DRILLS • Taper Length
172

High Speed Steel Taper Length (Long) Drills Designed for drilling holes 1/16" to 3/32" Sold In
deeper than possible with
118° Point • Straight Shank • Right Hand • Cylindrically Ground standard jobbers length drills Package Quantity Only.
QuanTiTy Per Package
Taper Length Drill Sets Size QuanTiTy
Page 130 TTc ProDucTion
1/16" thru 9/32" 12
19/64" thru 1/2" 6
APPLICATIONS: FeATureS: TeChNICAL DATA: Over 1/2" 1
• Normal duty, general purpose drills. • Taper length drills have TTC Production PreciSon Dormer
• For a variety of ferrous, non-ferrous approximately the same overall • Surface treated or bright finish. 1/16" thru 1/4" 12
metals, alloys and non-metallic materials. length as taper shank drills. Precision Dormer 17/64" thru 1/2" 6 1
33/64" and above
• For hand held drills and variety of • 1/16" thru 11/16": bright finish Prices Shown Are Per Drill

portable and stationary machine tools. • 45/64" thru 1-3/4": black finish

FOR STEEL FOR STEEL

fracTionaL SizeS [A23] [R51] fracTionaL SizeS [A23] [R51]
fLuTe overaLL orDer Price orDer Price fLuTe overaLL orDer Price orDer Price
Size Size
LengTH LengTH # eacH # eacH LengTH LengTH # eacH # eacH
1/16" 1-3/4" 3" 01-110-004 $2.03 01-313-204 $3.66 49/64" 6" 9-7/8" 01-110-049 $30.59 01-313-249 $69.89
5/64 2 3-3/4 01-110-005 2.37 01-313-205 4.32 25/32 6 9-7/8 01-110-050 30.08 01-313-250 66.57
3/32 2-1/4 4-1/4 01-110-006 2.76 01-313-206 5.05 51/64 6-1/8 10 01-110-051 32.79 — —
7/64 2-1/2 4-5/8 01-110-007 3.45 01-313-207 6.50 13/16 6-1/8 10 01-110-052 32.28 01-313-252 71.23
1/8 2-3/4 5-1/8 01-110-008 3.55 01-313-208 6.55 53/64 6-1/8 10 01-110-053 34.03 01-313-253 81.21
9/64 3 5-3/8 01-110-009 4.63 01-313-209 7.99 27/32 6-1/8 10 01-110-054 34.03 01-313-254 75.21
5/32 3 5-3/8 01-110-010 4.28 01-313-210 7.99 55/64 6-1/8 10 01-110-055 35.73 — —
11/64 3-3/8 5-3/4 01-110-011 4.97 01-313-211 8.10 7/8 6-1/8 10 01-110-056 35.73 01-313-256 79.22
3/16 3-3/8 5-3/4 01-110-012 4.28 01-313-212 7.99 57/64 6-1/8 10 01-110-057 37.19 — —
13/64 3-5/8 6 01-110-013 5.70 01-313-213 9.44 29/32 6-1/8 10 01-110-058 39.29 — —
7/32 3-5/8 6 01-110-014 6.04 01-313-214 9.26 59/64 6-1/8 10-3/4 01-110-059 40.80 — —
15/64 3-3/4 6-1/8 01-110-015 6.04 01-313-215 9.44 15/16 6-1/8 10-3/4 01-110-060 40.47 01-313-260 90.54
1/4 3-3/4 6-1/8 01-110-016 4.97 01-313-216 9.26 61/64 6-3/8 11 01-110-061 44.64 — —
17/64 3-7/8 6-1/4 01-110-017 6.32 01-313-217 11.49 31/32 6-3/8 11 01-110-062 44.64 01-313-262 99.18
9/32 3-7/8 6-1/4 01-110-018 6.04 01-313-218 11.43 63/64 6-3/8 11 01-110-063 46.96 01-313-263 111.83
19/64 4 6-3/8 01-110-019 6.94 01-313-219 11.65 1 6-1/2 11 01-110-064 46.62 01-313-264 103.84
5/16 4 6-3/8 01-110-020 6.20 01-313-220 11.49 1-1/64 6-1/2 11-1/8 01-110-065 55.71 — —
21/64 4-1/8 6-1/2 01-110-021 7.22 01-313-221 13.32 1-1/32 6-1/2 11-1/8 01-110-066 55.71 — —
