Router Mills • END MILLS
113

Single Flute Solid Carbide Routers
For Aluminum Or Plastic

Single flute geometry avoids chip
melting and chip rewelding problems
Sfp StyLE
SFa STyle SFP STyle BeNeFITS: APPLICATIONS:

alUmInUm PlaSTIC • Optimized rake and clearance angles • Solid carbide routers designed for
Shank FlUTe oveRall oRDeR PRICe oRDeR PRICe produce highest material removal high speed machining of aluminum
SIze
DIameTeR lengTh lengTh # eaCh # eaCh rates and improved surface finishes. and non-ferrous materials or plastic
1/16" 1/8" 1/4" 1-1/2" 21-101-200 $27.63 21-101-300 $27.63 SFA Style and non-ferrous applications.
1/8 1/8 1/4 1-1/2 21-101-201 24.40 21-101-301 24.40 • For use on aluminum, has a higher
1/8 1/8 1/2 1-1/2 21-101-202 24.40 21-101-302 24.40 rake angle with clearance for superior FeATureS:
3/16 3/16 1/2 2 21-101-203 26.96 21-101-303 26.96 shearing action for aluminum alloys. • Specific helix angle for aluminum or
3/16 3/16 5/8 2 21-101-204 26.96 21-101-304 26.96 • The corner radius allows for ease of plastic materials.
1/16 1/4 1/4 2 21-101-205 32.49 21-101-305 32.49 machining and better finish as well as SFA Style
1/8 1/4 1/4 2 21-101-206 28.42 21-101-306 28.42 the wide open “zero” flute designs for • Corner radius often preferred to
1/8 1/4 1/2 2 21-101-207 28.42 21-101-307 28.42 prolong tool life in high speed
5/32 1/4 5/8 2 21-101-208 28.42 21-101-308 28.42 added room for chip flow ejection. cutting of aluminum.
3/16 1/4 1/2 2 21-101-209 28.42 21-101-309 28.42 SFP Style SFP Style
3/16 1/4 5/8 2 21-101-210 28.42 21-101-310 28.42 • For use on plastics and composites, • Features a sharp cutting edge.
7/32 1/4 3/4 2-1/2 21-101-211 28.42 — — has a sharp point and radial cutting
1/4 1/4 3/8 2-1/2 21-101-212 28.42 21-101-312 28.42 on the ends and sides for a superior
1/4 1/4 3/4 2-1/2 21-101-213 28.42 21-101-313 28.42 cutting edge and tool strength.
1/4 1/4 1-1/4 3 21-101-214 32.02 21-101-314 32.02 • The parabolic flute design assists in ToleRanCeS:
3/8 3/8 1-1/8 3 21-101-215 42.57 21-101-315 42.57 managing the chip flow of hard to Shank Diameter: -.0001" / -.0003"
1/2 1/2 1 3 21-101-216 70.52 21-101-316 70.52 machine materials. Cutter Diameter: +.000" / -.002"
1/2 1/2 1-1/2 3 21-101-217 74.18 21-101-317 74.18 TIR Maximum: .0005"
2 Flute Solid Carbide Upcut & Downcut Spiral Routers
For Hard Plastics & Aluminum • 30° Helix

Increased production
with longer tool life
APPLICATIONS: FeATureS:
• Routing hard plastics and aluminum. • Specifically engineered
geometries for routing hard UpcUt SpIraL
plastics and aluminum.
FlUTe Shank oveRall oRDeR PRICe Upcut Spiral
SIze
lengTh DIameTeR lengTh # eaCh • Pushes chips up and
UPCUT SPIRal provides good bottom finish.
1/4" 3/4" 1/4" 2-1/2" 20-542-025 $21.99 Downcut Spiral
3/8 7/8 3/8 2-1/2 20-542-030 36.50 • Pushes chips down and DowNcUt SpIraL
1/2 1 1/2 3 20-542-035 60.29 provides good top finish.
DownCUT SPIRal
1/4" 3/4" 1/4" 2-1/2" 20-542-050 $21.99
3/8 7/8 3/8 2-1/2 20-542-055 36.50 ToleRanCeS:
1/2 1 1/2 3 20-542-060 64.06 Cutting Diameter: +.000" / -.003"
4 Piece Carbide Burr Set In nylon Pouch
1/8" & 1/4" Shanks • Double Cut

Popular sizes for your common applications
in protective nylon pouch
BeNeFITS: FeATureS: INCLudeS:
• Blue nylon pouch for protection and Double Cut • (1) Each of shapes: SA-43, SB-1,
easy storage in toolbox. • Addition of the left hand flutes reduces SD-42, SF-1
the pulling action, allowing better • (1) Nylon pouch.
APPLICATIONS: operator control.
• Used in hand held grinders for • Reduces the size of the chips & can be
burr removal. used at lower than normal speeds.
• Cylindrical-square end (not end cut &
with end cut), ball, tree-radius end.
• Double cut allows for rapid stock
removal in harder materials.

oRDeR PRICe
# eaCh
20-022-800 $44.28 Sa-43 SB-1 SD-42 Sf-1
