Designation system - tools
                                                                                                                    F8
                                                                                    Solid carbide tools for milling








           Z6 . F0020A . HA                                                   SCPX215





               6                      7                       8                             9




            6                                                  8
            Number of teeth                                    Shank
                                                               HE
                                                               HA
                                                               HB
            7
            Corner radius, chamfer
             F    chamfer  1st to 4th position  size  0040 0.40 mm
                                                               9
                            5th position  angle  A  45°
                                             D   60°           Grade
                                             E   75°
                                             F   85°
             R    radius      0005    R = 0.05
                              0400    R = 4.00
             S     sharp
