES: 5/8" 5/8" 3/4" 3" 16-062-017 151.00
Cutting Diameter: +.000" / -.002" 5/8" 5/8" 1-5/8" 3-1/2" 16-062-018 170.00
Shank Diameter: -.0001" / -.0004" 3/4" 3/4" 1" 3" 16-062-021 195.00
Flute Length 3/4" 3/4" 1-5/8" 4" 16-062-022 218.00
1/16" thru 5/16": +.030" / -.000" 3/4" 3/4" 2-1/4" 5" 16-062-023 289.00
21/64" thru 1": +.060" / -.000" 1" 1" 2" 4" 16-062-027 345.00
Overall Length: ±.060" 1" 1" 3-1/4" 6" 16-062-029 473.00
5 Flute 45° Helix alTin Coated Solid Carbide End Mills
Center Cutting • Right Hand • Square End
For high performance
machining
APPLiCAtiOns: feAtures: ToLERanCES:
• For peripheral & finish • High helix. Cutting Diameter: +.0000" / -.002"
milling of titanium, • Black coating color. Shank Diameter: +.0000" / -.0001" to -.0005"
stainless steel & high
temperature alloys. SIzE SHank FLuTE ovERaLL oRDER PRICE
AlTiN Coating DIaMETER LEngTH LEngTH # EaCH
• Provides high heat 1/4" 1/4" 3/4" 2-1/2" 20-104-406 $27.44
resistance. 5/16" 5/16" 3/4" 2-1/2" 20-104-409 34.36
• For dry high speed 3/8" 3/8" 1" 2-1/2" 20-104-412 42.68
machining as well as 3/8" 3/8" 1-3/4" 4" 20-104-415 65.59
hard machining. 1/2" 1/2" 1-1/4" 3" 20-104-418 65.59
93.94
Benefits: • Thermal threshold of 1/2" 1/2" 2" 4" 20-104-421 120.46
3-1/2"
5/8"
1-5/8"
5/8"
20-104-424
• Rapid evacuation of chips. 900°C or 1,652°F. 3/4" 3/4" 1-5/8" 4" 20-104-427 174.69
