DRILLS • Combined Drills & Countersinks
192
192
Long Series Combined Drills & Countersinks
Center Drills • High Speed Steel Or M42 Cobalt • 60° Included Angle • Double End • Right Hand

Benefits: APPLiCAtiOns:
• Cobalt tools provide greater tool life due to the heat resistance of • Long length provides extra
the M42 material as compared to high speed steel. reach over a conventional tool.
keo high speed steel T&O • Great for 60° live centers.
• The industry best total runout for extreme accuracy at a

fantastic price.
82° & 90° Also Available In

12 Pack Quantity, Please Call
• Better grind, exceptional finish and smoother edges. FOR STAINLESS
FOR STEEL FOR STEEL

HIGH SPEED STEEL HIGH SPEED STEEL HIGH SPEED STEEL M42 COBALT

[A195L] [A195L-60] [A195L-60C]
BODy POInT OvErALL OrDEr PrICE OvErALL OrDEr PrICE OvErALL OrDEr PrICE OvErALL OrDEr PrICE
SIzE
DIAMETEr DIAMETEr LEnGTH # EACH LEnGTH # EACH LEnGTH # EACH LEnGTH # EACH
1A 1/8" 3/64" 3" 01-093-005 $7.29 3" 01-094-605 $10.62 3" 01-095-070 $12.49 3" 01-095-700 $37.52
1B 1/8 3/64 4 01-093-010 7.62 4" 01-094-610 11.09 4 01-095-071 13.05 4 01-095-701 38.80
1C 1/8 3/64 5 01-093-011 7.79 — — — 5 01-095-072 18.12 — — —
1D 1/8 3/64 6 01-093-012 14.53 — — — 6 01-095-073 23.73 — — —
2A 3/16 5/64 4 01-093-015 8.63 3" 01-094-615 10.76 3 01-095-074 12.66 3 01-095-704 37.63
2B 3/16 5/64 5 01-093-020 8.13 4" 01-094-620 12.15 4 01-095-075 14.29 4 01-095-705 42.53
2C 3/16 5/64 6 01-093-021 14.47 — — — 5 01-095-076 18.32 5 01-095-706 54.52
2D 3/16 5/64 — — — — — — 6 01-095-077 23.83 — — —
3A 1/4 7/64 4 01-093-025 8.75 3" 01-094-625 11.23 3 01-095-078 13.21 3 01-095-708 39.23
3B 1/4 7/64 5 01-093-030 11.28 4" 01-094-630 12.80 4 01-095-079 15.06 4 01-095-709 44.71
3C 1/4 7/64 6 01-093-031 14.69 5" 01-094-631 16.84 5 01-095-080 19.81 — — —
3D 1/4 7/64 — — — — — — 6 01-095-081 24.05 6 01-095-711 71.54
4A 5/16 1/8 4 01-093-035 10.21 3" 01-094-635 13.18 3 01-095-082 15.51 3 01-095-712 46.08
4B 5/16 1/8 5 01-093-040 12.67 — — — 4 01-095-083 16.69 4 01-095-713 49.67
4C 5/16 1/8 6 01-093-045 14.81 5" 01-094-645 18.14 5 01-095-084 21.34 — — —
4D 5/16 1/8 — — — — — — 6 01-095-085 24.64 6 01-095-715 73.27
4-1/2A 3/8 9/64 4 01-093-046 13.01 — — — 4 01-095-086 18.76 — — —
4-1/2B 3/8 9/64 5 01-093-047 14.76 5" 01-094-647 18.85 5 01-095-087 22.18 5 01-095-717 64.71
4-1/2C 3/8 9/64 6 01-093-048 17.59 6" 01-094-648 22.74 6 01-095-088 26.75 6 01-095-718 78.10
5A 7/16 3/16 — — — — — — 4 01-095-089 21.92 4 01-095-719 64.01
5B 7/16 3/16 5 01-093-050 15.15 5" 01-094-650 21.59 5 01-095-090 25.40 5 01-095-720 74.09
5C 7/16 3/16 6 01-093-055 17.11 6" 01-094-655 24.23 6 01-095-091 28.51 6 01-095-721 83.15
6A 1/2 7/32 5 01-093-060 13.46 — — — 4 01-095-092 23.79 4 01-095-722 67.96
6B 1/2 7/32 6 01-093-065 16.61 — — — 5 01-095-093 27.29 — — —
6C 1/2 7/32 — — — — — — 6 01-095-094 32.98 — — —
7A 5/8 1/4 6 01-093-070 35.84 — — — 6 01-095-095 61.45 — — —
8A 3/4 5/16 6 01-093-075 39.10 — — — 6 01-095-096 66.36 6 01-095-726 188.81
High Speed Steel Plain Type Long Length Combined Drills & Countersink Set
60° Included Angle • Center Drills • Right Hand
Supplied with plastic
pouch for tool protection

APPLiCAtiOns: inCLudes:
• Produces countersunk drilled holes. • (1) Each of sizes #1 to #5.
• Used when producing a center hole on a
workpiece for turning and cylindrical grinding.
• High speed steel provides good wear resistance
in mild steels and non-ferrous materials. OrDEr PrICE
• Long length provides extra reach over a # PEr SET
conventional tool. 01-093-500 $49.29
Left Hand Plain Type Combined Drills And Countersinks

Center Drills • 60° Included Angle • High Speed Steel

[A18-LH]
BODy DrILL OvErALL OrDEr PrICE
SIzE
DIAMETEr DIAMETEr LEnGTH # EACH
#1 1/8" 3/64" 1-1/4" 01-091-101 $11.03
#2 3/16 5/64 1-7/8 01-091-102 11.27
APPLiCAtiOns: #3 1/4 7/64 2 01-091-103 11.57
• Used when producing a center hole on a workpiece for turning #4 5/16 1/8 2-1/8 01-091-104 11.91
& cylindrical grinding. #4-1/2 3/8 9/64 2-1/2 01-091-109 16.65
• High speed steel provides good wear resistance in mild steels #5 7/16 3/16 2-3/4 01-091-105 18.11
& non-ferrous materials. #6 1/2 7/32 3 3-1/4 01-091-106 26.29
01-091-107
36.50
1/4
#7
5/8
