TAC Flash Mills for plunging
TZF11 90° Steel Cast Iron Materials

Hard

For Z-feed finish milling of steels and cast irons
Plunging Face
Milling
Lf Rake angle: A.R. 0° R.R. –6°~0°

ød a øDc

b
Max. ap: .020 R
No. of Dimensions (in) Weight Mounting
Cat. No. Stock
inserts øDc ød R Lf b a (kg) details
TZF11050R  4 1.97 .866 .750 1.77 .236 .394 0.38 Pg.# 9-148
TZF11063R 6 2.48 0.72
TZF11080R 7 3.15 1.25 1.25 2.50 .315 .500 1.51 Pg# 9-148 for Ø100

Inserts

11°
r ε
B
.020
r ε
A s
9 Grades Dimensions (in)
Honing
Accuracy
Cat. No.
Coated A B s rε
AH740 AH120 .375 .375 .156 .039
DPCW11T3ZFR
Without
C
TAC Mills  
Replacement parts
No. Parts Part Cat. No.
a Clamping screw CSTB-4S
b Cartridge SDUPR09CZ-11
c Cartridge fixing screw CM4×.028×12
d Cartridge adjusting screw SSHM3-10
- Wrench T-15D
- Hex. wrench P-1.5, P-3
b
d
a
c

 : Stocked items
Most unmarked items are available on a RFQ basis, contact your sales rep for more information. : Stocked in Japan
9–134 Relating Technical Reference
pages
