Designation system - tools
F7
Solid carbide tools - milling

MRO . V . 0839 . 0800 . L

1 2 3 4 5

1 3

Tool group Type
HPC2-SF
HPC-SF – HPC end mills
SF – end mills
SFM – mini end mills 4
CPC-SF – CPC end mills (Circle Power Cutting)
Ø d 1
HPC-SR – HPC rough milling cutters
0600 ➢ Ød1 = 6,00 mm
SR – rough milling cutters
SRS – rough and finish milling cutters
VR – ball nose milling cutters
HPC-TF – HPC torus milling cutters
TF – torus milling cutters
5
MSF – micro end mills
MVR – micro ball nose milling cutters Length
MTF – micro torus milling cutters XS – extra-short
HG-SC – high-precision finish milling cutters S – short
SC – finish milling cutters L – long
EZ – single flute milling cutters LS – long S
E – deburring cutters OL – very long
FF – chamfer milling cutters OLS – very long S
R – solid carbide milling cutters for plastics XL – extra-long
MRO – multiple milling cutters for plastics

2
Material main application
UN – universal
ST – steel
VA – stainless steel
TI – titanium
H – hardened steel
AL – aluminium
V – composite materials

Solid carbide tools / Milling
