Page 63 - Parlec Catalog

ER Collets

High Precision Toolholding Solutions 61

ER TAP COLLETS L

D

ER Tap
Collet
*For specifications see page 54.

ER 16 INCH/METRIC ER 25 INCH/METRIC ER 40 INCH/METRIC

Part Number Inch Size ANSI Metric Part Number Inch Size ANSI Metric Part Number Inch Size ANSI Metric
ERT16-#0-6 #0-#6 - ERT25-025 1/4" M6,M6.5 ERT40-012N 1/8" NPT -
ERT16-#8 #8 M4 ERT25-031 5/16" M7, M8 ERT40-025 1/4" M6,M6.5
ERT16-#10 #10 M4.5, M5 ERT25-037 3/8" M10 ERT40-025N 1/4" NPT -
ERT16-#12 #12 - ERT25-043 7/16" - ERT40-031 5/16" M7, M8
ERT16-025 1/4" M6,M6.5 ERT25-050 1/2" M12,M12.5 ERT40-037 3/8" M10
ERT16-031 5/16" M7, M8 ERT25-056 9/16" M14 ERT40-037N 3/8" NPT -
ERT16-037 3/8" M10 ERT25-062 5/8" M16 ERT40-043 7/16" -
ERT16-043 7/16" - ERT40-050 1/2" M12,M12.5
ERT16-050 1/2" M12,M12.5 ER 25 INCH/METRIC SET ERT40-050N 1/2" NPT -
ER 16 INCH/METRIC SET PART NUMBER ERT25-S011 ERT40-056 9/16" M14
M16
ERT40-062
5/8"
PART NUMBER ERT16-S009 NUMBER OF PIECES 11 PIECES ERT40-068 11/16" M18
RANGE
#8-5/8"
NUMBER OF PIECES 9 PIECES ERT40-075 3/4" -
RANGE #0-1/2" ER 32 INCH/METRIC ERT40-081 13/16" M20
ER 20 INCH/METRIC ERT32-#0-6 #0-#6 - ERT40-087 7/8" M22
15/16"
M24
ERT40-093
ERT20-#8 #8 M4 ERT32-#8 #8 M4 ERT40-100 1" M25
ERT32-#10
#10
M4.5, M5
ERT20-#10 #10 M4.5, M5 ERT32-#12 #12 - ER 40 INCH/METRIC SET
ERT20-#12 #12 - ERT32-012N 1/8" NPT -
ERT20-025 1/4" M6,M6.5 ERT32-025 1/4" M6,M6.5 PART NUMBER ERT40-S017
ERT20-031 5/16" M7, M8 ERT32-025N 1/4" NPT - NUMBER OF PIECES 17 PIECES
ERT20-037 3/8" M10 ERT32-031 5/16" M7, M8 RANGE 1/4" - 1"
ERT20-043 7/16" - ERT32-037 3/8" M10
ERT20-050 1/2" M12,M12.5 ERT32-043 7/16" -
ER 20 INCH/METRIC SET ERT32-050 1/2" M12,M12.5
PART NUMBER ERT20-S008 ERT32-056 9/16" M14
M16
ERT32-062
5/8"
NUMBER OF PIECES 8 PIECES ERT32-068 11/16" M18
RANGE #8-1/2" ERT32-075 3/4" -
ER 25 INCH/METRIC ERT32-081 13/16" M20
ERT25-#8 #8 M4 ER 32 INCH/METRIC SET
ERT25-#10 #10 M4.5, M5 PART NUMBER ERT32-S016
ERT25-#12 #12 -
ERT25-012N 1/8" NPT - NUMBER OF PIECES 16 PIECES
RANGE #6-13/16"
