H.S.S. Screw Machine • DRILLS
163

SG Coated CNC Stub Length Drills
With Common End Mill Shank

Made from cobalt powder high speed steel
with composite multi-layer SG coating

FLUTe OveraLL SHaNk OrDer PriCe FLUTe OveraLL SHaNk OrDer PriCe feAtures:
Size Size
LeNGTH LeNGTH Dia. # eaCH LeNGTH LeNGTH Dia. # eaCH • 135° 3 facet point.
3/32" 1/2" 1-3/4" 1/8" 01-047-236 $10.36 17/64" 1-3/8" 3-13/16" 3/8" 01-047-247 $25.49 • SG multi-layer coating.
#36 5/8 1-7/8 1/8 01-047-263 10.29 9/32 1-3/8 3-13/16 3/8 01-047-248 26.87 • Reduced drill cycle time.
7/64 5/8 1-7/8 1/8 01-047-237 8.21 19/64 1-3/8 3-13/16 3/8 01-047-249 30.32 • Common end mill shank
1/8 3/4 2 1/8 01-047-238 10.36 5/16 1-1/2 3-3/8 3/8 01-047-250 33.77 (fits standard collets).
#29 13/16 2-1/8 3/16 01-047-264 13.04 21/64 1-1/2 3-3/8 3/8 01-047-251 34.46 • Higher feed rates.
9/64 13/16 2-1/8 3/16 01-047-239 13.04 11/32 1-5/8 3-1/2 3/8 01-047-252 44.74
#25 13/16 2-1/8 3/16 01-047-265 13.04 3/8 1-5/8 3-1/2 3/8 01-047-254 38.61
5/32 13/16 2-1/8 3/16 01-047-240 13.73 25/64 1-11/16 3-7/8 3/8 01-047-255 42.67
3/16 1 2-3/8 3/16 01-047-242 15.88 13/32 1-11/16 3-7/8 1/2 01-047-256 42.67
#7 1-1/8 2-7/8 1/4 01-047-267 15.81 27/64 1-7/8 4-1/8 1/2 01-047-257 48.20
13/64 1-1/8 2-7/8 1/4 01-047-243 15.88 7/16 1-7/8 4-1/8 1/2 01-047-258 48.20
7/32 1-1/8 2-7/8 1/4 01-047-244 22.72 29/64 1-7/8 4-1/8 1/2 01-047-259 51.65
15/64 1-1/4 3 1/4 01-047-245 22.72 15/32 2 4-1/4 1/2 01-047-260 51.65
1/4 1-1/4 3 1/4 01-047-246 25.49 31/64 2 4-1/4 1/2 01-047-261 56.49
F 1-3/8 3-13/16 1/4 01-047-268 26.79 1/2 2 4-1/4 1/2 01-047-262 62.63
Type 260-UB Ultra Bor Super Premium High Speed Steel QUaNTiTy BreakS:
Heavy Duty Screw Machine Length Drills Package Quantity: Less 10%
60+ Pcs: Less 15%
135° Split Point • Premium Hi-Molybdenum Steel

Benefits:
Designed for series 300 stainless
steel, except for 303 • Much tougher than cobalt steel.
• Thin web design will penetrate the work
Number & Letter Sizes hardening (series 300, except for 303
Available, Please Call which is free machining) stainless steel
fast enough to continually cut beneath the
DeCiMaL FLUTe OveraLL OrDer PriCe DeCiMaL FLUTe OveraLL OrDer PriCe
Size Size chip which is hardening from deformation.
DiaMeTer LeNGTH LeNGTH # eaCH DiaMeTer LeNGTH LeNGTH # eaCH • 135° split point design stops drill walking,
1/16" .0625" 5/8" 1-5/8" 01-912-107 $1.38 19/64" .2969" 1-9/16" 2-3/4" 01-912-133 $3.23 holds tighter hole size and takes a smaller
5/64" .0781" 11/16" 1-11/16" 01-912-109 1.38 5/16" .3125" 1-5/8" 2-13/16" 01-912-135 3.52 chip resulting in less heat.
3/32" .0938" 3/4" 1-3/4" 01-912-111 1.38 21/64" .3281" 1-11/16" 2-15/16" 01-912-202 3.82
7/64" .1094" 13/16" 1-13/16" 01-912-113 1.38 11/32" .3438" 1-11/16" 3" 01-912-137 4.31 APPLiCAtiOns:
1/8" .1250" 7/8" 1-7/8" 01-912-115 1.38 23/64" .3594" 1-3/4" 3-1/16" 01-912-203 5.01 • Outperforms cobalt drills in work
9/64" .1406" 15/16" 1-15/16" 01-912-117 1.40 3/8" .3750" 1-13/16" 3-1/8" 01-912-139 5.25 hardening stainless steel applications.
5/32" .1562" 1" 2-1/16" 01-912-119 1.54 25/64" .3906" 1-7/8" 3-1/4" 01-912-204 5.91
11/64" .1719" 1-1/16" 2-1/8" 01-912-121 1.71 13/32" .4062" 1-15/16" 3-5/16" 01-912-205 6.27 feAtures:
3/16" .1875" 1-1/8" 2-3/16" 01-912-123 1.78 27/64" .4219" 2" 3-3/8" 01-912-206 6.80 • Manufactured to NAS 907C specification.
13/64" .2031" 1-3/16" 2-1/4" 01-912-125 1.89 7/16" .4375" 2-1/16" 3-7/16" 01-912-207 6.95
7/32" .2188" 1-1/4" 2-3/8" 01-912-200 2.25 29/64" .4531" 2-1/8" 3-9/16" 01-912-141 8.24 QUaNTiTy Per PaCkaGe
15/64" .2344" 1-5/16" 2-7/16" 01-912-127 2.27 15/32" .4688" 2-1/8" 3-5/8" 01-912-208 8.76 Size QUaNTiTy
1/4" .2500" 1-3/8" 2-1/2" 01-912-129 2.40 31/64" .4844" 2-3/16" 3-11/16" 01-912-209 9.02 1/16" thru 9/32" 12
17/64" .2656" 1-7/16" 2-5/8" 01-912-201 2.81 1/2" .5000" 2-1/4" 3-3/4" 01-912-143 9.02 19/64" thru 1/2" 6
9/32" .2812" 1-1/2" 2-11/16" 01-912-131 3.04 Prices shown are per drill.
