Page 53 - Ceratizit Catalog

Chip grooves for aluminium wheel machining
A32

Machining conditions
-24P

○ For the machining of wrought aluminium with less than 1 % of

silicon, non-ferrous metals, plastics and refractory metals
○ Medium and rough machining
○ Good chip control for a wide range of applications

H210T, H216T H210T, H216T H210T, H216T

Machining conditions
-F4

○ PCD segment without chip groove
○ Mainly suitable for interrupted cut
○ Available types of edge preparation: sharp (F), honed (E),
chamfered (T) according to the ISO designation system

CTD4110 CTD4110 CTD4110

Machining conditions
-F41

○ PCD segment

○ Chip groove for good chip control and small depths of cut
○ Available types of edge preparation: sharp (F), honed (E),
chamfered (T) according to the ISO designation system

CTD4110 CTD4110 CTD4110

Machining conditions
-M4

○ PCD segment with carbide pin to improve chip control with

larger depths of cut
○ Available types of edge preparation: sharp (F), honed (E),
chamfered (T) according to the ISO designation system

CTD4110 CTD4110 CTD4110

Machining conditions
-M41

○ PCD segment with proven M41 chip groove

○ Optimised chip groove for low cutting pressure and ideal chip
Turning / Introduction
form
○ Available types of edge preparation: sharp (F), honed (E),
chamfered (T) according to the ISO designation system
CTD4110 CTD4110 CTD4110
