DRILLS • Reduced Shank
168

High Speed Steel Silver & Deming Drills note: SpecificationS:
118° Point • 1/2" Reduced Shank • 6" Overall Length • Special care should be exercised Flute Length
when using these drills to avoid
ttc & preciSion Dormer
bending or shearing the reduced 33/64" thru 3/4" ......................3-1/8"
diameter drill shank. 49/64" thru 1-1/2" .........................3"
ttc proDuction uSa
All sizes .........................................3"
Additional Sizes Of Precision Dormer
Drills Available, Please Call
ttc a15 - milled round shank

FOR STEEL

ttc a15-g - ground
milleD GrounD 3 flat SHank GrounD
[A15] [A15-G] [R56]

Decimal orDer price orDer price orDer price orDer price
Size
Diameter # eacH # eacH # eacH # eacH
33/64" .5156" 01-080-033 $12.54 01-080-633 $16.73 01-080-533 $21.11 01-312-333 $28.57
17/32 .5312 01-080-034 12.54 01-080-634 16.27 01-080-534 21.11 01-312-334 27.87
35/64 .5469 01-080-035 13.93 01-080-635 17.80 01-080-535 22.36 01-312-335 30.43
9/16 .5625 01-080-036 13.81 01-080-636 17.30 01-080-536 22.41 01-312-336 29.58
ttc production usa - 3 flat shank 37/64 .5781 01-080-037 14.40 01-080-637 19.12 01-080-537 24.10 01-312-337 32.65
19/32 .5938 01-080-038 14.45 01-080-638 18.59 01-080-538 24.12 01-312-338 31.79
39/64 .6094 01-080-039 15.90 01-080-639 20.04 01-080-539 25.21 01-312-339 34.24
5/8 .6250 01-080-040 14.63 01-080-640 19.49 01-080-540 25.26 01-312-340 33.32
precision dormer - ground 41/64 .6406 01-080-041 16.02 01-080-641 21.37 01-080-541 26.95 01-312-341 36.56
21/32 .6562 01-080-042 16.08 01-080-642 20.80 01-080-542 26.99 01-312-342 35.52
43/64 .6719 01-080-043 17.30 01-080-643 22.21 01-080-543 27.98 01-312-343 38.03
11/16 .6875 01-080-044 17.24 01-080-644 21.59 01-080-544 28.00 01-312-344 36.92
45/64 .7031 01-080-045 17.54 01-080-645 22.51 01-080-545 28.31 01-312-345 38.53
23/32 .7188 01-080-046 17.88 01-080-646 21.89 01-080-546 28.51 01-312-346 37.41
47/64 .7344 01-080-047 17.99 01-080-647 24.50 01-080-547 29.92 01-312-347 41.86
3/4 .7500 01-080-048 18.58 01-080-648 23.82 01-080-548 30.25 01-312-348 40.77
49/64 .7656 01-080-049 19.45 01-080-649 26.15 01-080-549 31.77 01-312-349 44.74
25/32 .7812 01-080-050 19.04 01-080-650 25.44 01-080-550 32.24 01-312-350 43.46
51/64 .7969 01-080-051 20.67 01-080-651 33.76 01-080-551 34.62 01-312-351 52.37
13/16 .8125 01-080-052 20.67 01-080-652 26.74 01-080-552 34.83 01-312-352 45.72
53/64 .8281 01-080-053 21.24 01-080-653 34.93 01-080-553 35.94 01-312-353 54.27
27/32 .8438 01-080-054 21.24 01-080-654 27.65 01-080-554 36.13 01-312-354 47.31
55/64 .8594 01-080-055 22.17 01-080-655 32.95 01-080-555 36.77 01-312-355 56.32
7/8 .8750 01-080-056 22.06 01-080-656 28.71 01-080-556 37.01 01-312-356 49.07
57/64 .8906 01-080-057 23.92 01-080-657 34.41 01-080-557 43.33 01-312-357 58.84
29/32 .9062 01-080-058 23.16 01-080-658 29.98 01-080-558 39.20 01-312-358 51.20
59/64 .9219 01-080-059 26.35 01-080-659 36.80 01-080-559 46.43 01-312-359 62.87
15/16 .9375 01-080-060 25.08 01-080-660 32.04 01-080-560 42.25 01-312-360 54.74
