DRILLS • Screw Machine
162

Heavy Duty High Speed Steel Screw Machine Drills
135° Split Point • Bright Finish Or TiN Coated

Quantity BreakS:
BrigHt FiniSH
Bright Finish Package Quantity: Less 10%
60+ Pieces: Less 15%
tin cOateD
Package Quantity: Less 10%
30+ Pieces: Less 15%
tin Coated
BrigHt FiniSH tin cOateD
tyPe 260-tW tyPe 260-tn
Benefits: APPLiCAtiOns: DeciMal Flute Overall OrDer Price OrDer Price
• Accurate centering. • Ideal for drilling thin metal work. Size eQuivalent lengtH lengtH # eacH # eacH
• Fast penetration. Bright Finish Type 260-TW nuMBer SizeS
• For non-ferrous materials such as: #1 .2280" 1-5/16" 2-7/16" 01-914-101 $2.26 01-914-301 $5.01
aluminum, copper, brass, zinc, copper, #2 .2210" 1-5/16" 2-7/16" 01-914-102 2.26 01-914-302 5.01
titanium wood & plastics #3 .2130" 1-1/4" 2-3/8" 01-914-103 2.12 01-914-303 4.85
TiN Coated Type 260-TN #4 .2090" 1-1/4" 2-3/8" 01-914-104 2.12 01-914-304 4.85
• For all ferrous materials including #5 .2055" 1-1/4" 2-3/8" 01-914-105 2.12 01-914-305 4.85
carbon and or iron: steels and #6 .2040" 1-1/4" 2-3/8" 01-914-106 2.12 01-914-306 4.85
stainless steel. #7 .2010" 1-3/16" 2-1/4" 01-914-107 1.83 01-914-307 4.58
#8 .1990" 1-3/16" 2-1/4" 01-914-108 1.83 01-914-308 4.58
feAtures: #9 .1960" 1-3/16" 2-1/4" 01-914-109 1.83 01-914-309 4.58
• Right hand drills. #10 .1935" 1-3/16" 2-1/4" 01-914-110 1.83 01-914-310 4.58
#11 .1910" 1-3/16" 2-1/4" 01-914-111 1.83 01-914-311 4.58
#12 .1890" 1-3/16" 2-1/4" 01-914-112 1.83 01-914-312 4.58
#13 .1850" 1-1/8" 2-3/16" 01-914-113 1.83 01-914-313 3.59
Quantity Per Package #14 .1820" 1-1/8" 2-3/16" 01-914-114 1.83 01-914-314 3.59
Size Quantity #15 .1800" 1-1/8" 2-3/16" 01-914-115 1.83 01-914-315 3.59
BrigHt FiniSH #16 .1770" 1-1/8" 2-3/16" 01-914-116 1.83 01-914-316 3.59
1/16" thru 9/32" 12 #17 .1730" 1-1/8" 2-3/16" 01-914-117 1.83 01-914-317 3.59
19/64" thru 1/2" 6 #18 .1695" 1-1/16" 2-1/8" 01-914-118 1.53 01-914-318 3.32
#1 thru #60 12 #19 .1660" 1-1/16" 2-1/8" 01-914-119 1.53 01-914-319 3.32
tin cOateD #20 .1610" 1-1/16" 2-1/8" 01-914-120 1.53 01-914-320 3.32
1/16" thru 9/32" 6 #21 .1590" 1-1/16" 2-1/8" 01-914-121 1.46 01-914-321 3.24
19/64" thru 1/2" 3 Additional Sizes Available #22 .1570" 1-1/16" 2-1/8" 01-914-122 1.46 01-914-322 3.24
#1 thru #60 6 In Package Quantity, #23 .1540" 1" 2-1/16" 01-914-123 1.46 01-914-323 3.24
Price shown are per drill. Please Call #24 .1520" 1" 2-1/16" 01-914-124 1.46 01-914-324 3.24
#25 .1495" 1" 2-1/16" 01-914-125 1.40 01-914-325 3.24
BrigHt FiniSH tin cOateD #26 .1470" 1" 2-1/16" 01-914-126 1.40 01-914-326 3.24
#27
2-1/16"
1"
.1440"
01-914-327
3.24
01-914-127
1.40
tyPe 260-tW tyPe 260-tn #28 .1405" 15/16" 1-15/16" 01-914-128 1.31 01-914-328 3.10
DeciMal Flute Overall OrDer Price OrDer Price
Size #29 .1360" 15/16" 1-15/16" 01-914-129 1.31 01-914-329 3.10
eQuivalent lengtH lengtH # eacH # eacH #30 .1285" 15/16" 1-15/16" 01-914-130 1.31 01-914-330 3.10
FractiOnal SizeS #31 .1200" 7/8" 1-7/8" 01-914-131 1.27 01-914-331 2.66
1/16" .0625" 5/8" 1-5/8" 01-914-004 $1.26 01-914-204 $2.73 #32 .1160" 7/8" 1-7/8" 01-914-132 1.27 01-914-332 2.66
5/64" .0781" 11/16" 1-11/16" 01-914-005 1.26 01-914-205 2.73 #33 .1130" 7/8" 1-7/8" 01-914-133 1.27 01-914-333 2.66
