ALORIS CARBIDE INSERTS

GRADES
SHAPE OR CHIPBREAKER ORDER # DIMENSIONS
DEPICTED GRADE A2/A6 † GRADE 767 †
I.C. THICK- RADIUS HOLE
NESS
WNMG-331 MN* 3 /8 3 /16 1 /64 .150 7.60 10.75
WNMG-332 MN* 3 /8 3 /16 1 /32 .150 7.60 10.75
WNMG-333 MN* 3 /8 3 /16 3 /64 .150 7.60 10.75
WNMG-431 MN* 1 /2 3 /16 1 /64 .203 9.34 12.96
WNMG-432 MN* 1 /2 3 /16 1 /32 .203 9.34 12.96
WNMG WNMG-433 MN* 1 /2 3 /16 3 /64 .203 9.34 12.96

Quantities of 100 and over, call for price.

LAY DOWN THREADING INSERTS

DIMENSIONS GRADES GRADES
SHAPE OR CHIPBREAKER ORDER #
DEPICTED I.C. THICK- RADIUS HOLE X Y TPI A2/A6 767
NESS
1 ⁄4 AIT-R60* 1 /4 .126 .0018 .128 .031 .035 16-48 31.50 37.25
1 ⁄4 AIT-L60* 1 /4 .126 .0018 .128 .031 .035 16-48 31.50 37.25
3 ⁄8 AIT-R60* 3 /8 .143 .002 .155 .047 .067 8-48 31.50 37.25
3 ⁄8 AIT-L60* 3 /8 .143 .002 .155 .047 .067 8-48 31.50 37.25
1 ⁄2 AIT-R60* 1 /2 .188 .008 .192 .067 .098 5-7 38.10 45.85
AIT-R/L60 1 ⁄2 AIT-L60* 1 /2 .188 .008 .192 .067 .098 5-7 38.10 45.85
16ER LAG 60-RH* 3 /8 .143 .002 .155 .047 .067 8-48 31.50 37.25
16ER LAG 60-LH* 3 /8 .143 .002 .155 .047 .067 8-48 31.50 37.25
22ER LN 60-RH* 1 /2 .188 .0132 .192 .067 .098 5-7 38.10 45.85
ER/L60 22ER LN 60-LH* 1 /2 .188 .0132 .192 .067 .098 5-7 38.10 45.85
Inserts sold in packages of 10. Prices are per piece.

NOW AVAILABLE FROM ALORIS

ALORIS/YES TOOL QUICKTIP DRILLS

CALL FOR A COMPLETE CATALOG
