Metric Assorted # Of Flutes • END MILLS
89

4 Flute Metric Tialn Coated Solid Carbide Single End Mills
Center Cutting • Square End • 30° Helix

ToLEranCES:
Cutting Diameter: +.000 / -.050mm
Shank Diameter: +.000 / -.012mm
SHank FLuTE oVEraLL orDEr PriCE SHank FLuTE oVEraLL orDEr PriCE
SizE SizE
DiaMETEr LEngTH LEngTH # EaCH DiaMETEr LEngTH LEngTH # EaCH
1mm 3mm 3mm 38mm 20-501-700 $15.67 8mm 8mm 19mm 63mm 20-501-722 $33.65 APPLiCAtiOns:
1.5 3 5 38 20-501-702 15.67 9 10 22 70 20-501-724 45.02 • TiAlN is used mainly on the following materials:
2 3 6 38 20-501-704 12.96 10 10 22 70 20-501-726 40.71 cast iron, aluminum alloys, tool steels and
2.5 3 7 38 20-501-706 12.96 11 11 25 70 20-501-728 60.27 nickel alloys
3 3 12 38 20-501-708 12.96 12 12 25 75 20-501-730 57.38 • Commonly used for dry machining and other
3.5 4 12 50 20-501-710 17.84 14 14 30 88 20-501-732 93.19 high temperature applications.
4 4 14 50 20-501-712 17.26 16 16 32 88 20-501-734 119.09
4.5 5 14 50 20-501-714 17.84 18 18 36 100 20-501-736 136.48 feAtures:
5 5 16 50 20-501-716 18.99 20 20 38 100 20-501-738 169.69 • Hardness: 80 Rc
6 6 19 63 20-501-718 25.75 22 22 38 100 20-501-740 201.37
7 8 19 63 20-501-720 34.66 25 25 38 100 20-501-742 247.35
4 Flute Metric Solid Carbide Long Length Single End Mills
Right Hand • Center Cutting • 30° Helix

ToLEranCES:
Cutting Edge: +0.000mm / - 0.0508mm Other Sizes And Coatings Available,
Shank: H6
Please Call
SHank FLuTE oVEraLL orDEr PriCE
SizE
DiaMETEr LEngTH LEngTH # EaCH
3mm 3mm 25mm 65mm 20-304-000 $21.22 Benefits: APPLiCAtiOns:
4mm 4mm 25mm 65mm 20-304-001 23.73 • Provides good wear resistance and are • Steel, stainless steel, cast irons,
5mm 5mm 25mm 75mm 20-304-002 25.16 used for excellent size control plus the non-ferrous materials & high
6mm 6mm 25mm 75mm 20-304-003 31.63 length allows for an extended reach, temp alloys.
8mm 8mm 25mm 75mm 20-304-004 34.54 especially in tight spaces where a • 4 fluted tool commonly used in profiling
10mm 10mm 38mm 100mm 20-304-005 51.78 greater reach is needed. applications on harder materials than 2
12mm 12mm 50mm 100mm 20-304-006 69.04 flute end mills.
4 Flute Metric SuperCEED Solid Carbide Variable Helix
®
-FACTOR Coated Single End Mills
®
Center Cutting • Square End

Benefits: feAtures:
• Altering cutting flute geometries greatly • Low amplitude variable sine wave
reduce vibrations, thus allowing faster design allows smoother cutting at
metal removal rates, improved surface higher speeds and inches per minute.
finishes and longer tool life. • Made from SuperCEED grade carbide.
®
• Breakup of the chattering and • X-Factor coating improves oxidation variable helix
®
minimized tool deflection provides resistance and toughness. reduces vibrations
faster and deeper machining.
• Increased cutting depth and feed rates.
APPLiCAtiOns:
• Excels on the following materials: mild
steels, cast iron, tool steels, titanium
alloys, pre-hardened steels and low
hardness materials under HRc 40

SHank FLuTE oVEraLL orDEr PriCE
SizE
DiaMETEr LEngTH LEngTH # EaCH
3mm 6mm 8mm 57mm 20-102-220 $18.08
4mm 6mm 11mm 57mm 20-102-221 20.87
5mm 6mm 13mm 57mm 20-102-222 25.04
6mm 6mm 13mm 57mm 20-102-223 28.52
8mm 8mm 19mm 63mm 20-102-224 36.17 ToLEranCES:
10mm 10mm 22mm 72mm 20-102-225 41.74 Shank Diameter: h6
12mm 12mm 26mm 83mm 20-102-226 66.79 Cutting Diameter: +.000mm / - .03mm
