END MILLS • 4 Flute
80

4 Flute TiAlN/AlTiN Coated Solid Carbide Stabilizer End Mills
For Stainless Steel, Exotic Materials & Titanium Materials
Stabilizer-HT • Center Cutting • Corner Radius

Cut faster and deeper
with higher chip removal Benefits: aPPLiCatiOns:
• Chatter reduction. • Designed for stainless steels, high
• Increased productivity. temperature alloys, nickel base alloys,
• Greater depths of cut. titanium & titanium alloys.
• Faster speeds. • Ideal for applications such as profiling,
• Heavier feeds. roughing and slotting.
• Better surface finish.
features:
• Extra fine solid carbide with TiAlN coating.
• Eccentric primary relief.
• Weldon flat on shank sizes 3/8" and larger.
• Patent #6,991,409.
Aerospace Radius Also Available, • Right hand cutting direction.
Please Call
• TiAlN coating will evolve to AlTiN as
stock rotates.
INCh SIZES [STR440]
ShANk FLuTE ovErALL CorNEr ordEr prICE
SIZE
dIAMETEr LENGTh LENGTh rAdIuS # EACh
1/8" 1/8" 1/8" 1-1/2" .010" 16-057-453 $19.40
1/8 1/8 3/8 1-1/2 .010 16-057-454 21.60
3/16 3/16 3/16 2 .010 16-057-457 26.00
3/16 3/16 7/16 2 .010 16-057-458 30.10
1/4 1/4 1/4 2 .020 16-057-461 34.40
1/4 1/4 1/2 2-1/2 .020 16-057-462 38.30
5/16 5/16 5/16 2 .020 16-057-464 43.10
5/16 5/16 13/16 2-1/2 .020 16-057-465 48.00
3/8 3/8 3/8 2 .020 16-057-467 53.30
3/8 3/8 7/8 2-1/2 .020 16-057-468 59.50
7/16 7/16 1 2-3/4 .020 16-057-471 74.50
1/2 1/2 1/2 2-1/2 .030 16-057-473 82.40
INCh SIZES WITh rEduCEd NECkS [STRN440] 1/2 1/2 1 3 .030 16-057-474 91.40
ShANk FLuTE NECk ovErALL CorNEr ordEr prICE 5/8 5/8 5/8 3 .030 16-057-477 173.00
SIZE rEACh
dIAMETEr LENGTh dIAMETEr LENGTh rAdIuS # EACh 5/8 5/8 1-1/4 3-1/2 .030 16-057-478 192.00
1/4" 1/4" 3/8" 2-1/8" 0.240" 4" .020" 16-057-525 $69.90 3/4 3/4 3/4 3 .030 16-057-480 224.00
3/8 3/8 1/2 2-1/8 0.360 4 .020 16-057-527 101.00 3/4 3/4 1-1/2 4 .030 16-057-481 250.00
1/2 1/2 5/8 2-1/8 0.480 4 .030 16-057-531 144.00 1 1 1 4 .030 16-057-485 357.00
4 Flute TiAlN/AlTiN Coated Solid Carbide Single End Mills
With STABILIZING Flute Geometry
Square Corner • Center Cutting • Corner Radius

Prevent vibration and unstable
harmonics from developing Benefits: features:
• The design of the stabilizer keeps • Eccentric primary relief.
vibration and unstable harmonics • Extra fine grain carbide.
from developing during the • Patent #6,991,409.
machining process, resulting in • TiAlN coating will evolve to
SQUARE CORNER chatter-free machining even in deep AlTiN as stock rotates.
slotting cuts.
• Increased productivity, greater
depths of cut, faster speeds, heavier
feeds and better surface finish.
WITH RADIUS SquArE CorNEr WITh rAdIuS
[STS430] [STR430]

ShANk FLuTE ovErALL ordEr prICE CorNEr ordEr prICE
SIZE
dIAMETEr LENGTh LENGTh # EACh rAdIuS # EACh
1/8" 1/8" 1/8" 1-1/2" 16-060-650 $18.80 — — —
1/8 1/8 3/8 1-1/2 16-060-651 21.10 .010" 16-060-680 $21.60
3/16 3/16 3/16 2 16-060-654 25.20 — — —
3/16 3/16 7/16 2 16-060-655 29.20 .010 16-060-684 30.10
SlOTTINg ROUgHINg pROfIlINg 1/4 1/4 1/4 2 16-060-658 32.70 .020 16-060-687 34.40
1/4 1/4 1/2 2-1/2 16-060-659 36.50 .020 16-060-688 38.30
AppLICATIoN MATErIALS: 5/16 5/16 5/16 2 16-060-661 41.40 .020 16-060-690 43.10
MILd STEELS MEdIuM ALLoyS CAST & duCTILE IroNS 5/16 5/16 13/16 2-1/2 16-060-662 45.80 — — —
1018 A36 Cast & Ductile Irons 3/8 3/8 3/8 2 16-060-664 51.10 .020 16-060-693 53.30
1020 4340 Cast & Ductile Irons 3/8 3/8 7/8 2-1/2 16-060-665 56.80 .020 16-060-694 59.50
1/2 1/2 1/2 2-1/2 16-060-670 78.90 .030 16-060-699 82.40
NoTE: 1/2 1/2 1 3 16-060-671 87.50 .030 16-060-700 91.40
• The STABILIZER GP has the unique ability to take heavy cuts, it is possible to 5/8 5/8 1-1/4 3-1/2 16-060-674 184.00 .030 16-060-703 192.00
™
exceed the capacity of the other machining components. 3/4 3/4 3/4 3 — — .030 16-060-704 224.00
• Fixturing, tool holder and spindle bearings all must be able to withstand the 3/4 3/4 1-1/2 4 16-060-676 239.00 — — —
increased metal removal rates the stabilizer can deliver. 1 1 1-1/2 4 16-060-678 380.00 — — —
