Cobalt Parabolic Screw Machine • DRILLS
165
M35 Cobalt Parabolic Screw Machine Length Twist Drills
130° Split Point • Straight Shank • Right Hand • DIN 1897 • Bright Finish

For NoN-Ferrous Easier penetration and QuanTiTy BreakS:

For Plastic For steel reduced time per hole Deduct 10% when buying 10 pieces or
unCoaTeD Tialn CoaTeD more of same size.
DeCiMaL FLuTe overaLL orDer PriCe orDer PriCe
Size
DiaMeTer LengTh LengTh # eaCh # eaCh
FraCTionaL SizeS UncoateD
3/64" .0469" .315" 1.181" 01-075-003 $3.31 01-077-003 $4.69 Benefits: APPLiCAtiOns:
1/16 .0626 .394 1.339 01-075-004 3.07 01-077-004 4.44 • Fast chip removal and reduced heat TiAlN
5/64 .0780 .472 1.496 01-075-005 3.11 01-077-005* 4.47 generation at the point. • For high speed and dry machining of cast
3/32 .0937 .551 1.693 01-075-006 3.09 01-077-006 4.47 • Increased hole depth, accuracy and iron, stainless steels, nickel based high
7/64 .1094 .630 1.811 01-075-007 3.44 01-077-007 4.82 number of holes per sharpening. temperature alloys & titanium alloys.
1/8 .1248 .709 1.929 01-075-008 4.04 01-077-008 6.13
9/64 .1406 .787 2.047 01-075-009 4.64 01-077-009 7.24 ♦ See Page 152 For Features & Tolerance Data.
5/32 .1563 .866 2.165 01-075-010 4.89 01-077-010 7.49
11/64 .1720 .945 2.283 01-075-011 5.20 01-077-011 7.80 Additional Sizes, For NoN-Ferrous

3/16 .1874 1.024 2.441 01-075-012 5.60 01-077-012 8.20 See Pages 152-153 Or Call For Plastic For steel
13/64 .2031 1.024 2.441 01-075-013 5.89 01-077-013 8.47 unCoaTeD Tialn CoaTeD
7/32 .2189 1.102 2.598 01-075-014* 6.62 01-077-014 9.29 DeCiMaL FLuTe overaLL orDer PriCe orDer PriCe
15/64 .2343 1.102 2.598 01-075-015* 6.93 01-077-015 9.60 Size DiaMeTer LengTh LengTh # eaCh # eaCh
1/4 .2500 1.220 2.756 01-075-016 7.38 01-077-016 12.56
17/64 .2657 1.339 2.913 01-075-017 7.73 01-077-017 12.93 nuMBer SizeS
9/32 .2811 1.339 2.913 01-075-018 8.89 01-077-018 14.09 #60 .0402" .236" 1.024" 01-075-160* $2.82 01-077-160 $4.51
19/64 .2969 1.457 3.110 — — 01-077-019 15.07 59 .0409 .276 1.024 01-075-159* 2.82 01-077-159* 4.47
5/16 .3126 1.457 3.110 01-075-020 9.93 01-077-020 15.13 58 .0421 .276 1.102 01-075-158* 2.49 01-077-158* 4.77
21/64 .3280 1.457 3.110 01-075-021 10.16 01-077-021 15.36 57 .0429 .276 1.102 01-075-157 3.04 01-077-157 4.82
11/32 .3437 1.575 3.307 01-075-022 11.98 01-077-022 17.18 56 .0465 .276 1.102 01-075-156* 3.28 01-077-156 4.69
23/64 .3594 1.575 3.307 01-075-023 12.40 01-077-023 17.60 55 .0520 .354 1.260 01-075-155 3.82 01-077-155 5.20
3/8 .3748 1.693 3.504 01-075-024 14.38 01-077-024 19.58 54 .0551 .354 1.260 01-075-154 3.22 01-077-154 4.51
