DRILLS • Aircraft Extension
176

Cobalt 6" Long Aircraft Extension Drills
135° Split Point • Straight Shank • Right Hand Spiral • 30° Helix

Improved chip
removal
ToLErAnCEs:
APPLICATIONS: FeATureS: Cutting Diameter:
• For deep drilling applications. • 5% cobalt. Up to 1/8": 0 / - .0005"
• Excellent for carbon steels to HB225. • Package quantity: 12 pieces Over 1/8" up to 1/4": 0 / - .0007"
• Good results for alloy steels HB225-325, cast iron, aluminum, stainless steels, DECimAL FLuTE ovErALL orDEr ___PriCE EACh___
mild steels, copper & bronze. sizE DiAmETEr LEngTh LEngTh # 1-11 PCs. 12+ PCs.
numbEr
DECimAL FLuTE ovErALL orDEr ___PriCE EACh___
sizE #5 .2055" 2-1/2" 6" 01-115-705 $6.43 $5.79
DiAmETEr LEngTh LEngTh # 1-11 PCs. 12+ PCs. #7 .2010" 2-7/16" 6" 01-115-707 6.43 5.79
FrACTionAL #27 .1440" 1-7/8" 6" 01-115-727 4.85 4.37
3/32" .0938" 1-1/4" 6" 01-115-606 $3.65 $3.29 #29 .1360" 1-3/4" 6" 01-115-729 4.85 4.37
1/8" .1250" 1-5/8" 6" 01-115-608 3.88 3.49 #30 .1280" 1-5/8" 6" 01-115-730 3.85 3.47
5/32" .1563" 2" 6" 01-115-610 4.53 4.08 #31 .1200" 1-5/8" 6" 01-115-731 3.93 3.54
11/64" .1719" 2-1/8" 6" 01-115-611 5.03 4.53 #33 .1130" 1-1/2" 6" 01-115-733 3.93 3.54
3/16" .1875" 2-5/16" 6" 01-115-612 4.95 4.46 #35 .1100" 1-1/2" 6" 01-115-735 3.93 3.54
13/64" .2031" 2-7/16" 6" 01-115-613 6.23 5.61 #37 .1040" 1-7/16" 6" 01-115-737 3.93 3.54
15/64" .2344" 2-5/8" 6" 01-115-615 6.80 6.12 #40 .0980" 1-3/8" 6" 01-115-740 3.58 3.22
1/4" .2500" 2-3/4" 6" 01-115-616 7.70 6.93 #41 .0960" 1-3/8" 6" 01-115-741 3.73 3.36
high speed steel 6" Long Aircraft Extension Drills Access hard-to-reach
locations
118° Point • 135° Split Point • Straight Shank
Larger Sizes FOR STEEL

Page 186

135° sPLiT PoinT
bright finish FrACTionAL sizEs 118° PoinT [500-6]
FLuTE orDEr PriCE orDEr PriCE
sizE
LEngTh # EACh # EACh
black finish 1/16" 7/8" 01-114-002 $2.63 01-315-202 $4.87
QuAnTiTy PEr PACkAgE APPLICATIONS: 5/64 1 1-1/4 01-114-003 2.72 01-315-203 4.93
2.05
01-114-004
3.73
3/32
01-315-204
sizE QuAnTiTy • For general purpose deep drilling 7/64 1-1/2 01-114-005 2.29 01-315-205 4.08
TTC ProDuCTion in steels, cast iron, ferrous and 1/8 1-5/8 01-114-006 2.29 01-315-206 3.96
1/16" thru 9/32" & #1 thru #52 12 non-ferrous metals and alloys. 9/64 1-3/4 01-114-007 2.77 01-315-207 4.69
19/64" thru 1/2" 6 FeATureS: 5/32 2 01-114-008 2.77 01-315-208 4.75
PrECision DormEr [SeRieS 500-6] 11/64 2-1/8 01-114-009 2.95 01-315-209 5.20
1/16" thru 1/4" 12 • Right hand (clockwise rotation) 3/16 2-5/16 01-114-010 2.95 01-315-210 5.20
17/64" thru 1/2" 6 cutting direction. 13/64 2-7/16 01-114-011 3.68 01-315-211 6.33
PrECision DormEr [SeRieS 501-6] • Standard two flute design. 7/32 2-1/2 01-114-012 3.68 01-315-212 6.33
#1 thru #60 12 • Normal spiral - helical flutes. 15/64 2-5/8 01-114-013 3.92 01-315-213 7.02
Prices shown are per drill. 1/4 2-3/4 01-114-014 3.92 01-315-214 6.90
♦ See Page 177 For Technical Data.

