EcoCut Mini
E13
ECM..

P ●
M ●
K
N ●
S ●
H
CTPP435 CTWN425 RL D min d A l 1 l 2 r f

6
0.2
2
35
ECM 04L-2.25D-27 ● L [mm] [mm] [mm] [mm] [mm] [mm]
4
9
ECM 04L-4.00D-27 ● L 4 6 41 16 0.2 2
ECM 04R-2.25D-27 ● R 4 6 35 9 0.2 2
ECM 04R-4.00D-27 ● R 4 6 41 16 0.2 2
ECM 05L-2.25D-27 ● L 5 6 37 11.25 0.2 2.5
ECM 05L-4.00D-27 ● L 5 6 45 20 0.2 2.5
ECM 05R-2.25D-27 ● R 5 6 37 11.25 0.2 2.5
ECM 05R-4.00D-27 ● R 5 6 45 20 0.2 2.5
ECM 06L-2.25D-27 ● L 6 8 38 13.5 0.2 3
24
-27 ECM 06L-4.00D-27 ● R L 6 6 8 8 49 13.5 0.2 3 3
●
0.2
38
ECM 06R-2.25D-27
ECM 06R-4.00D-27 ● R 6 8 49 24 0.2 3
ECM 07L-2.25D-27 ● L 7 8 42 15.75 0.2 3.5
ECM 07L-4.00D-27 ● L 7 8 53 28 0.2 3.5
ECM 07R-2.25D-27 ● R 7 8 42 15.75 0.2 3.5
ECM 07R-4.00D-27 ● R 7 8 53 28 0.2 3.5
ECM 08L-2.25D-27 ● L 8 8 45 18 0.2 4
ECM 08L-4.00D-27 ● L 8 8 57 32 0.2 4
ECM 08R-2.25D-27 ● R 8 8 45 18 0.2 4
ECM 08R-4.00D-27 ● R 8 8 57 32 0.2 4
ECM 04L-2.25D ● L 4 6 35 9 0.2 2
ECM 04L-4.00D ● L 4 6 41 16 0.2 2
ECM 04R-2.25D ● R 4 6 35 9 0.2 2
ECM 04R-4.00D ● R 4 6 41 16 0.2 2
ECM 05L-2.25D ● L 5 6 37 11.25 0.2 2.5
ECM 05L-4.00D ● L 5 6 45 20 0.2 2.5
ECM 05R-2.25D ● R 5 6 37 11.25 0.2 2.5
ECM 05R-4.00D ● R 5 6 45 20 0.2 2.5
ECM 06L-2.25D ● L 6 8 38 13.5 0.2 3
EN ECM 06L-4.00D ● L 6 8 49 24 0.2 3
ECM 06R-2.25D ● R 6 8 38 13.5 0.2 3
ECM 06R-4.00D ● R 6 8 49 24 0.2 3
ECM 07L-2.25D ● L 7 8 42 15.75 0.2 3.5
ECM 07L-4.00D ● L 7 8 53 28 0.2 3.5
ECM 07R-2.25D ● R 7 8 42 15.75 0.2 3.5
ECM 07R-4.00D ● R 7 8 53 28 0.2 3.5
ECM 08L-2.25D ● L 8 8 45 18 0.2 4
ECM 08L-4.00D ● L 8 8 57 32 0.2 4
ECM 08R-2.25D ● R 8 8 45 18 0.2 4
8
ECM 08R-4.00D ● RL D min d A 57 32 0.2 4 f
R
8
r
CTPP435 CTWN425
l 2
l 1
90° +15’
D d A
l 2 l 1
