C-ADER/L Adapters for square shank toolholders
h

øD L1
f1
h1
f
L2

Stock Dimensions (mm)
Cat. No. Clamp screw
R L øD f1 L2 f h1 h L1

C4ADE-20R/L   40 35 54 25 20 20 67 SRM10X20DIN912
C5ADE-20R/L   50 35 60 20 20 20 67 SRM10X16
Toolholders may be used after shortening shank length
C-ASHR/L Adapters for square shank toolholders

b L2 L3 øD1 h1 h2
f2
h3
øD

L1
Stock Dimensions (in)
Cat. No. Clamp screw
R L øD L1 L2 L3 f2 h1 b h2 h3 øD1

C6ASHR/L3/4X1   2.5 3.937 2.5 1.044 0.4 0.75 0.8 1 1.181 3.543 SRM10X25DIN915
C6ASHR/L1X1   2.5 4.724 2.8 1.181 0.5 1 1 1 1.496 3.937 SRM12X30DIN915
Tooling Systems Cat. No. Stock øD L1 L2 Dimensions (mm) b h2 h3 øD1 Clamp screw
Toolholders may be used after shortening shank length

L
R
L3
h1
f2
C5ASHR/L201   50 98 63.5 24.5 10 20 20 33 30 90 SRM10X25DIN91545H
C6ASHR/L251   63 120 70 30 13 25 25 32 38 100
12 C8ASHR/L32-1   80 140 95 35 8 32 32 32 40 110 SRM12X30DIN91545H
Toolholders may be used after shortening shank length
C-ADES Adapters for square shank toolholders

L Coolant nozzle
L3

16.6 øD 74 90

F1
f
r1
r2 h
Dimensions (mm)
Cat. No. Stock
øD F1 r2 L L3 h f r1
C4ADES-20  40 41.6 98 85 71 20 25 67
C5ADES-20  50 41.6 98 85 71 20 25 67
