ALORIS AT-19 ADJUSTABLE KNURLING HOLDER

…excellent knurling, with approach adjustability, is provided with the newly
designed AT-19 knurling holder. The AT-19 is self-centering and is adjusted by
means of a conveniently located knurled knob, providing the ideal near-vertical-
axis approach angle for a wide range of stock diameters. Spindle and cross-
3 / 4"
slide pressure are minimal, thus knurling of thin wall tubing is easily performed.
3 / 4" The Aloris AT-19, which is designed for use in any standard turret tool post
2" max or other open-slot holder, is also availalbe with dovetail mounting (series 19) to
3
3
fit Aloris tool posts. Precision ground, / 4" O.D. x /8" wide, high-speed medium
diamond knurls are supplied unless otherwise specified.
4" ORDER # AT-19
PRICE – EACH $339.00

ALORIS AT-20 COMBO CNC BAR PULLER KNURLING TOOL

3
3 / 8"
…mounts into tool slot on CNC turrets easily adjustable with knurls installed
1
the range is / 8"–2". Opposing forces on knurls create little or no force on the
machine. Just remove the two knurl lock screws, replace with bar grippers and
1"
use as a heavy duty bar puller. There are no gripper springs to remove when
changing bar diameters. Just loosen the lockscrew, insert allen wrench and dial
1" to the next size, preload approximately / 8 rev., lock locking screw. Furnished
1
with 1" shank without knurls or grippers. Minimum clearance required between
3
turret and covers is 3 / 8".
ORDER # AT-20
PRICE – EACH $402.00
1 /8" min to 2" max

BAR GRIPPERS
GRIPPER ORDER # (pair) AT-20G*
PRICE – PAIR $104.40

HIGH SPEED KNURLS AD20R/AD20L/AS20/AD25R*
For #10, #19, #20 Holders: KNURL AD16R/AD16L/AS16* AD25L/AS25/ACD20R/ACD20L* AD50R/AD50L/AS50*
AD-Diamond/AS-Straight/NEW – Convex ORDER # ACD16R/ACD16L/ACS16* ACS20/ACD25R/ACD25L/ACS25* ACD50R/ACD50L/ACS50*
Hi-Cobalt (ACD-Spiral & ACS-Straight)
COARSE MEDIUM FINE
PRICE EA. 16.00 AD & AS
38.00 ACD & ACS (NEW) TiN COATED
KNURL-LOCK SCREW
ORDER # SCR-10* Used with any #10, #19 and #20 holder
PRICE EA. $7.80
