Page 171 - Fullerton Tool Catalog

REAMERS

1410 JIT Decimal Size Reamers

Solid Carbide
12
24-Hour
Just in Time PIECES
Delivery OR LESS
3:00 PM EST
Order Deadline All Styles

Straight Flutes For all types of general reaming applications.

RH Spiral Flutes For blind holes and abrasive, ductile materials. Do not use for holes with
interruptions unless material is reasonably soft.

LH Spiral Flutes Produces better finishes on hard materials such as heat-treated steels.
Shear action is excellent for holes with interruptions;
i.e., keyways, elongated slots, etc.

Straight Flute Standard Sizes available in 1400 Series Stub
Available with Coatings at Tolerances as Low as .0001”
(Additional Charges May Apply)
Manufactured using Female and Male Centers for improved
concentricity
Male Centers on items up to .1124” (2.86mm)
45˚ Lead Angle UNCOATED
Speeds and Feeds, see fullertontool.com
I
Same Day Delivery If Ordered by 11AM EST Add 20% to Price
IMPERIAL

Tolerance:
Shank Diameter: +.0005” -.0005”
+0.013mm -0.013mm
Cutting Diameter:
Up to .2500” +.0002” -.0000”
Over .2501” +.0003” -.0000”
Up to 6.35mm +0.005mm -0.000mm
Over 6.351mm +0.008mm -0.000mm
.0001” Tolerances Available (+20%)

Visit fullertontool.com for the most up to date information. 169
