END MILLS • 6 & 8 Flute
84

6 Flute 45° Helix Solid Carbide nACo Coated Single End Mills
Center Cutting • Corner Radius

For hardened steel Benefits: feAtures:
with HRc>52 • Higher metal removal rates in • High chip evacuation. TolErAnCES:
light finishing applications. • Excellent material removal in Cutting Diameter: +.000" / -.002"
• Excellent in machining hard to machine materials. Shank Diameter: +.0000" / -.0003"
hardened materials. SHAnk FluTE ovErAll
SizE CornEr orDEr PriCE
APPLiCAtiOns: D1 DiAMETEr lEngTH lEngTH rADiuS # EACH
D2
l2
l1
• For achieving higher metal 1/8" 1/8" 1/2" 1-1/2" .010" 28-500-120 $19.19
removal rates in light finishing 3/16" 3/16" 5/8" 2" .010" 28-500-121 26.67
applications when machining 1/4" 1/4" 3/4" 2-1/2" .015" 28-500-122 38.61
hardened materials. 5/16" 5/16" 13/16" 2-1/2" .020" 28-500-123 49.43
3/8" 3/8" 1" 2-1/2" .020" 28-500-124 56.64
1/2" 1/2" 1" 3" .025" 28-500-125 91.14
6 Flute 45° Helix Solid Carbide TiAln Coated Single End Mills
Center Cutting • Square End • With Corner Radius

Excellent for dry APPLiCAtiOns: SHAnk FluTE ovErAll CornEr orDEr PriCE
machining conditions • Widely used in the mold and die SizE DiAMETEr lEngTH lEngTH rADiuS # EACH
industries. 1/8" 1/8" 1/2" 1-1/2" .010" 09-510-700 $17.81
• Ideal for high speed cutting of heat 3/16 3/16 5/8 2 .010 09-510-702 23.25
treated and tough to machine materials. 1/4 1/4 3/4 2-1/2 .015 09-510-704 31.67
• Excellent for 55 Rc. 5/16 5/16 13/16 2-1/2 .020 09-510-706 39.50
3/8 3/8 7/8 2-1/2 .020 09-510-708 47.06
TolErAnCES: feAtures: 1/2 1/2 1 3 .025 09-510-710 75.07
Cutter Diameter: +.000" / -.002" • Corner radius provides a stronger 5/8 5/8 1-1/4 3-1/2 .030 09-510-712 124.12
Shank Diameter: -.0001" / -.0004" corner on the end mill. 3/4 3/4 1-1/2 4 .035 09-510-714 183.70
TIR Maximum: .0005" 1 1 1-1/2 4 .035 09-510-716 303.92
6 & 8 Flute Micrograin Solid Carbide Single End Mills
Right Hand Spiral • Center Cutting • Straight Shank • 30° Helix
[1516]
SHAnk FluTE ovErAll # oF orDEr PriCE
SizE
DiAMETEr lEngTH lEngTH FluTES # EACH
3/16" 3/16" 5/8" 2" 6 20-516-012 $16.06
APPLiCAtiOns: 1/4 1/4 3/4 2-1/2 6 6 20-516-016 21.10
13/16
26.51
2-1/2
20-516-020
5/16
5/16
• For light stock removal on cast iron, 3/8 3/8 7/8 2-1/2 6 20-516-024 47.00
TolErAnCES: carbon steels and stainless alloys. 7/16 7/16 1 2-3/4 6 20-516-028 49.16
Shank Diameter: -.0000" / -.0005" feAtures: 1/2 1/2 1 3 6 20-516-032 51.90
Cutter Diameter 9/16 9/16 1-1/4 3-1/2 6 20-516-036 129.61
3/16" thru 1/4": +.000" / -.002" • Improves finish. 5/8 5/8 1-1/4 3-1/2 8 20-516-040 112.16
5/16" thru 3/4": +.000" / -.003" 3/4 3/4 1-1/2 4 8 20-516-048 160.24
