Page 43 - Aloris Catalog

ALORIS ADJUSTABLE CHIPBREAKER BORING BARS

• Heat-treated alloy steel
• Supplied with adjustable carbide chip-breaker and carbide shim to protect the boring bar
• Accommodates standard positive rake triangular inserts
• Used for boring to square shoulder
• Can be used with open slot holders #1 and #2,
as well as heavy duty holders #4, #41, #4D,
#41D, #100, #104, #141 Chip-Breaker is adjustable for
perfect chip control

Triangular
Carbide
Insert

Buttonhead Chip-Breaker
Clamp Screw

ORDERING INFORMATION REPLACEMENT PARTS
BORING BORING BAR SIZE MIN. INSERT SIZE ADJUSTABLE CHIPBREAKER CHIPBREAKER CLAMP SCREW CARBIDE SHIM CARBIDE SHIM SCREW
BAR PRICE EA. BORE
ORDER # Square Round Length DIA. I.C. Thick ORDER # PRICE EA. ORDER # PRICE EA. ORDER # PRICE EA. ORDER # PRICE SET OF 5
CBB-1 $137.50 5 /8 3 /4 8" 1/8 3 /8 1 /8 CB-13* $25.30 SCR-1* $4.95 SM-41* $8.40 SM-41SS* $9.90
1
1
CBB-2 $154.00 7 /8 1" 12" 1/4 3 /8 1 /8 CB-13* $25.30 SCR-2* $4.95 SM-41* $8.40 SM-41SS* $9.90
1
5
CBB-3 $175.00 1/16 1/4 14" 1 /16 3 /8 1 /8 CB-13* $25.30 SCR-3* $6.60 SM-41* $8.40 SM-41SS* $9.90
1
CBB-4 $247.50 1/4 1/2 16" 1/8 1 /2 3 /16 CB-46* $27.50 SCR-12* $5.50 SM-37* $10.00 SM-37SS* $10.75
5
1
1
INSERTS FOR ADJUSTABLE CHIPBREAKER BORING BARS
DIMENSIONS INSERT GRADE
I.C. T R ORDER # A2/A6 767
3 1 1 TPG-322* $6.30 $10.30
/8 /8 /32
1 3 1 TPG-432* $9.15 $15.70
/2 /16 /32
Inserts are priced individually, however, they must be purchased in packages of 10. 100 & up call for price. See full selection of inserts on pages 49 – 54.

ALORIS REVERSIBLE BORING BARS
FOR SQUARE TOOL BITS
The Aloris boring bars are designed for 45° and 90° cutting BORING PRICE SQUARE
BAR
tool positions. Both ends of the boring bar are broached in ORDER # EA. DIA. LENGTH CUTTER
the same plane, so that either end can be BB-1 $49.50 5 10" 3
used after removing the bar from BB-2 $53.90 3 /8 12" /16
1
the holder. /4 /4
BB-3 $69.30 1" 14" 5 /16
BB-4 $99.00 1/4 16" 3 /8
1
BB-5 $147.50 1/2 22" 1 /2
1
BB-6 $211.20 2" 24" 1 /2
1
NOTE: All boring bars are supplied with screw wrench and tool bits. BB-7 $292.60 2/2 30" 5 /8
BORING BARS FOR SQ. TOOL BITS

DESIGNED IN TWO MODELS: ONE FOR 45°, OTHER FOR 90° CUTTING TOOL POSITION
BORING BAR PRICE DIA. LENGTH TOOL BIT
ORDER # EA.
FOR 90° BB-8 $41.80 3 /4 6" 1 /4
CUTTING
ANGLE BB-10 $56.10 1" 9" 5 /16
FOR 45° BB-9 $45.10 3 /4 6" 1 /4
CUTTING
ANGLE BB-11 $56.10 1" 9" 5 /16