25/64 .3906 1.693 3.504 01-075-025 13.98 01-077-025 19.18 53 .0594 .394 1.339 01-075-153 3.13 01-077-153 4.51
13/32 .4063 1.693 3.504 01-075-026 15.93 01-077-026 22.42 52 .0634 .394 1.339 01-075-152 3.13 01-077-152 4.53
27/64 .4220 1.850 3.740 01-075-027 16.64 01-077-027 23.16 51 .0669 .394 1.339 01-075-151 3.71 01-077-151 5.11
7/16 .4374 1.850 3.740 01-075-028 17.84 01-077-028 24.33 50 .0701 .433 1.417 01-075-150 3.16 01-077-150 4.56
29/64 .4531 1.850 3.740 01-075-029 17.82 01-077-029 24.31 49 .0728 .433 1.417 01-075-149 3.18 01-077-149 4.56
15/32 .4689 2.008 4.016 01-075-030* 19.27 — — 48 .0760 .472 1.496 01-075-148 3.18 01-077-148 4.04
31/64 .4843 2.008 4.016 01-075-031* 23.34 01-077-031* 31.90 47 .0783 .472 1.496 01-075-147 3.18 01-077-147 4.58
1/2 .5000 2.008 4.016 01-075-032 23.62 01-077-032 32.29 46 .0811 .472 1.496 01-075-146 3.09 01-077-146* 3.92
MeTriC SizeS 45 .0819 .472 1.496 01-075-145 3.09 01-077-145* 4.44
1.1mm .0433" .276" 1.102" 01-075-200 $3.04 01-077-200* $5.21 44 .0858 .512 1.575 01-075-144 3.18 01-077-144 4.56
01-077-143
01-075-143
.512
1.575
43
.0890
3.11
4.51
1.15 .0453 .276 1.102 01-075-201* 3.01 01-077-201* 5.24
1.2 .0472 .315 1.181 01-075-202* 3.28 01-077-202 5.27 42 .0933 .551 1.693 01-075-142 3.16 01-077-142 4.53
1.25 .0492 .315 1.181 01-075-203 3.29 01-077-203 5.29 41 .0961 .551 1.693 01-075-141 3.44 01-077-141 4.82
1.3 .0512 .315 1.181 01-075-204 3.82 01-077-204* 5.21 40 .0980 .551 1.693 01-075-140 3.44 01-077-140* 4.77
1.45 .0571 .354 1.260 01-075-205* 2.88 01-077-205* 3.51 39 .0996 .551 1.693 01-075-139* 3.85 01-077-139* 5.21
1.5 .0591 .354 1.260 01-075-206* 3.52 01-077-206 4.96 38 .1016 .551 1.693 01-075-138 3.89 01-077-138 5.27
1.55 .0610 .394 1.339 01-075-207 3.13 — — 37 .1039 .551 1.693 01-075-137 3.89 01-077-137* 5.24
1.6 .0630 .394 1.339 01-075-208* 3.04 01-077-208* 4.77 36 .1067 .630 1.811 01-075-136 3.56 01-077-136 4.96
2 .0787 .472 1.496 01-075-209 3.00 01-077-209 4.82 35 .1098 .630 1.811 01-075-135 3.49 01-077-135 4.87
2.05 .0807 .472 1.496 01-075-210 3.09 01-077-210* 4.84 34 .1110 .630 1.811 01-075-134 3.49 01-077-134 4.87
2.35 .0925 .512 1.575 01-075-211 3.11 01-077-211 5.02 33 .1130 .630 1.811 01-075-133 3.49 01-077-133 4.87
2.4 .0945 .551 1.693 01-075-212 3.09 01-077-212* 4.86 32 .1161 .630 1.811 01-075-132 3.98 01-077-132 5.38
2.5 .0984 .551 1.693 01-075-213 3.36 01-077-213* 4.86 31 .1201 .709 1.929 01-075-131 4.16 01-077-131 5.56
3 .1181 .630 1.811 01-075-214 3.87 01-077-214 5.24 30 .1283 .709 1.929 01-075-130 4.20 01-077-130 6.27
3.1 .1220 .709 1.929 01-075-215 4.04 01-077-215 5.62 29 .1358 .787 2.047 01-075-129 4.67 01-077-129 7.27
3.2 .1260 .709 1.929 — — 01-077-216 6.13 27 .1441 .787 2.047 01-075-127 4.82 01-077-127 7.42