61/64 .9531 01-080-061 27.51 01-080-661 38.87 01-080-561 49.07 01-312-361 66.53
31/32 .9688 01-080-062 26.30 01-080-662 37.27 01-080-562 43.55 01-312-362 57.94
APPLICATIONS: 63/64 .9844 01-080-063 29.08 01-080-663 43.31 01-080-563 57.46 01-312-363 73.86
01-080-064
1.0000
1
31.65 01-080-664
64.09
57.92 01-312-364
37.72 01-080-564
• Can be used in electric drills and drill presses with 1/2" 1-1/64 1.0156 01-080-065 33.76 — — — — — —
capacity drill chuck. 1-1/32 1.0312 01-080-066 33.76 — — 01-080-566 76.94 — —
• Primarily designed as tools for drilling larger holes with 1-3/64 1.0469 01-080-067 34.82 — — — — — —
reduced diameter straight shank drills. 1-1/16 1.0625 01-080-068 34.82 — — 01-080-568 74.26 01-312-368 76.91
• For most drilling operations in a wide array of materials 1-5/64 1.0781 01-080-069 36.93 — — — — — —
having low and medium tensile strength ratings. 1-3/32 1.0938 01-080-070 36.93 — — — — — —
• Intended for those applications where only a 1/2" chuck 1-7/64 1.1094 01-080-071 36.93 — — 01-080-571 83.73 — —
is available to drive the drills. 1-1/8 1.1250 01-080-072 36.93 — — 01-080-572 84.46 01-312-372 86.07
• May be used with a wide range of portable or stationary 1-9/64 1.1406 01-080-073 41.15 — — — — — —
machine tools and with hand held manual drills. 1-5/32 1.1562 01-080-074 40.10 — — 01-080-574 87.69 — —
• For optimal performance and the best tool life suitable, 1-11/64 1.1719 01-080-075 42.21 — — — — — —
lubricating/cutting oils or the appropriate coolant fluids 1-3/16 1.1875 01-080-076 42.21 — — — — 01-312-376 94.61
are recommended. 1-13/64 1.2031 01-080-077 44.32 — — — — — —
1-7/32 1.2188 01-080-078 44.32 — — 01-080-578 99.02 — —
FeATureS: 1-15/64 1.2344 01-080-079 46.43 — — — — — —
• Right hand (clockwise rotation) cutting direction. 1-1/4 1.2500 01-080-080 45.37 — — 01-080-580 102.37 01-312-380 104.37
• Standard two flute design. 1-17/64 1.2656 01-080-081 51.71 — — — — — —
• Standard spiral, helical flutes. 1-9/32 1.2812 01-080-082 51.71 — — — — — —
—
—
—
—
51.71
—
01-080-083
1-19/64 1.2969
—
• All drills have reduced shanks that are 1/2" in diameter. 1-5/16 1.3125 01-080-084 51.71 — — — — — —
Precision Dormer 1-21/64 1.3281 01-080-085 52.76 — — — — — —
• Black oxide flutes with bright body finish. 1-11/32 1.3438 01-080-086 52.76 — — — — — —
TTC Production USA 1-23/64 1.3594 01-080-087 55.93 — — — — — —
• Supplied with 3 flat shank. 1-3/8 1.3750 01-080-088 52.76 — — 01-080-588 125.93 — —
†Ships direct from factory. 1-25/64 1.3906 01-080-089 63.32 — — — — — —
1-13/32 1.4062 01-080-090 62.26 — — — — — —
TeChNICAL DATA: 1-27/64 1.4219 01-080-091 62.26 — — — — — —
• Manufactured from high speed steel. 1-7/16 1.4375 01-080-092 65.43 — — — — — —
• 118° point angle and standard web thickness. 1-29/64 1.4531 01-080-093 65.43 — — — — — —
TTC 1-15/32 1.4688 01-080-094 63.32 — — — — — —
• Surface treated. 1-31/64 1.4844 01-080-095 63.32 — — — — — —
• Black finish. 1-1/2 1.5000 01-080-096 62.16 — — — — 01-312-396 180.67
