EcoCut
E17
XC..

P ●●●
M ○●○
K ●○●○●
N ○ ●●
S ● ●
H
CTCP425 CTPP430 CTCP435 H210T H216T d l s r d 1

5.80
2.25
XCNT 050204EN-M50Q ● [mm] [mm] [mm] [mm] [mm]
0.40
2.10
5.00
XCNT 060204EN-M50Q ● 6.50 6.00 2.38 0.40 2.50
XCNT 070304EN-M50Q ● 7.60 7.00 3.18 0.40 2.80
XCNT 080304EN-M50Q ● 8.50 8.00 3.18 0.40 3.40
-M50Q XCNT 09T304EN-M50Q ● 10.60 10.00 3.97 0.40 3.40
9.60
9.00
●
3.97
XCNT 10T304EN-M50Q
4.40
0.40
XCNT 10T308EN-M50Q ● 10.60 10.00 3.97 0.80 4.40
XCNT 130404EN-M50Q ● 13.50 12.50 4.76 0.40 5.30
XCNT 130408EN-M50Q ● 13.50 12.50 4.76 0.80 5.30
XCNT 170508EN-M50Q ● 17.50 16.00 5.56 0.80 5.30
r
d
l
s
CTCP425 CTPP430 CTCP435 H210T H216T
d 1

Multi-function tools / EcoCut E21-E22 E18-E20