3/32" .0938" 3/4" 1-3/4" 01-914-006 1.26 01-914-206 2.73 #34 .1110" 7/8" 1-7/8" 01-914-134 1.27 01-914-334 2.66
7/64" .1094" 13/16" 1-13/16" 01-914-007 1.26 01-914-207 2.73 #35 .1100" 7/8" 1-7/8" 01-914-135 1.27 01-914-335 2.66
1/8" .1250" 7/8" 1-7/8" 01-914-008 1.26 01-914-208 2.73 #36 .1065" 13/16" 1-13/16" 01-914-136 1.27 01-914-336 2.66
9/64" .1406" 15/16" 1-15/16" 01-914-009 1.34 01-914-209 3.11 #37 .1040" 13/16" 1-13/16" 01-914-137 1.27 01-914-337 2.66
5/32" .1562" 1" 2-1/16" 01-914-010 1.43 01-914-210 3.20 #38 .1015" 13/16" 1-13/16" 01-914-138 1.27 01-914-338 2.66
11/64" .1719" 1-1/16" 2-1/8" 01-914-011 1.55 01-914-211 3.34 #39 .0995" 13/16" 1-13/16" 01-914-139 1.27 01-914-339 2.66
3/16" .1875" 1-1/8" 2-3/16" 01-914-012 1.64 01-914-212 3.41 #40 .0980" 13/16" 1-13/16" 01-914-140 1.27 01-914-340 2.66
13/64" .2031" 1-3/16" 2-1/4" 01-914-013 1.73 01-914-213 4.49 #41 .0960" 13/16" 1-13/16" 01-914-141 1.27 01-914-341 2.66
7/32" .2188" 1-1/4" 2-3/8" 01-914-014 2.09 01-914-214 4.82 #42 .0935" 3/4" 1-3/4" 01-914-142 1.27 01-914-342 2.66
15/64" .2344" 1-5/16" 2-7/16" 01-914-015 2.10 01-914-215 4.84 #43 .0890" 3/4" 1-3/4" 01-914-143 1.27 01-914-343 2.66
1/4" .2500" 1-3/8" 2-1/2" 01-914-016 2.24 01-914-216 5.00 #44 .0860" 3/4" 1-3/4" 01-914-144 1.27 01-914-344 2.66
17/64" .2656" 1-7/16" 2-5/8" 01-914-017 2.58 01-914-217 6.94 #45 .0820" 3/4" 1-3/4" 01-914-145 1.27 01-914-345 2.66
9/32" .2812" 1-1/2" 2-11/16" 01-914-018 2.81 01-914-218 7.14 #46 .0810" 3/4" 1-3/4" 01-914-146 1.27 01-914-346 2.66
19/64" .2969" 1-9/16" 2-3/4" 01-914-019 3.00 01-914-219 7.33 #47 .0785" 3/4" 1-3/4" 01-914-147 1.27 01-914-347 2.66
5/16" .3125" 1-5/8" 2-13/16" 01-914-020 3.23 01-914-220 7.56 #48 .0760" 11/16" 1-11/16" 01-914-148 1.27 01-914-348 2.66
21/64" .3281" 1-11/16" 2-15/16" 01-914-021 3.53 01-914-221 8.72 #49 .0730" 11/16" 1-11/16" 01-914-149 1.27 01-914-349 2.66
11/32" .3438" 1-11/16" 3" 01-914-022 4.01 01-914-222 9.17 #50 .0700" 11/16" 1-11/16" 01-914-150 1.27 01-914-350 2.66
23/64" .3594" 1-3/4" 3-1/16" 01-914-023 4.63 01-914-223 9.78 #51 .0670" 11/16" 1-11/16" 01-914-151 1.27 01-914-351 2.66
3/8" .3750" 1-13/16" 3-1/8" 01-914-024 4.87 01-914-224 10.02 #52 .0635" 11/16" 1-11/16" 01-914-152 1.27 01-914-352 2.66
25/64" .3906" 1-7/8" 3-1/4" 01-914-025 5.47 01-914-225 11.46 #53 .0595" 5/8" 1-5/8" 01-914-153 1.27 01-914-353 2.66
13/32" .4062" 1-15/16" 3-5/16" 01-914-026 5.67 01-914-226 11.66 #54 .0550" 5/8" 1-5/8" 01-914-154 1.27 01-914-354 2.66
27/64" .4219" 2" 3-3/8" 01-914-027 6.23 01-914-227 12.18 #55 .0520" 5/8" 1-5/8" 01-914-155 1.27 01-914-355 2.66
7/16" .4375" 2-1/16" 3-7/16" 01-914-028 6.38 01-914-228 12.35 #56 .0465" 1/2" 1-3/8" 01-914-156 1.27 01-914-356 2.66
29/64" .4531" 2-1/8" 3-9/16" 01-914-029 7.49 01-914-229 14.29 #57 .0430" 1/2" 1-3/8" 01-914-157 1.27 01-914-357 2.66
15/32" .4688" 2-1/8" 3-5/8" 01-914-030 7.86 01-914-230 14.67 #58 .0420" 1/2" 1-3/8" 01-914-158 1.27 01-914-358 2.66
31/64" .4844" 2-3/16" 3-11/16" 01-914-031 8.17 01-914-231 14.95 #59 .0410" 1/2" 1-3/8" 01-914-159 1.27 01-914-359 2.66
1/2" .5000" 2-1/4" 3-3/4" 01-914-032 8.17 01-914-232 14.95 #60 .0400" 1/2" 1-3/8" 01-914-160 1.27 01-914-360 2.66
