Combined Drills & Countersinks • DRILLS
191

5 Piece Plain Type High Speed Steel Combined Drill & Countersink Set
Center Drills • 60° Included Angle

The world's most concentric
center drills for the best accuracy!
BeneFIts: aPPlIcatIOns: Features:
• Run faster and true. • Used when producing a center hole • CNC ground spiral flutes.
• Superior coolant flow and chip removal. on a workpiece for turning and
cylindrical grinding. Includes:
MoDel orDer PriCe • High speed steel provides wear • (1) Piece each of sizes:
#1, #2, #3, #4 & #5
# # eaCH resistance in mild steel and CNC GRouND
S115 01-091-020 $33.82 non-ferrous materials. • Fitted plastic case. SpIRaL FLuteS
14 Piece High Speed Steel Plain Type High Speed Steel Combined
Combined Drill & Countersink Set Drill & Countersink Set
60° Included Angle • Center Drills • Right Hand 60° Included Angle • Center Drills •
Right Hand
Features:
• High speed steel provides good wear resistance With classic
in mild steels and non-ferrous materials. wooden container
• Case not included.
Includes: Includes:
• (3) Each of sizes: #1, #2, #3 & #4 • (1) Each of sizes: #1, #2, #3, #4 & 5 plain type
• (2) Each of size: #5 • Strong wooden round box with threaded
screw top.
orDer PriCe MoDel orDer PriCe
# Per SeT # # Per SeT
01-091-014 $30.59 10000 01-095-000 $46.85
Bulge Type High Speed Steel Combined Drills & Countersinks & Set
Center Drills • 60° Angle
BeneFIts:
• Tighter tolerance tools last longer
and offer more consistency.
• Bulge design reinforces the point,
PoinT
BoDy
Size DiaMeTer DiaMeTer overall orDer PriCe increases chip removal and allows
lengTH
#
eaCH
for maximum lubrication.
#1 1/8" 3/64" 1-1/4" 01-090-551 $6.20
2 3/16 5/64 1-7/8 01-090-552 6.36 Features:
3 1/4 7/64 2 01-090-553 6.70 • Entirely ground spiral flutes.
4 5/16 1/8 2 01-090-554 7.04
5 7/16 3/16 2-3/4 01-090-555 11.02 ToleranCeS:
6 1/2 7/32 3 01-090-556 16.32 Body Diameter: +.0000" / -.0006"
7 5/8 1/4 3-1/4 01-090-557 23.94 Point Diameter: -.0000" / +.004"
8 3/4 5/16 3-1/2 01-090-558 37.20 Overall Length: +.040" / -.040"
5 piece Set Includes: (1) Each of #1, #2, #3, #4, #5 & 01-090-502 40.94 60° Tolerance: +.00' / -30' (0.5°)
plastic storage case 118° Tolerance: ±2°
4 & 5 Piece Plain Type Drill & Countersink Sets
High Speed Steel • Cobalt • 60° Included Angle • Center Drills • Right Hand
Supplied in a plastic
pouch for tool protection
aPPlIcatIOns:
• Produces countersunk drilled holes.
• Used when producing a center hole on a
workpiece for turning & cylindrical grinding.
High Speed Steel
• Provides good wear resistance in mild
steels and non-ferrous materials.
Cobalt
• For tougher materials and great 4 pIeCe HIGH SpeeD SteeL Set 4 pIeCe CobaLt Set 5 pIeCe HIGH SpeeD SteeL Set 5 pIeCe CobaLt Set
wear resistance. HigH SPeeD STeel CoBalT
PriCe
PriCe
DeSCriPTion orDer Per SeT orDer Per SeT
#
#
4 piece Set: (1) Each of sizes #1 to #4 01-091-204 $8.81 01-091-214 $25.19
5 piece Set: (1) Each of sizes #1 to #5 01-091-205 12.59 01-091-215 37.79
