ER Collets

56 High Precision Toolholding Solutions

ER STANDARD COLLET L

D

ER Standard
Collet
*For specifications see page 54.

ER 25 METRIC ER 32 METRIC ER 40 INCH SET

Part Number Size Range Part Number Size Range Part Number Size Range
ER25-0315 8 mm 7-8 mm ER32-0236 6 mm 5-6 mm PART NUMBER ER40-S024
ER25-0354 9 mm 8-9 mm ER32-0275 7 mm 6-7 mm NUMBER OF PIECES 24 PIECES
ER25-0393 10 mm 9-10 mm ER32-0315 8 mm 7-8 mm RANGE .2814”-1.0000"
ER25-0433 11 mm 10-11 mm ER32-0354 9 mm 8-9 mm ER 40 METRIC
ER25-0472 12 mm 11-12 mm ER32-0393 10 mm 9-10 mm
ER25-0511 13 mm 12-13 mm ER32-0433 11 mm 10-11 mm ER40-0157 4 mm 3-4 mm
ER25-0551 14 mm 13-14 mm ER32-0472 12 mm 11-12 mm ER40-0196 5 mm 4-5 mm
ER25-0590 15 mm 14-15 mm ER32-0511 13 mm 12-13 mm ER40-0236 6 mm 5-6 mm
ER25-0630 16 mm 15-16 mm ER32-0551 14 mm 13-14 mm ER40-0275 7 mm 6-7 mm
ER 25 METRIC SET ER32-0590 15 mm 14-15 mm ER40-0315 8 mm 7-8 mm
8-9 mm
9 mm
ER40-0354
ER32-0630
16 mm
15-16 mm
PART NUMBER ER25-S015 ER40-0393 10 mm 9-10 mm
NUMBER OF PIECES 15 PIECES ER 32 METRIC SET ER40-0433 11 mm 10-11 mm
RANGE 2 - 16 mm PART NUMBER ER40-S023 ER40-0472 12 mm 11-12 mm
ER 32 INCH NUMBER OF PIECES 23 PIECES ER40-0511 13 mm 12-13 mm
14 mm
13-14 mm
ER40-0551
ER32-0093 3/32” .0540"-.0937" RANGE 4 - 26 mm ER40-0590 15 mm 14-15 mm
ER32-0125 1/8” .0860"-.1250" ER 40 INCH ER40-0630 16 mm 15-16 mm
ER32-0156 5/32” .1170"-.1560" ER40-0125 1/8” .0860"-.1250" ER40-0669 17 mm 16-17 mm
ER32-0187 3/16” .1480"-.1870" ER40-0708 18 mm 17-18 mm
ER32-0218 7/32” .1790"-.2180" ER40-0187 3/16” .1480"-.1870" ER40-0748 19 mm 18-19 mm
ER32-0250 1/4” .2110"-.2500" ER40-0218 7/32” .1790"-.2180" ER40-0787 20 mm 19-20 mm
.2110"-.2500"
1/4”
ER40-0250
ER32-0281 9/32” .2420"-.2810" ER40-0826 21 mm 20-21 mm
ER32-0312 5/16” .2730"-.3120" ER40-0281 9/32” .2420"-.2810" ER40-0866 22 mm 21-22 mm
ER32-0343 11/32” .3040"-.3430" ER40-0312 5/16” .2730"-.3120" ER40-0905 23 mm 22-23 mm
ER32-0375 3/8” .3360"-.3750" ER40-0343 11/32” .3040"-.3430" ER40-0944 24 mm 23-24 mm
ER32-0406 13/32” .3666"-.4062" ER40-0375 3/8” .3360"-.3750" ER40-0984 25 mm 24-25 mm
ER32-0437 7/16” .3980"-.4370" ER40-0406 13/32” .3666"-.4062" ER40-1023 26 mm 25-26 mm
ER32-0468 15/32” .4290"-.4680" ER40-0437 7/16” .3980"-.4370" ER40-1063 27 mm 26-27 mm
ER32-0500 1/2” .4610"-.5000" ER40-0468 15/32” .4290"-.4680" ER40-1102 28 mm 27-28 mm
ER32-0531 17/32” .4920"-.5310" ER40-0500 1/2” .4610"-.5000" ER40-1141 29 mm 28-29 mm
ER32-0562 9/16” .5230"-.5620" ER40-0531 17/32” .4920"-.5310" ER40-1181 30 mm 29-30 mm
ER32-0593 19/32” .5544"-.5937" ER40-0562 9/16” .5230"-.5620"
19/32”
.5544"-.5937"
ER40-0593
ER32-0625 5/8” .5860"-.6250"
ER32-0656 21/32” .6170"-.6560" ER40-0625 5/8” .5860"-.6250" ER 40 METRIC SET
ER32-0687 11/16” .6480"-.6870" ER40-0656 21/32” .6170"-.6560" PART NUMBER ER40-S023
ER32-0718 23/32” .6794"-.7187" ER40-0687 11/16” .6480"-.6870" NUMBER OF PIECES 23 PIECES
ER32-0750 3/4” .7110"-.7500" ER40-0718 23/32” .6794"-.7187" RANGE 4 - 26 mm
ER32-0781 25/32" .7419"-.7812" ER40-0750 3/4” .7110"-.7500"
.7419"-.7812"
ER40-0781
25/32”
ER 32 INCH SET ER40-0812 13/16” .7732"-.8125"
PART NUMBER ER32-S021 ER40-0843 27/32” .8044"-.8437"
NUMBER OF PIECES 21 PIECES ER40-0875 7/8” .8360"-.8750"
RANGE 1/8" - 3/4" ER40-0906 29/32” .868-.906"
ER 32 METRIC ER40-0937 15/16” .8982"-.9375"
ER40-0968
31/32”
.9291"-.9685"
ER32-0118 3 mm 2-3 mm ER40-1000 1” .9610"-1.0000"
ER32-0157 4 mm 3-4 mm
ER32-0196 5 mm 4-5 mm
