Ball, 4 Flute • END MILLS
111

4 Flute Solid Carbide Spherical Ball End alTin Coated Single End Mills
220° Arc • Center Cutting

High
performance

BeNeFITS: FeATureS:
• AlTiN coated for increased tool life. • Made from premium submicron grain carbide.
• Neck diameter reduced for clearance.
APPLICATIONS: • Long reach tools available for deep milling applications.
• Used for high temperature cutting on
mold steels, such
as titanium and nickel alloys.
• For small depth of cut and high speed
& dry machining.

Shank FLUTE ovERaLL oRDER PRiCE
SizE
DiaMETER LEngTh LEngTh # EaCh
1/8" 1/8" 3/32" 1-1/2" 20-606-200 $18.15
3/16 3/16 9/64 2 20-606-201 22.95
1/4 1/4 3/16 2-1/2 20-606-202 33.18
3/8 3/8 9/32 2-1/2 20-606-203 47.60 2 Flute & Long Lengths ToLERanCES:
1/2 1/2 3/8 3 20-606-204 70.52 Available, Please Call Cutting Diameter: +.000" / -.002"
4 Flute Ball End Long Reach Undercut Shank Micrograin
Solid Carbide Single End Mills
Center Cutting • Right Hand • 30° Helix

The solid neck area provides
reach with maximum rigidity

APPLICATIONS:
• Designed especially for the moldmaking industry.
• For milling deep pockets or slots where long flute lengths are not needed.
FeATureS:
• Neck diameter reduced by .020" for clearance.
• 10% cobalt micrograin carbide. ToLERanCES:
Shank Diameter: -.0001" / -.0004"
Mill Diameter: +.000" / -.002"

Shank LEngTh ovERaLL nECk oRDER PRiCE Shank LEngTh ovERaLL nECk oRDER PRiCE
SizE SizE
DiaMETER oF CUT LEngTh LEngTh # EaCh DiaMETER oF CUT LEngTh LEngTh # EaCh
1/8" 1/8" 5/8" 2" 3/8" 20-606-125 $16.64 7/16" 7/16" 1" 4" 1-1/4" 20-606-143 $72.34
3/16 3/16 1 3 5/8 20-606-127 28.84 7/16 7/16 1-1/2 6 2-3/4 20-606-145 94.03
3/16 3/16 1 4 1-5/8 20-606-129 31.17 1/2 1/2 1 4 1 20-606-147 73.49
1/4 1/4 1 4 1-1/4 20-606-131 35.26 1/2 1/2 1-1/2 6 2-1/2 20-606-149 103.03
1/4 1/4 1-1/2 6 2-3/4 20-606-133 45.81 9/16 9/16 2 6 1-3/4 20-606-151 130.25
5/16 5/16 1 4 1-5/16 20-606-135 46.83 5/8 5/8 2 6 1-3/4 20-606-153 137.27
5/16 5/16 1-1/2 6 2-13/16 20-606-137 69.44 3/4 3/4 2 6 1-1/2 20-606-155 227.09
3/8 3/8 1 4 1-3/8 20-606-139 51.41 1 1 2 6 1-1/2 20-606-157 386.38
3/8 3/8 1-1/2 6 2-7/8 20-606-141 71.85
