Dream Cut • BURRS
115

Carbide Dream Cut Coarse/Fine Tooth Combination Burrs & 7 Piece Set

Replaces the need for separate
coarse tooth and fine tooth burrs
Benefits: APPLiCAtiOns:
• Highly efficent for metal removal • Effectively utilizes its unique coarse
and smooth finishing. teeth for rapid and strong metal
removal coupled with fine teeth for
smooth finishing. 7 Piece Set
• Suitable for deburring and polishing of 7 PieCe SeT
cast iron, cast steel, carbon steel, alloy Shank OrDer PriCe
steel and stainless steel etc. inCLuDeS DiameTer # Per SeT
look For
tHe Green (1) each of models: #SA43,#SB43, #SC42, #SD42, 1/8" 20-025-070 $46.85
#SE41, #SF42 & #SL42 in a plastic case
CuTTer FLuTe Shank OveraLL mODeL OrDer PriCe CuTTer FLuTe Shank OveraLL mODeL OrDer PriCe
DiameTer LengTh DiameTer LengTh # # eaCh DiameTer LengTh DiameTer LengTh # # eaCh
SerieS Sa CyLinDriCaL - nOT enD CuT SerieS Sh FLame
1/8" 9/16" 1/8" 1-1/2" SA43 20-025-002 $8.18 5/16" 3/4" 1/4" 2-1/2" SH2 20-025-044 $25.47
1/4 5/8 1/4 2-1/8 SA1 20-025-004 12.93 SerieS SH
5/16 3/4 1/4 2-1/2 SA2 20-025-006 18.78 FlAme 1/2 1-1/4 1/4 3 SH5 20-025-046 50.16
3/8 3/4 1/4 2-1/2 SA3 20-025-008 18.21 SerieS SF Tree raDiuS
1/2 1 1/4 2-3/4 SA5 20-025-010 28.19
SerieS SA 1/8" 1/2" 1/8" 1-1/2" SF42 20-025-048 $8.18
SerieS SB CyLinDriCaL - WiTh enD CuT
1/8" 9/16" 1/8" 1-1/2" SB43 20-025-012 $8.18 1/4 3/4 1/4 2-1/8 SF1 20-025-050 15.98
1/4 5/8 1/4 2 SB1 20-025-014 15.45 3/8 3/4 1/4 2-1/2 SF3 20-025-052 19.71
3/8 3/4 1/4 2-1/2 SB3 20-025-016 21.86 1/2 1 1/4 2-3/4 SF5 20-025-054 29.19
1/2 1 1/4 2-3/4 SB5 20-025-018 33.88 SerieS SF
SerieS SB SerieS SC CyLinDriCaL raDiuS enD SerieS Sg Tree POinTeD enD
1/8" 9/16" 1/8" 1-1/2" SC42 20-025-020 $8.18 1/8" 1/4" 1/8" 1-1/2" SG41 20-025-056 $8.18
3/32 7/16 1/8 1-1/2 SC41 20-025-022 8.18 1/4 5/8 1/4 2-1/8 SG1 20-025-058 15.98
3/16 5/8 1/4 2-1/8 SC14 20-025-024 17.08 SerieS SG SerieS Sh FLame POinT
1/4 5/8 1/4 2-1/8 SC1 20-025-026 15.38
3/8 3/4 1/4 2-1/2 SC3 20-025-028 20.16 1/8" 1/4" 1/8" 1-1/2" SH41 20-025-060 $8.18
1/2 1 1/4 2-3/4 SC5 20-025-030 31.73
SerieS Sc
SerieS SD BaLL SerieS SL TaPer/COne raDiuS enD
1/8" 1/8" 1/8" 1-1/2" SD42 20-025-032 $8.18 SerieS 1/8" 3/8" 1/8" 1-1/2" SL41 20-025-062 $8.18
3/32 3/32 1/8 1-1/2 SD41 20-025-034 8.18 SH FlAme 1/8 1/2 1/8 1-1/2 SL42 20-025-064 8.18
Point
1/2 7/16 1/4 2-13/64 SD5 20-025-038 22.77
SerieS SD SerieS Se OvaL 1/4 5/8 1/4 2-1/8 SL1 20-025-066 17.49
1/8" 7/32" 1/8" 1-1/2" SE41 20-025-040 $8.18 3/8 1-1/16 1/4 2-5/16 SL3 20-025-068 27.74
1/4 3/8 1/4 2-1/8 SE1 20-025-042 18.30
SerieS Se SerieS Sl
Carbide Dream Cut Coarse/Fine Tooth Combination 6" Overall Length Burrs & 7 Piece Set

Replaces the need for separate
coarse tooth and fine tooth burrs
Benefits:
• Highly efficent for metal removal
and smooth finishing.
APPLiCAtiOns:
• Effectively utilizes its unique coarse teeth for
rapid and strong metal removal coupled with
fine teeth for smooth finishing.
• Suitable for deburring and polishing of cast
iron, cast steel, carbon steel, alloy steel and
stainless steel etc.
• 6" overall length for harder to reach areas.
inDiviDuaL BurrS For HArD to reAcH AreAS
CuTTer FLuTe Shank mODeL OrDer PriCe
ShaPe
Dia. LengTh Dia. # # eaCh
Cylindrical 1/8" 9/16" 1/8" SA43L6 20-025-072 $13.04
Cylindrical 1/4 5/8 1/4 SA1L6 20-025-074 23.47
Cylindrical 1/2 1 1/4 SA5L6 20-025-076 31.28
Cylindrical End Cut 1/8 9/16 1/8 SB43L6 20-025-078 13.04
Cylindrical End Cut 1/4 5/8 1/4 SB1L6 20-025-080 23.47
Cylindrical Radius End 1/8 9/16 1/8 SC42L6 20-025-082 13.04
Cylindrical Radius End 1/4 5/8 1/4 SC1L6 20-025-084 23.47
Cylindrical Radius End 3/8 3/4 1/4 SC3L6 20-025-086 24.38 moDel moDel moDel moDel moDel moDel moDel
Ball 1/8 1/8 1/8 SD42L6 20-025-088 13.04 #SA1l6 #SB1l6 #Sc3l6 #SD1l6 #Se41l6 #SF3l6 #Sl41l6
Ball 1/4 1/4 1/4 SD1L6 20-025-090 23.47
Oval 1/8 7/32 1/8 SE41L6 20-025-092 13.04 7 PieCe SeT
Tree Radius 1/8 1/2 1/8 SF42L6 20-025-094 12.78 inCLuDeS OrDer PriCe
Tree Radius 3/8 3/4 1/4 SF3L6 20-025-096 25.06 # Per SeT
Taper/Cone Radius End 1/8 3/8 1/8 SL41L6 20-025-098 13.04 (1) each of unique shapes: SA5L6, SB1L6, SC3L6, SD1L6, 20-025-107 $146.47
Taper/Cone Radius End 1/8 1/2 1/8 SL42L6 20-025-100 13.04 SE41L6, SF3L6, SL42L6