11/32 4-1/8 6-1/2 01-110-022 6.99 01-313-222 13.20 1-3/64 6-5/8 11-1/4 01-110-067 57.68 — —
23/64 4-1/4 6-3/4 01-110-023 8.18 01-313-223 15.70 1-1/16 6-5/8 11-1/4 01-110-068 57.68 — —
3/8 4-1/4 6-3/4 01-110-024 8.18 01-313-224 15.53 1-5/64 6-7/8 11-1/2 01-110-069 61.80 — —
25/64 4-3/8 7 01-110-025 8.64 01-313-225 16.36 1-3/32 6-7/8 11-1/2 01-110-070 61.80 — —
13/32 4-3/8 7 01-110-026 8.58 01-313-226 16.20 1-7/64 7-1/8 11-3/4 01-110-071 62.48 — —
27/64 4-5/8 7-1/4 01-110-027 9.32 01-313-227 17.64 1-1/8 7-1/8 11-3/4 01-110-072 64.17 — —
7/16 4-5/8 7-1/4 01-110-028 9.54 01-313-228 17.81 1-9/64 7-1/4 11-7/8 01-110-073 69.53 — —
29/64 4-3/4 7-1/2 01-110-029 10.55 01-313-229 19.92 1-5/32 7-1/4 11-7/8 01-110-074 69.82 — —
15/32 4-3/4 7-1/2 01-110-030 11.12 01-313-230 20.97 1-11/64 7-3/8 12 01-110-075 74.58 — —
31/64 4-3/4 7-3/4 01-110-031 12.07 01-313-231 22.07 1-3/16 7-3/8 12 01-110-076 75.24 — —
1/2 4-3/4 7-3/4 01-110-032 11.63 01-313-232 21.91 1-13/64 7-1/2 12-1/8 01-110-077 78.18 — —
33/64 4-3/4 8 01-110-033 15.35 01-313-233 31.28 1-7/32 7-1/2 12-1/8 01-110-078 77.43 — —
17/32 4-3/4 8 01-110-034 14.96 01-313-234 31.01 1-15/64 7-7/8 12-1/2 01-110-079 79.61 — —
35/64 4-7/8 8-1/4 01-110-035 17.10 01-313-235 32.90 1-1/4 7-7/8 12-1/2 01-110-080 80.43 — —
9/16 4-7/8 8-1/4 01-110-036 15.69 01-313-236 32.62 1-9/32 8-1/2 14-1/8 01-110-082 90.70 — —
37/64 4-7/8 8-3/4 01-110-037 18.34 01-313-237 38.51 1-5/16 8-5/8 14-1/4 01-110-084 96.06 — —
19/32 4-7/8 8-3/4 01-110-038 18.34 01-313-238 38.51 1-11/32 8-3/4 14-3/8 01-110-086 100.78 — —
39/64 4-7/8 8-3/4 01-110-039 19.35 01-313-239 39.77 1-3/8 8-7/8 14-1/2 01-110-088 103.06 — —
5/8 4-7/8 8-3/4 01-110-040 18.46 01-313-240 39.44 1-13/32 9 14-5/8 01-110-090 108.59 — —
41/64 5-1/8 9 01-110-041 21.84 01-313-241 47.92 1-7/16 9-1/8 14-3/4 01-110-092 112.20 — —
21/32 5-1/8 9 01-110-042 21.00 01-313-242 45.76 1-15/32 9-1/4 14-7/8 01-110-094 121.86 — —
43/64 5-3/8 9-1/4 01-110-043 24.61 — — 1-1/2 9-3/8 15 01-110-096 125.81 — —
11/16 5-3/8 9-1/4 01-110-044 25.00 01-313-244 54.47 1-9/16 9-5/8 15-1/4 01-110-100 140.82 — —
45/64 5-5/8 9-1/2 01-110-045 26.31 — — 1-5/8 9-7/8 15-5/8 01-110-104 158.94 — —
23/32 5-5/8 9-1/2 01-110-046 25.96 01-313-246 56.58 1-11/16 10 15-3/4 01-110-108 175.25 — —
47/64 5-7/8 9-3/4 01-110-047 28.83 01-313-247 63.74 1-3/4 10-1/2 16-1/4 01-110-112 191.50 — —
3/4 5-7/8 9-3/4 01-110-048 27.94 01-313-248 59.69
Taper Length (Long) Drill Sets
118° Point • Straight Shank • Right Hand • High Speed Steel
APPLICATIONS: INCLuDeS:
• For long reach drilling applications. Model #A40
• High speed combines good tool life & • Metal index. Individual Sizes
productivity with minimal cost. Pages 172-175
Size # of moDeL orDer Price
range PieceS # # Per SeT
1/16" to 1/2" by 64ths 29 A40 01-110-901 $161.49
model #A40 33/64" to 3/4" by 64ths 16 A42 01-110-902 314.99
