Metric Ball, 2 & 4 Flutes • END MILLS
91

2 Flute Metric Ball End Stub Length Solid Carbide
Miniature End Mills
Center Cutting • 30° Helix

Shank FLutE OvERaLL MODEL ORDER PRiCE
SizE
DiaMEtER LEngth LEngth # # EaCh
0.3mm 3mm 0.5mm 38mm BMSM-003-2 21-101-930 $30.25
0.4 3 0.6 38 BMSM-004-2 21-101-931 22.36 Benefits: APPLiCAtiOns:
0.5 3 0.8 38 BMSM-005-2 21-101-932 20.63
0.6 3 0.9 38 BMSM-006-2 21-101-933 20.63 • Stub length design for added strength. • Intra-occular lens industry, medical
0.7 3 1.1 38 BMSM-007-2 21-101-934 19.64 • Superior finish. device industry where precision cutting
0.8 3 1.2 38 BMSM-008-2 21-101-935 19.64 • Center cutting for precise cutting action is a must.
0.9 3 1.4 38 BMSM-009-2 21-101-936 19.64 upon entry. • Miniature parts, small pockets,
1.0 3 1.5 38 BMSM-010-2 21-101-937 19.17 printed circuit board industry and
1.4 3 2.1 38 BMSM-014-2 21-101-941 19.17 mold applications.
1.5 3 2.3 38 BMSM-015-2 21-101-942 19.17
1.6 3 2.4 38 BMSM-016-2 21-101-943 17.66 feAtures:
1.8 3 2.7 38 BMSM-018-2 21-101-945 17.66 • Stub length for added strength and
1.9 3 2.8 38 BMSM-019-2 21-101-946 17.66 better finishes.
2.0 3 3.0 38 BMSM-020-2 21-101-947 17.66 Other Sizes Available, • Ball nose design allows a radius where
2.5 3 3.8 38 BMSM-025-2 21-101-948 17.66 Please Call the tool meets the workpiece.
2 Flute Metric Solid Carbide Square End
Extended Reach Ball End Mills
For Die & Mold Industry • Center Cutting • 30° Helix

Shank FLutE OvERaLL nECk
SizE DiaMEtER LEngth LEngth DiaMEtER REaCh MODEL ORDER PRiCE
EaCh
#
#
D1 D2 L2 L1 D3 L3 APPLiCAtiOns:
2mm 6mm 5mm 57mm 1.5mm 15mm BLRM-020-2 21-101-900 $29.67 • Neck diameter reduced .020"
3 6 8 75 2.5 30 BLRM-030-2 21-101-901 31.40 for long reach applications.
4 6 8 75 3.5 30 BLRM-040-2 21-101-902 31.40 • Use in softer materials.
5 6 10 100 4.5 50 BLRM-050-2 21-101-903 22.66
6 6 12 100 5.5 50 BLRM-060-2 21-101-904 40.28 feAtures:
8 8 14 100 7.5 50 BLRM-080-2 21-101-905 54.96 • Slightly increased flute and overall length offers the greatest versatility.
10 10 18 120 9.5 65 BLRM-100-2 21-101-906 61.75 • Excellent concentricity on ball nose radius.
12 12 22 130 11.5 80 BLRM-120-2 21-101-907 86.51 • Superior “blend” between ball radius and linear cutting edge.
4 Flute Metric Ball End Stub Length Solid Carbide
Miniature End Mills
Center Cutting • 30° Helix

Other Sizes Available,
Benefits: feAtures: Please Call
• Stub length design for added strength. • Stub length for added strength and Shank FLutE OvERaLL MODEL ORDER PRiCE
• Superior finish. better finishes. SizE DiaMEtER LEngth LEngth # # EaCh
• Center cutting for precise cutting action • Ball nose design allows a radius where 1.0mm 3mm 1.5mm 38mm BMSM-010-4 21-101-960 $19.17
upon entry. the tool meets the workpiece. 1.2 3 1.8 38 BMSM-012-4 21-101-962* 19.27
1.5 3 2.3 38 BMSM-015-4 21-101-965* 19.27
APPLiCAtiOns: 1.9 3 2.8 38 BMSM-019-4 21-101-969 17.66
• Intra-occular lens industry, medical device industry where precision cutting is a must. 2.0 3 3.0 38 BMSM-020-4 21-101-970* 17.75
• Miniature parts, small pockets, printed circuit board industry and mold applications. *Limited Supply.
4 Flute Metric Solid Carbide Square End
Extended Reach Ball End Mills
For Die & Mold Industry • Center Cutting • 30° Helix

Shank FLutE OvERaLL nECk
SizE DiaMEtER LEngth LEngth DiaMEtER REaCh MODEL ORDER PRiCE APPLiCAtiOns:
#
EaCh
#
D1 D2 L2 L1 D3 L3 • Neck diameter reduced .020"
2mm 6mm 5mm 57mm 1.5mm 15mm BLRM-020-4 21-101-910 $29.67 for long reach applications.
3 6 8 75 2.5 30 BLRM-030-4 21-101-911 31.40 • Use in harder materials.
4 6 8 75 3.5 30 BLRM-040-4 21-101-912 31.40
6 6 12 100 5.5 50 BLRM-060-4 21-101-914 40.28 feAtures:
8 8 14 100 7.5 50 BLRM-080-4 21-101-915 54.96 • Slightly increased flute and overall length offers the greatest versatility.
10 10 18 120 9.5 65 BLRM-100-4 21-101-916 61.75 • Excellent concentricity on ball nose radius.
12 12 22 130 11.5 80 BLRM-120-4 21-101-917 86.51 • Superior “blend” between ball radius and linear cutting edge.