FOR STEEL FOR STEEL FOR STEEL

numbEr 135° sPLiT PoinT numbEr 135° sPLiT PoinT numbEr 135° sPLiT PoinT
sizEs 118° PoinT [501-6] sizEs 118° PoinT [501-6] sizEs 118° PoinT [501-6]
FLuTE orDEr PriCE orDEr PriCE FLuTE orDEr PriCE orDEr PriCE FLuTE orDEr PriCE orDEr PriCE
sizE sizE sizE
LEngTh # EACh # EACh LEngTh # EACh # EACh LEngTh # EACh # EACh
#1 2-5/8" 01-114-101 $4.09 — — #21 2-1/8" 01-114-121 $2.90 01-315-321 $4.98 #41 1-3/8" 01-114-141 $2.05 01-315-341 $3.91
#2 2-5/8" 01-114-102 4.09 01-315-302 $7.46 #22 2" 01-114-122 2.95 01-315-322 5.20 #42 1-1/4" 01-114-142 2.05 01-315-342 3.91
#3 2-1/2" 01-114-103 3.74 01-315-303 6.73 #23 2" 01-114-123 2.95 01-315-323* 5.26 #43 1-1/4" 01-114-143 2.72 01-315-343 4.98
#4 2-1/2" 01-114-104 3.74 01-315-304 6.78 #24 2" 01-114-124 2.95 01-315-324 5.09 #44 1-1/8" 01-114-144 2.72 01-315-344 5.03
#5 2-1/2" 01-114-105 3.74 01-315-305* 6.85 #25 1-7/8" 01-114-125 2.95 01-315-325 5.09 #45 1-1/8" 01-114-145 2.72 01-315-345 5.03
#6 2-1/2" 01-114-106 3.74 01-315-306 6.73 #26 1-7/8" 01-114-126 2.95 01-315-326* 5.15 #46 1-1/8" 01-114-146 2.72 01-315-346 4.87
#7 2-7/16" 01-114-107 3.74 01-315-307 6.73 #27 1-7/8" 01-114-127 2.95 — — #47 1" 01-114-147 2.72 01-315-347 4.93
#8 2-7/16" 01-114-108 3.74 01-315-308* 6.73 #28 1-3/4" 01-114-128 2.95 01-315-328* 5.26 #48 1" 01-114-148 2.72 01-315-348 5.03
#9 2-7/16" 01-114-109 3.68 01-315-309 6.45 #29 1-3/4" 01-114-129 2.95 01-315-329 5.03 #49 1" 01-114-149 2.72 01-315-349 5.03
#10 2-7/16" 01-114-110 3.44 — — #30 1-5/8" 01-114-130 2.36 01-315-330 4.08 #50 1" 01-114-150 2.72 01-315-350 4.80
#11 2-5/16" 01-114-111 3.14 01-315-311 5.54 #31 1-5/8" 01-114-131 2.36 01-315-331 4.29 #51 1" 01-114-151 2.72 01-315-351 5.03
#12 2-5/16" 01-114-112 3.20 01-315-312 5.60 #32 1-5/8" 01-114-132 2.36 01-315-332 4.29 #52 7/8" 01-114-152 2.72 01-315-352 4.98
#13 2-5/16" 01-114-113 3.14 — — #33 1-1/2" 01-114-133 2.36 01-315-333 4.29 #53 7/8" 01-114-153 5.36 — —
#14 2-3/16" 01-114-114 3.14 — — #34 1-1/2" 01-114-134 2.36 01-315-334 4.29 #54 7/8" 01-114-154 5.36 — —
#15 2-3/16" 01-114-115 3.14 01-315-315 5.54 #35 1-1/2" 01-114-135 2.36 01-315-335 4.29 #55 7/8" 01-114-155 5.36 — —
#16 2-3/16" 01-114-116 3.14 01-315-316 5.49 #36 1-7/16" 01-114-136 2.36 01-315-336 4.18 #56 3/4" 01-114-156 5.36 — —
#17 2-3/16" 01-114-117 3.14 01-315-317 5.71 #37 1-7/16" 01-114-137 2.36 01-315-337* 4.32 #57 3/4" 01-114-157 6.38 — —
#18 2-1/8" 01-114-118 3.14 01-315-318* 5.67 #38 1-7/16" 01-114-138 2.36 01-315-338 4.29 #58 11/16" 01-114-158 6.38 — —
#19 2-1/8" 01-114-119 2.95 01-315-319 5.49 #39 1-3/8" 01-114-139 2.36 01-315-339 4.29 #59 11/16" 01-114-159 6.38 — —
#20 2-1/8" 01-114-120 2.95 01-315-320 4.98 #40 1-3/8" 01-114-140 2.05 01-315-340 3.67 #60 11/16" 01-114-160 6.38 — —
*Limited Supply.
