Grade description
F16
Solid carbide tools for milling
SCPS240 HC-S40 ○ ●
Specification:
Grain size: submicron / 0.7 µm | Hardness: HV 1600 | Coating specification: Ti Al Zr N |
30
Coating structure: multi-layer
Recommended application:
Excellent combination of carbide and coating for the machining of nickel-base alloys.
SCPH205
HC-H05 ○ ○ ●
Specification:
Grain size: submicron / 0.7 µm | Hardness: HV 1600 | Coating specification: Ti Al Cr X N |
30
Coating structure: gradient nanostructure with doping element
Recommended application:
Good combination of carbide and coating for the machining of hard materials, dry machining
is also possible.
SCPH215 HC-H15 ○ ●
Specification:
Grain size: submicron / 0.7 µm | Hardness: HV 1600 | Coating specification: Ti Al C N |
30
Coating structure: multi-layer (stacked structure)
Recommended application:
Good combination of carbide and coating for hard machining.
