END MILLS • Router Mills
112

Solid Carbide Diamond Cut Routers
Fish Tail Or Drill Point End Styles

Precision dimensional consistency for
CNC or hand held routing applications

[SERiES 2120]
FiSh tail Style FLuTe oveRaLL Shank enD oRDeR PRiCe
Size
LengTh LengTh DiaMeTeR STyLe # eaCh
1/32" .255" 1-1/2" 1/8" Fish Tail 20-517-300 $7.77
1/32 .255 1-1/2 1/8 Drill Point 20-517-301 7.77
Drill Point Style 3/64 .255 1-1/2 1/8 Fish Tail 20-517-302 7.77
3/64 .255 1-1/2 1/8 Drill Point 20-517-303 7.77
APPLICATIONS: FeATureS: 1/16 .255 1-1/2 1/8 Fish Tail 20-517-304 7.77
• Routing fiberglass, wood or • Sub micron grade carbide. 1/16 .255 1-1/2 1/8 Drill Point 20-517-305 7.77
composite materials. • Diamond cut fluting geometry for 3/32 .395 1-1/2 1/8 Fish Tail 20-517-306 7.77
Drill Point End Style maximum chip removal. 3/32 .395 1-1/2 1/8 Drill Point 20-517-307 7.77
• For routing applications with 1/8 .500 1-1/2 1/8 Fish Tail 20-517-308 7.77
plunging requirements. 1/8 .500 1-1/2 1/8 Drill Point 20-517-309 7.77
Fish Tail End Style 3/16 .625 2 3/16 Fish Tail 20-517-310 13.06
• For side routing applications with 3/16 .625 2 3/16 Drill Point 20-517-311 13.06
controlled depth priority. 1/4 .750 2 2 1/4 Fish Tail 20-517-312 14.91
1/4
Drill Point
20-517-313
14.91
.750
1/4
1/4 .750 2-1/2 1/4 Fish Tail 20-517-314 16.41
ToLeRanCeS: 1/4 .750 2-1/2 1/4 Drill Point 20-517-315 16.41
Diameter: +0.000" / -0.001" 1/4 1.000 3 1/4 Fish Tail 20-517-316 19.68
Flute Length: ±0.004" 1/4 1.000 3 1/4 Drill Point 20-517-317 19.68
2 Flute Solid Carbide Single end Router Mills
Straight Flute • Straight Shank • End Cutting • Right Hand Cut • 0° Helix
[SERiES 1540]
FLuTe
Shank
APPLICATIONS: Size DiaMeTeR LengTh oveRaLL oRDeR PRiCe
#
eaCh
LengTh
• Full eccentric relief for routing the full range of free machining metals & 1/8" 1/8" 1/2" 1-1/2" 20-540-008 $17.88
abrasive non-metallic materials such as plastics, epoxy fiberglass, Bakelite, 3/16 3/16 5/8 2 20-540-012 21.42
die castings, copper, aluminum, brass, bronze, hard rubber and hard wood. 1/4 1/4 3/4 2-1/2 20-540-016 26.47
5/16 5/16 13/16 2-1/2 20-540-020 29.31
ToLeRanCeS: 3/8 3/8 7/8 2-1/2 20-540-024 57.55
Cutter Diameter: +.000" / - .003" 7/16 7/16 1 2-3/4 20-540-028 78.54
Shank Diameter: +.0000" / - .0005" 1/2 1/2 1 3 20-540-032 78.81
2 Flute Solid Carbide Left Spiral Router Mills
Straight Shank • Left Hand Spiral (Down Cut) Profiling (Not End Cutting) • Right Hand Cut

APPLICATIONS: FeATureS:
• For general purpose profile routing. • Left hand spiral flutes hold work down.
• For brass, bronze, manganese bronze
and hard rubber. [SERiES 1541]
Shank
FLuTe
Size DiaMeTeR LengTh oveRaLL oRDeR PRiCe
#
eaCh
LengTh
ToLeRanCeS: 3/8" 3/8" 7/8" 2-1/2" 20-541-024 $25.90
Cutter Diameter: +.000" / - .003" 7/16 7/16 1 2-3/4 20-541-028 37.49
Shank Diameter: +.0000" / - .0005" ♦ Limited Supply. 1/2 1/2 1 3 20-541-032 46.27
