MaxiMill 251 system
B178
A251-10/-12

Ø d
H6
Ø d A

h

a

Ø d 1
Ø d 2

d 2 Type, d 1 h d d A a z n max
-1
[mm] description [mm] [mm] [mm] [mm] [mm] [min ] [Nm]

40 A251.40.R.03-10-RS 30 40 38 16 5 3 15900 2.0 RP.. 10T3.. E01

40 A251.40.R.05-10-RE 30 40 38 16 5 5 15900 2.0 RP.. 10T3.. E01

40 A251.40.R.05-10-RS 30 40 38 16 5 5 15900 2.0 RP.. 10T3.. E02

42 A251.42.R.06-10-RE 32 40 38 16 5 6 15150 2.0 RP.. 10T3.. E01

42 A251.42.R.06-10-RS 32 40 38 16 5 6 15150 2.0 RP.. 10T3.. E02

50 A251.50.R.04-10-RS 40 40 43 22 5 4 12700 2.0 RP.. 10T3.. E01

50 A251.50.R.06-10-RE 40 40 43 22 5 6 12700 2.0 RP.. 10T3.. E01

50 A251.50.R.06-10-RS 40 40 43 22 5 6 12700 2.0 RP.. 10T3.. E01

52 A251.52.R.06-10-RE 42 40 43 22 5 6 12200 2.0 RP.. 10T3.. E01
52 A251.52.R.06-10-RS 42 40 43 22 5 6 12200 2.0 RP.. 10T3.. E01

40 A251.40.R.04-12-RE 28 40 38 16 6 4 15900 3.2 RP.. 1204.. E03

40 A251.40.R.04-12-RS 28 40 38 16 6 4 15900 3.2 RP.. 1204.. E04

50 A251.50.R.04-12-RS 38 40 43 22 6 4 12700 3.2 RP.. 1204.. E05

50 A251.50.R.05-12-RE 38 40 43 22 6 5 12700 3.2 RP.. 1204.. E03

50 A251.50.R.05-12-RS 38 40 43 22 6 5 12700 3.2 RP.. 1204.. E05

52 A251.52.R.05-12-RE 40 40 43 22 6 5 12200 3.2 RP.. 1204.. E06

52 A251.52.R.05-12-RS 40 40 43 22 6 5 12200 3.2 RP.. 1204.. E05

63 A251.63.R.06-12-RE 51 40 48 22 6 6 10100 3.2 RP.. 1204.. E03

63 A251.63.R.06-12-RS 51 40 48 22 6 6 10100 3.2 RP.. 1204.. E05

66 A251.66.R.07-12-RE 54 40 48 22 6 7 9650 3.2 RP.. 1204.. E03

66 A251.66.R.07-12-RS 54 40 48 22 6 7 9650 3.2 RP.. 1204.. E05

80 A251.80.R.05-12-RS 68 50 58 27 6 5 7950 3.2 RP.. 1204.. E05

80 A251.80.R.07-12-RE 68 45 58 27 6 7 7950 3.2 RP.. 1204.. E03

80 A251.80.R.07-12-RS 68 50 58 27 6 7 7950 3.2 RP.. 1204.. E05

100 A251.100.R.06-12-RS 88 50 78 32 6 6 6350 3.2 RP.. 1204.. E05

100 A251.100.R.10-12-RS 88 50 78 32 6 10 6350 3.2 RP.. 1204.. E05
E01 11464141 11464183 8095010400
E02 11036880 11464141 11464183 8095010400
E03 11610311 11450867 8095012000
E04 11036880 165795 11149570 8095010500
E05 165795 11149570 8095010500
Milling / Form milling
E06 11610311 11149570 8095012000

B276
