Page 176 - Fullerton Tool Catalog
P. 176
REAMERS
1400 General Purpose Reamers
Tool Flute Shank Overall Number Steel EDP Number
Cutting Diameter Length Length Diameter Length of Flutes Shank
Style UC
.0820 45 STB 1/2 .0781 2 4 14034
.0860 44 STB 1/2 .0781 2 4 14035
.0890 43 STB 1/2 .0781 2 4 14036
.0935 42 STB 1/2 .0781 2 4 14037
.0938 3/32 STB 1/2 .0781 2 4 14038
.0960 41 STB 1/2 .0781 2 4 14039
.0980 40 STB 5/8 .0938 2 1/4 4 14040
.0995 39 STB 5/8 .0938 2 1/4 4 14042
.1015 38 STB 5/8 .0938 2 1/4 4 14043
.1040 37 STB 5/8 .0938 2 1/4 4 14044
.1065 36 STB 5/8 .0938 2 1/4 4 14045
.1094 7/64 STB 5/8 .0938 2 1/4 4 14046
.1100 35 STB 5/8 .0938 2 1/4 4 14047
.1110 34 STB 5/8 .0938 2 1/4 4 14048
.1130 33 STB 5/8 .1094 2 1/4 4 14049
.1160 32 STB 5/8 .1094 2 1/4 4 14050
.1200 31 STB 5/8 .1094 2 1/4 4 14052
.1240 STB 5/8 .1094 2 1/4 4 14150
.1245 STB 5/8 .1094 2 1/4 4 14151
.1250 1/8 STB 5/8 .1094 2 1/4 4 14053
.1255 STB 5/8 .1094 2 1/4 4 14153
.1260 STB 5/8 .1094 2 1/4 4 14154
.1285 30 STB 3/4 .1250 2 1/2 4 14054
.1360 29 STB 3/4 .1250 2 1/2 4 14055
.1405 28 STB 3/4 .1250 2 1/2 4 14057
.1406 9/64 STB 3/4 .1250 2 1/2 4 14058
.1440 27 STB 3/4 .1250 2 1/2 4 14059
.1470 26 STB 3/4 .1406 2 1/2 4 14060
.1495 25 STB 3/4 .1406 2 1/2 4 14061
.1520 24 STB 3/4 .1406 2 1/2 4 14062
.1540 23 STB 3/4 .1406 2 1/2 4 14063
.1562 5/32 STB 3/4 .1406 2 1/2 4 14064
UNCOATED
.1570 22 STB 3/4 .1406 2 1/2 4 14065
I M .1590 21 STB 3/4 .1406 2 1/2 4 4 14067
7/8
STB
20
.1562
14068
.1610
2 3/4
IMPERIAL METRIC .1660 19 STB 7/8 .1562 2 3/4 4 14069
.1695 18 STB 7/8 .1562 2 3/4 4 14070
.1719 11/64 STB 7/8 .1562 2 3/4 4 14071
.1730 17 STB 7/8 .1562 2 3/4 4 14072
.1770 16 STB 7/8 .1719 2 3/4 4 14073
.1800 15 STB 7/8 .1719 2 3/4 4 14075
.1820 14 STB 7/8 .1719 2 3/4 4 14076
.1850 13 STB 7/8 .1719 2 3/4 4 14077
.1865 STB 7/8 .1719 2 3/4 4 14155
.1870 STB 7/8 .1719 2 3/4 4 14156
■ Titanium ■ Super Alloys ■ Hardened Steels ■ Stainless Steels ■ Steels ■ Cast Iron ■ Graphite ■ Brass & Copper ■ High Si Al
■ Low Si Al ■ Composites ■ Plastics ■ Wood ■ General Purpose
174 Visit fullertontool.com for the most up to date information.