3.25 .1280 .709 1.929 01-075-217 4.20 01-077-217* 4.00 26 .1469 .787 2.047 01-075-126 4.84 01-077-126 7.42
3.3 .1299 .709 1.929 01-075-218 4.07 01-077-218 6.16 25 .1496 .866 2.165 01-075-125 4.98 — —
3.4 .1339 .787 2.047 01-075-219 4.40 01-077-219* 6.93 24 .1520 .866 2.165 01-075-124 4.98 01-077-124 7.58
3.5 .1378 .787 2.047 01-075-220 4.56 01-077-220 7.16 23 .1539 .866 2.165 01-075-123 5.02 01-077-123* 7.55
3.9 .1535 .866 2.165 01-075-221* 4.82 — — 22 .1571 .866 2.165 01-075-122 5.02 01-077-122* 7.55
4 .1575 .866 2.165 01-075-222 4.89 01-077-222* 7.41 21 .1591 .866 2.165 01-075-121 5.16 01-077-121 7.76
4.1 .1614 .866 2.165 01-075-223* 4.99 01-077-223* 7.57 20 .1610 .866 2.165 01-075-120 5.16 — —
4.2 .1654 .866 2.165 01-075-224 5.04 01-077-224* 7.57 19 .1661 .866 2.165 01-075-119 5.18 01-077-119 7.76
5 .1969 1.024 2.441 01-075-225 5.60 01-077-225 8.20 18 .1693 .945 2.283 01-075-118 5.31 01-077-118 7.91
5.5 .2165 1.102 2.598 01-075-226 6.73 — — 17 .1728 .945 2.283 01-075-117 5.31 01-077-117 7.91
6 .2362 1.102 2.598 01-075-227 7.04 01-077-227 12.24 16 .1772 .945 2.283 01-075-116 5.33 — —
6.3 .2480 1.220 2.756 01-075-228 7.16 01-077-228* 12.23 15 .1799 .945 2.283 01-075-115 5.47 01-077-115* 7.99
6.4 .2520 1.220 2.756 01-075-229 7.16 01-077-229 12.36 14 .1819 .945 2.283 01-075-114 5.40 01-077-114* 7.90
6.5 .2559 1.220 2.756 01-075-230 7.29 01-077-230 12.49 13 .1850 .945 2.283 01-075-113 5.40 01-077-113* 7.90
6.7 .2638 1.220 2.756 — — 01-077-231* 12.76 12 .1910 1.024 2.441 01-075-112 5.71 — —
7 .2756 1.339 2.913 01-075-232 8.40 01-077-232 13.60 11 .1909 1.024 2.441 01-075-111 5.71 01-077-111 8.31
8 .3150 1.457 3.110 01-075-233 9.93 01-077-233 15.13 10 .1937 1.024 2.441 01-075-110 5.73 — —
8.1 .3189 1.457 3.110 01-075-234 10.16 01-077-234 15.36 9 .1961 1.024 2.441 01-075-109 5.73 01-077-109 8.33
8.5 .3346 1.457 3.110 01-075-235 11.09 01-077-235 16.29 8 .1992 1.024 2.441 01-075-108 6.22 01-077-108 8.80
9 .3543 1.575 3.307 01-075-236 12.02 01-077-236 17.22 7 .2012 1.024 2.441 01-075-107 6.13 01-077-107 8.73
10 .3937 1.693 3.504 01-075-237 13.98 — — 6 .2039 1.024 2.441 01-075-106 6.13 01-077-106* 8.65
10.5 .4134 1.693 3.504 — — 01-077-238* 22.20 5 .2055 1.024 2.441 01-075-105 6.09 01-077-105* 8.60
11 .4331 1.850 3.740 — — 01-077-239 23.29 4 .2091 1.102 2.598 01-075-104 6.91 01-077-104 9.51
12 .4724 2.008 4.016 01-075-240 19.47 01-077-240* 27.85 3 .2130 1.102 2.598 01-075-103 6.96 01-077-103 9.56
12.5 .4921 2.008 4.016 — — 01-077-241* 33.90 2 .2209 1.102 2.598 01-075-102* 6.89 01-077-102 9.56
13 .5118 2.008 4.016 01-075-242 26.51 — — 1 .2280 1.102 2.598 — — 01-077-101* 9.75
