ALORIS ADJUSTABLE-SHANK TOOL HOLDERS

FOR LEFT OR RIGHT HAND TURNING, FACING OR CHAMFERING.

Two-way adjustable rake The adjustable shank feature introduces added flexibility — turning the shank
with 5° cutting angle — Crt. 90° permits choice of shank and cutting tool alignment. The cartridge, with its
positive stop cradle 12 indexing positions at 15° intervals, provides for many angular turning
lock operations. See page 10 for cartridge details.
screw
The two-way adjustable rake provides for right or left hand turning, facing and
chamfering. Rake has 5° cutting angle with positive stop. Adjustment is made by
loosening cradle lock screw and selecting desired setting.

Pin

ILLUSTRATIONS SHOW WHAT ONE
Cartridge Cartridge SINGLE TOOL CAN ACCOMPLISH
lock screw cradle
Tool
Standard steel
carbide cartridge
insert

Standard triangular
carbide insert has
6 cutting edges.
CARTRIDGE has 12 indexing
positions at 15° intervals. This
PICTORIAL DIAGRAM means many angular turning
OF CARTRIDGE and chamfering jobs can be
done faster and easier.
Exclusive positive lock with Tool Steel Cartridge adjuster
2-way force holding insert every 15° for right or left hand
down and tight against turning facing or chamfering.
shoulder. 12 positive lock positions.

ORDERING INFORMATION REPLACEMENT PARTS
HOLDER DIMENSIONS CARTRIDGE HEX LOCKING PIN LOCKING SCREW CRADLES
ORDER # PRICE EA. A B C D H H 1 ORDER # PRICE EA. ORDER # PRICE EA. ORDER # PRICE EA. ORDER # PRICE EA.
7
AT-32 $184.80 4" 1" 3 /4 4/8 7 /8 3 /4 CRT-20* $60.00 LP-20* $12.50 LS-20* $14.50 CC-20S* $67.00
1
AT-40 $217.80 4 /2 1/4 1" 5 /16 1/16 15 /16 CRT-30* $80.00 LP-30* $14.75 LS-30* $16.50 CC-30S* $71.00
11
1
1
CARBIDE INSERTS FOR ALORIS ADJUSTABLE-SHANK TOOL HOLDERS

STYLE TNMG
5° NEGATIVE HOLDER # CARTRIDGE # DIMENSIONS INSERT GRADE
I.C. T R ORDER # A2/ A6 767
TNMG-332 $7.94 $11.82
AT-32 CRT-20 3 /8 3 /16 1 /32 TNMP-332 $8.54 $12.35
STYLE TNMP TNMS-332 $8.58 $12.52
5° POSITIVE
DIMENSIONS INSERT GRADE
HOLDER # CARTRIDGE #
I.C. T R ORDER # A2/ A6 767
TNMG-432 $12.13 $17.19
AT-40 CRT-30 1 /2 3 /16 1 /32 TNMP-432 $10.23 $15.84
STYLE TNMS
15° POSITIVE TNMS-432 $12.75 $17.84

Inserts are priced individually, however, they must be purchased in packages of 10. 100 & up call for price.
See full selection of inserts on pages 49 – 54.
