Drills
L/D = 2 Machined hole diameter may change depending upon the rigidity of

the machine tool or cutting conditions.
Shank with flat
NEW

øDc øDs h6 øD Tolerance

Tool diameter (mm) Hole diameter
tolerance
R R s øDc Tolerance (mm)
L
ø0.812 - ø1.063 + 0.008 / 0 + 0.010 / 0
Dimensions (in) Max Clamping Torx
Cat. No. Stock offset Weight Applicable inserts screw driver
øDc øDs øD r rs L (Radius) (lb)
TDSU0812F-2 d 0.812 1.000 1.457 1.625 2.205 4.665 0.031 0.7 WWMU05X205R-D* CSPB-2.2 IP-7D
TDSU0875F-2 d 0.875 1.000 1.457 1.75 2.205 4.831 0.020 0.7 WWMU05X205R-D* CSPB-2.2 IP-7D
TDSU0937F-2 d 0.937 1.000 1.457 1.875 2.205 4.994 0.047 0.9 WWMU060306R-D* CSPB-2.5 IP-8D
TDSU1000F-2 d 1.000 1.000 1.457 2.000 2.205 5.161 0.026 0.9 WWMU060306R-D* CSPB-2.5 IP-8D
TDSU1062F-2 d 1.062 1.250 1.575 2.125 2.362 5.465 0.012 1.3 WWMU060306R-D* CSPB-2.5 IP-8D

Whistle notch

øDc øDs h6 øD Tolerance

Tool diameter (in) Hole diameter
R R s øDc Tolerance tolerance
(in)
L ø1.125 - ø2.000 ± 0.004 + 0.008 / - 0.004
11
Dimensions (in) Max Clamping Torx
offset
Cat. No. Stock øDc øDs øD r rs L (Radius) Weight Applicable inserts screw driver
(lb)
Drilling Tools TDSU1125-02 d 1.125 1.250 1.575 2.250 2.280 5.892 0.043 1.5 WWMU08X408R-** CSTB-3 T-9D
TDSU1187-02
1.6
2.280
1.250
2.374
6.079 0.019
1.575
T-9D
1.187
WWMU08X408R-** CSTB-3
d
TDSU1250-02
2.500
WWMU08X408R-** CSTB-3
T-9D
6.267 0.008
1.575
1.250
1.7
2.280
1.250
d
TDSU1312-02
TDSU1375-02 d 1.312 1.500 1.969 2.624 2.688 6.862 0.055 2.5 WWMU09X510R-** CSTB-4 T-15D
7.049 0.047
WWMU09X510R-** CSTB-4 T-15D
2.6
2.688
1.500
1.375
1.969
2.750
d
TDSU1437-02 d 1.437 1.500 1.969 2.874 2.688 7.237 0.027 2.8 WWMU09X510R-** CSTB-4 T-15D
TDSU1500-02 d 1.500 1.500 1.969 3.000 2.688 7.424 0.015 2.9 WWMU09X510R-** CSTB-4 T-15D
TDSU1562-02 d 1.562 1.500 1.969 3.124 2.688 7.612 0.074 3.0 WWMU11X512R-** CSTB-5 T-20D
TDSU1625-02 d 1.625 1.500 2.165 3.250 2.688 7.799 0.059 3.3 WWMU11X512R-** CSTB-5 T-20D
TDSU1687-02 d 1.687 1.500 2.165 3.374 2.688 7.987 0.051 3.5 WWMU11X512R-** CSTB-5 T-20D
TDSU1750-02 d 1.750 1.500 2.165 3.500 2.688 8.174 0.027 3.7 WWMU11X512R-** CSTB-5 T-20D
TDSU1812-02 d 1.812 1.500 2.165 3.624 2.688 8.362 0.015 3.9 WWMU11X512R-** CSTB-5 T-20D
TDSU1875-02 d 1.875 1.500 2.165 3.750 2.688 8.549 0.094 4.2 WWMU13X512R-** CSTB-5 T-20D
TDSU1937-02 d 1.937 1.500 2.165 3.874 2.688 8.737 0.078 4.3 WWMU13X512R-** CSTB-5 T-20D
TDSU2000-02 d 2.000 1.500 2.165 4.000 2.688 8.924 0.067 4.6 WWMU13X512R-** CSTB-5 T-20D
● : Stocked items
11–24 Relating Cutting Conditions Technical reference
pages
(14-1)
(11-14 )
