DRILLS • Cobalt Micro
166

Spirec Cobalt Micro Twist Drills
118° Point • Reinforced Metric Shank • Right Hand Cut

APPLICATIONS: FeATureS:
• For drilling a wide • 2 facet point up to size .0571".
range of normal • Helix angle: 20°
ferrous, non-ferrous • Dimensions: DIN 1899 A RN
materials and alloys. • Accuracy: +.000" / -.00015", Sold In 10 Piece Package
Micro Center Drills ±.0002" (over .0571") FOR MICRO MACHINING Quantity Only.
APPLICATIONS
Page 190 Prices Shown Are Per Drill.
Wire GaGe/ Wire GaGe/
DeCiMal Shank FluTe overall orDer PriCe DeCiMal Shank FluTe overall orDer PriCe
DiaMeTer FraCTional DiaMeTer DiaMeTer lenGTh lenGTh # eaCh DiaMeTer FraCTional DiaMeTer DiaMeTer lenGTh lenGTh # eaCh
SizeS SizeS
.0039" — .10mm 1.0mm 0.7mm 25mm 01-045-010 $16.31 .0311" 1/32" .79mm 1.0mm 6.3mm 25mm 01-045-079 $7.93
.0043 — .11 1.0 0.7 25 01-045-011* 15.58 .0315 — .80 1.5 6.3 25 01-045-080 7.93
.0047 — .12 1.0 0.7 25 01-045-012 16.31 .0319 #67 .81 1.5 6.3 25 01-045-081 7.93
.0051 — .13 1.0 1.0 25 01-045-013 13.50 .0323 — .82 1.5 6.3 25 01-045-082 7.93
.0055 — .14 1.0 1.0 25 01-045-014 13.50 .0327 — .83 1.5 6.3 25 01-045-083 7.93
.0059 #97 .15 1.0 1.0 25 01-045-015 13.50 .0331 66 .84 1.5 6.3 25 01-045-084 7.93
.0063 96 .16 1.0 1.4 25 01-045-016 13.50 .0335 — .85 1.5 6.3 25 01-045-085 7.93
.0067 95 .17 1.0 1.4 25 01-045-017* 12.89 .0339 — .86 1.5 7.1 25 01-045-086 7.93
.0071 94 .18 1.0 1.4 25 01-045-018 13.50 .0343 — .87 1.5 7.1 25 01-045-087 7.93
.0075 93 .19 1.0 1.4 25 01-045-019 13.50 .0346 — .88 1.5 7.1 25 01-045-088* 7.57
.0079 92 .20 1.0 1.8 25 01-045-020 11.29 .0350 65 .89 1.5 7.1 25 01-045-089 7.93
.0083 91 .21 1.0 1.8 25 01-045-021 11.29 .0354 — .90 1.5 7.1 25 01-045-090 7.93
.0087 90 .22 1.0 1.8 25 01-045-022 11.29 .0358 64 .91 1.5 7.1 25 01-045-091* 7.57
.0091 89 .23 1.0 1.8 25 01-045-023 11.29 .0362 — .92 1.5 7.1 25 01-045-092 7.93
.0094 88 .24 1.0 1.8 25 01-045-024* 10.77 .0370 63 .94 1.5 7.1 25 01-045-094 7.93
.0098 87 .25 1.0 2.2 25 01-045-025 11.29 .0374 — .95 1.5 7.1 25 01-045-095 7.93
.0102 86 .26 1.0 2.2 25 01-045-026 11.29 .0378 — .96 1.5 8.0 25 01-045-096 7.93
.0106 — .27 1.0 2.2 25 01-045-027* 10.77 .0382 62 .97 1.5 8.0 25 01-045-097 7.93
.0110 85 .28 1.0 2.2 25 01-045-028 11.29 .0386 — .98 1.5 8.0 25 01-045-098 7.93
.0114 84 .29 1.0 2.2 25 01-045-029 11.29 .0390 61 .99 1.5 8.0 25 01-045-099 7.93
.0118 — .30 1.0 2.2 25 01-045-030 11.29 .0394 — 1.00 1.5 8.0 25 01-045-100 7.93
.0122 83 .31 1.0 2.8 25 01-045-031 10.83 .0413 — 1.05 1.5 8.0 25 01-045-105 7.93
.0126 82 .32 1.0 2.8 25 01-045-032 10.83 .0433 — 1.10 1.5 9.0 25 01-045-110 7.93
.0130 81 .33 1.0 2.8 25 01-045-033 10.83 .0453 — 1.15 1.5 9.0 25 01-045-115 7.93
.0134 80 .34 1.0 2.8 25 01-045-034 10.83 .0472 — 1.20 1.5 10.0 25 01-045-120 7.93
.0138 — .35 1.0 2.8 25 01-045-035 10.83 .0492 — 1.25 1.5 10.0 25 01-045-125 7.93
.0142 — .36 1.0 2.8 25 01-045-036 10.83 .0512 — 1.30 1.5 10.0 25 01-045-130 7.93
.0146 79 .37 1.0 2.8 25 01-045-037 10.83 .0531 — 1.35 1.5 11.2 25 01-045-135* 7.57
