Parobolic Jobbers • DRILLS
153

M35 Cobalt Parabolic Jobbers Length Twist Drills (Cont.)
130° Split Point • Right Hand • DIN 338 • Bright Finish • Uncoated & TiAlN Coated

QuanTiTy Breaks:
Deduct 10% when buying 10 pieces
or more of same size.

BeNefITS: APPLICATIONS:
• Fast chip removal and reduced heat TiAlN
generation at the point. • For high speed & dry machining of cast UncoateD
iron, stainless steels, nickel based high
temperature alloys and titanium alloys.
♦ See Page 152 For Tolerances & Additional Information. TiAln coateD

For NoN-Ferrous For NoN-Ferrous
For Plastic For steel For Plastic For steel
FraCTiOnaL sizes unCOaTeD Tialn COaTeD FraCTiOnaL sizes unCOaTeD Tialn COaTeD
DeCiMaL FLuTe OveraLL OrDer PriCe OrDer PriCe DeCiMaL FLuTe OveraLL OrDer PriCe OrDer PriCe
size size
DiaMeTer LengTH LengTH # eaCH # eaCH DiaMeTer LengTH LengTH # eaCH # eaCH
3/64" .0469" .630" 1.496" 01-060-003 $3.16 01-065-003 $4.02 9/32" .2811" 2.717" 4.291" 01-060-018 $10.67 01-065-018* $21.36
1/16 .0626 .787 1.693 01-060-004 3.91 01-065-004 5.29 19/64 .2969 2.953 4.606 01-060-019* 12.50 01-065-019* 25.37
5/64 .0781 .945 1.929 01-060-005* 4.09 01-065-005 5.53 5/16 .3126 2.953 4.606 01-060-020 12.80 01-065-020 23.20
3/32 .0937 1.181 2.244 01-060-006 4.27 01-065-006 4.29 21/64 .3281 2.953 4.606 01-060-021* 12.89 01-065-021* 21.12
7/64 .1094 1.299 2.402 01-060-007 4.67 01-065-007 4.69 11/32 .3437 3.189 4.921 01-060-022* 15.51 — —
1/8 .1248 1.417 2.559 01-060-008 4.84 01-065-008 7.44 23/64 .3594 3.189 4.921 01-060-023* 16.85 01-065-023 25.33
9/64 .1406 1.535 2.756 01-060-009 5.51 01-065-009 6.38 3/8 .3748 3.425 5.236 01-060-024 18.84 01-065-024* 26.88
5/32 .1563 1.693 2.953 01-060-010 5.78 01-065-010 8.38 25/64 .3906 3.425 5.236 01-060-025* 18.55 01-065-025 27.04
11/64 .1719 1.850 3.150 01-060-011* 6.27 01-065-011* 6.29 13/32 .4063 3.425 5.236 01-060-026* 20.66 01-065-026* 30.93
3/16 .1874 2.047 3.386 01-060-012 6.87 01-065-012 9.47 27/64 .4219 3.701 5.591 01-060-027* 22.18 01-065-027 35.40
13/64 .2031 2.047 3.386 01-060-013* 6.89 01-065-013 10.42 7/16 .4374 3.701 5.591 01-060-028* 22.64 01-065-028 29.36
7/32 .2189 2.244 3.661 01-060-014* 8.16 — — 29/64 .4531 3.701 5.591 01-060-029* 24.29 01-065-029 37.53
15/64 .2343 2.244 3.661 01-060-015* 8.62 01-065-015 13.91 15/32 .4689 3.976 5.945 01-060-030* 26.31 01-065-030* 32.74
1/4 .2500 2.480 3.976 01-060-016 9.29 — — 31/64 .4843 3.976 5.945 01-060-031* 32.36 01-065-031* 42.00
17/64 .2657 2.717 4.291 01-060-017 10.67 01-065-017* 20.86 1/2 .5000 3.976 5.945 01-060-032 33.16 01-065-032 33.27
*Limited Supply.
High speed steel Jobbers Length Bright Finish Twist Drills
118° Drill Point • DIN 338 • Ground From The Solid • Right Hand • 30° Helix

QuanTiTy Breaks:
Package Quantity: Less 10%
Bright finish drills help increase
chip flow in soft materials

QuanTiTy Per PaCkage APPLICATIONS:
size QuanTiTy • For drilling metric holes in a wide
0.50mm to 7.0mm 12 range of materials.
8.0mm to 12.5mm 6
13.0mm to 13.3mm 3
Prices shown are per drill.
DeCiMaL FLuTe OveraLL OrDer PriCe DeCiMaL FLuTe OveraLL OrDer PriCe
size size
eQuivaLenT LengTH LengTH # eaCH eQuivaLenT LengTH LengTH # eaCH
.50mm 0.020" 6mm 22mm 01-042-105 $1.97 4.0mm 0.148" 43mm 75mm 01-042-210 $.99
.70mm 0.030" 9mm 28mm 01-042-110 1.97 4.20mm 0.157" 43mm 75mm 01-042-215 1.10
.75mm 0.130" 9mm 28mm 01-042-115 1.50 4.50mm 0.165" 47mm 80mm 01-042-220 1.15
.80mm 0.260" 10mm 30mm 01-042-120 1.39 5.00mm 0.177" 52mm 86mm 01-042-225 1.33
.85mm 0.028" 10mm 30mm 01-042-125 1.39 5.50mm 0.197" 57mm 93mm 01-042-230 1.61
1.0mm 0.031" 12mm 34mm 01-042-130 .87 6.0mm 0.217" 57mm 93mm 01-042-235 1.80
1.10mm 0.033" 14mm 36mm 01-042-135 .87 6.40mm 0.236" 63mm 101mm 01-042-240 1.97
1.20mm 0.039" 16mm 38mm 01-042-140 .87 6.50mm 0.252" 63mm 101mm 01-042-245 1.97
1.45mm 0.043" 18mm 40mm 01-042-145 .87 6.60mm 0.256" 63mm 101mm 01-042-250 2.32
1.50mm 0.047" 18mm 40mm 01-042-150 .87 6.70mm 0.264" 63mm 101mm 01-042-255 2.32
1.85mm 0.057" 22mm 46mm 01-042-155 .87 7.0mm 0.276" 69mm 109mm 01-042-260 2.32
2.0mm 0.059" 24mm 49mm 01-042-160 .87 8.0mm 0.315" 75mm 117mm 01-042-265 3.01
2.20mm 0.073" 27mm 53mm 01-042-165 .87 8.5mm 0.335" 75mm 117mm 01-042-270 3.36
2.30mm 0.079" 27mm 53mm 01-042-170 .87 9.0mm 0.354" 81mm 125mm 01-042-275 3.93
2.35mm 0.087" 27mm 53mm 01-042-175 .92 10.0mm 0.394" 87mm 133mm 01-042-280 5.49
2.5mm 0.091" 30mm 57mm 01-042-180 .87 10.50mm 0.413" 87mm 133mm 01-042-285 5.67
3.0mm 0.093" 33mm 61mm 01-042-185 .87 12.00mm 0.472" 101mm 151mm 01-042-290 8.15
3.25mm 0.098" 36mm 65mm 01-042-190 .99 12.50mm 0.492" 101mm 151mm 01-042-295 8.42
3.30mm 0.118" 36mm 65mm 01-042-195 .99 13.00mm 0.512" 101mm 151mm 01-042-300 10.19
3.50mm 0.128" 39mm 70mm 01-042-200 .92 13.30mm 0.524" 108mm 160mm 01-042-305 12.84
3.75mm 0.138" 39mm 70mm 01-042-205 1.04
