P. 568

Surface quality
   B241





           Definition of measured variables for surface
           quality

           The surface quality of milled work pieces is influenced
           through
           ○  the machine tool (condition, stability)
           ○ the milling tool (cutting edge geometry, construction)
           ○  the application data (v , v , f )
                               f  c  z
           ○ the work piece (geometry, material, clamping)



             The average roughness value R  is the arithmetical mean of the roughness profile within the entire measured length l .
                                                                                                         m
                                      a










                     R =     1 xl= m  ││
                                      ydx
                        a
                             l mx 0=

                                                                       Average roughness value R a












             Average roughness depth R  is the arithmetic mean resulting from the single roughness depths Z of five successive
                                                                                          i
                                   z
             single measured lengths.










                      R                                     Determination of the average roughness depth R  from the




      Milling / Technical information  Maximum roughness depth R max  is the largest single roughness depth Z on the measured length l .   z
                                                                           roughness profile

                                                                                          m
                                                                      i
             In order to produce an excellent surface finish with insert milling cutters, inserts with wiper facets
             are employed.