.0150 — .38 1.0 2.8 25 01-045-038 10.83 .0551 — 1.40 1.5 11.2 25 01-045-140 7.93
.0154 — .39 1.0 3.6 25 01-045-039 9.45 .0571 — 1.45 1.5 11.2 25 01-045-145 7.93
.0157 1/64" .40 1.0 3.6 25 01-045-040 9.45 .0591 — 1.50 2.0 11.2 38 01-045-150 9.00
.0161 #78 .41 1.0 3.6 25 01-045-041 9.45 .0610 — 1.55 2.0 11.5 38 01-045-155 9.00
.0165 — .42 1.0 3.6 25 01-045-042 9.45 .0625 1/16" 1.5875 2.0 11.5 38 01-045-158 9.00
.0169 — .43 1.0 3.6 25 01-045-043 9.45 .0630 — 1.60 2.0 11.5 38 01-045-160 9.00
.0173 — .44 1.0 3.6 25 01-045-044 9.45 .0650 — 1.65 2.0 11.5 38 01-045-165 9.00
.0177 — .45 1.0 3.6 25 01-045-045 9.45 .0669 — 1.70 2.0 11.5 38 01-045-170 9.00
.0181 77 .46 1.0 3.6 25 01-045-046 9.45 .0689 — 1.75 2.0 11.5 38 01-045-175 9.00
.0185 — .47 1.0 3.6 25 01-045-047 9.45 .0709 — 1.80 2.0 11.5 38 01-045-180 9.00
.0189 — .48 1.0 3.6 25 01-045-048 9.45 .0728 — 1.85 2.0 12.0 38 01-045-185 9.00
.0193 — .49 1.0 4.0 25 01-045-049 8.31 .0748 — 1.90 2.0 12.0 38 01-045-190* 8.59
.0197 — .50 1.0 4.0 25 01-045-050 8.31 .0768 — 1.95 2.0 12.0 38 01-045-195 9.00
.0201 76 .51 1.0 4.0 25 01-045-051 8.31 .0781 5/64" 1.9844 2.0 13.0 38 01-045-198 9.00
.0205 — .52 1.0 4.0 25 01-045-052 8.31 .0787 — 2.00 2.5 13.0 43 01-045-200 11.14
.0209 75 .53 1.0 4.0 25 01-045-053 8.31 .0827 — 2.10 2.5 13.0 43 01-045-210* 10.63
.0220 — .56 1.0 4.5 25 01-045-056 8.31 .0846 — 2.15 2.5 13.0 43 01-045-215 11.14
.0224 74 .57 1.0 4.5 25 01-045-057 8.31 .0868 — 2.20 2.5 14.0 43 01-045-220 11.14
.0232 — .59 1.0 4.5 25 01-045-059 8.31 .0886 — 2.25 2.5 14.0 43 01-045-225 11.14
.0236 — .60 1.0 4.5 25 01-045-060 8.31 .0906 — 2.30 2.5 14.0 43 01-045-230 11.14
.0240 73 .61 1.0 5.0 25 01-045-061 8.31 .0925 — 2.35 2.5 14.0 43 01-045-235 11.14
.0244 — .62 1.0 5.0 25 01-045-062* 5.53 .0938 3/32" 2.3812 2.5 14.0 43 01-045-238 11.14
.0248 — .63 1.0 5.0 25 01-045-063 8.31 .0945 — 2.40 2.5 15.0 43 01-045-240 11.14
.0252 72 .64 1.0 5.0 25 01-045-064 8.31 .0965 — 2.45 2.5 15.0 43 01-045-245 11.14
.0256 — .65 1.0 5.0 25 01-045-065 8.31 .0995 — 2.55 3.0 16.0 46 01-045-255 13.73
.0260 71 .66 1.0 5.0 25 01-045-066 8.31 .1024 — 2.60 3.0 16.0 46 01-045-260* 13.10
.0264 — .67 1.0 5.0 25 01-045-067 8.31 .1040 — 2.65 3.0 17.0 46 01-045-265 13.73
.0268 — .68 1.0 5.6 25 01-045-068 7.93 .1063 — 2.70 3.0 17.0 46 01-045-270* 13.10
.0272 — .69 1.0 5.6 25 01-045-069 7.93 .1083 — 2.75 3.0 18.0 46 01-045-275 13.73
.0276 — .70 1.0 5.6 25 01-045-070 7.93 .1102 — 2.80 3.0 18.0 46 01-045-280 13.73
.0280 70 .71 1.0 5.6 25 01-045-071 7.93 .1122 — 2.85 3.0 19.0 46 01-045-285* 13.10
.0283 — .72 1.0 5.6 25 01-045-072 7.93 .1161 — 2.95 3.0 20.0 46 01-045-295* 13.10
.0287 — .73 1.0 5.6 25 01-045-073* 7.57 .1181 — 3.00 3.0 20.0 46 01-045-300 13.73
.0291 69 .74 1.0 5.6 25 01-045-074 7.93 .1250 1/8" 3.1750 3.1750 20.0 46 01-045-317 13.73
.0295 — .75 1.0 5.6 25 01-045-075 7.93 *Limited Supply.
.0299 — .76 1.0 6.3 25 01-045-076 7.93
.0303 — .77 1.0 6.3 25 01-045-077 7.93
.0307 — .78 1.0 6.3 25 01-045-078 7.93
