Long Length • DRILLS
179

High Speed Steel 1/2" Shank 12" Extra Long Drills

DECimaL OrDEr PriCE DECimaL OrDEr PriCE
SizE SizE
EquivaLEnt # EaCH EquivaLEnt # EaCH
33/64" .5156" 01-080-833 $55.92 23/32" .7188" 01-080-846 $83.81
17/32 .5312 01-080-834 55.92 47/64 .7344 01-080-847 82.76
35/64 .5469 01-080-835 55.92 3/4 .7500 01-080-848 78.82 unIque Long
9/16 .5625 01-080-836 55.82 49/64 .7656 01-080-849 88.77 Length DRILL
37/64 .5781 01-080-837 65.10 25/32 .7812 01-080-850 84.54 BeNeFITS: FeATureS: wIth 1/2" Shank
19/32 .5938 01-080-838 59.17 13/16 .8125 01-080-852 89.48 • 118° provides quick penetration. • Flute length: 9"
39/64 .6094 01-080-839 67.11 53/64 .8281 01-080-853 104.56
5/8 .6250 01-080-840 63.94 27/32 .8438 01-080-854 99.58 APPLICATIONS:
21/32 .6562 01-080-842 68.70 55/64 .8594 01-080-855 108.03
43/64 .6719 01-080-843 78.70 7/8 .8750 01-080-856 102.89 • Good wear resistance in mild steels,
11/16 .6875 01-080-844 71.54 15/16 .9375 01-080-860 117.90 soft metals (aluminum, copper, brass
45/64 .7031 01-080-845 83.81 1 1.0000 01-080-864 125.72 & bronze) & non-ferrous materials.
Extra Long High Speed Steel Drills
118° Point • Straight Shank • Right Hand • 12" Or 18" Lengths
FeATureS: TeChNICAL DATA:
• Right hand (clockwise rotation) • Manufactured from high speed steel.
cutting direction. • Cylindrically ground.
APPLICATIONS: • Standard two flute design, normal TTC Production
• Designed for general-purpose deep drilling operations for normal materials. spiral - helical flutes. • Bright or black finish depending upon
• Designed for drilling holes in hard to reach locations or inaccessible areas. • Straight shanks that correspond to our stock.
• For drilling steel, cast iron, and variety of other ferrous, non-ferrous metals and alloys. the drill diameter. Precision Dormer
• Used with hand held manual drills and either portable or stationary machines. • Sizes 1/2" and smaller: bright finish
• Sizes 33/64" and larger: black finish

12" LEngtH [A29] 12" LEngtH [1290] 12" LEngtH [A29] 12" LEngtH [1290] 18" LEngtH [A30] 18" LEngtH [1813]
FLutE OrDEr PriCE OrDEr PriCE FLutE OrDEr PriCE OrDEr PriCE FLutE OrDEr PriCE OrDEr PriCE
SizE SizE SizE
LEngtH # EaCH # EaCH LEngtH # EaCH # EaCH LEngtH # EaCH # EaCH
1/8" 9" 01-130-008 $13.31 01-319-108 $22.50 1/2" 9" 01-130-032 $28.46 01-319-132 $43.72 3/16" 12" 01-131-012 $29.86 — —
9/64" 9" 01-130-009 13.31 — — 33/64" 9" 01-130-033 33.05 — — 7/32" 12" 01-131-014 29.86 — —
5/32" 9" 01-130-010 13.31 — — 17/32" 9" 01-130-034 33.05 01-319-134 54.34 1/4" 13" 01-131-016 30.06 01-320-116 $52.32
11/64" 9" 01-130-011 13.31 — — 35/64" 9" 01-130-035 33.18 — — 9/32" 13" 01-131-018 31.33 — —
3/16" 9" 01-130-012 13.31 01-319-112 25.42 9/16" 9" 01-130-036 33.18 01-319-136 54.34 5/16" 13" 01-131-020 31.34 01-320-120 55.88
13/64" 9" 01-130-013 13.31 — — 37/64" 9" 01-130-037 34.77 — — 11/32" 13" 01-131-022 31.34 — —
7/32" 9" 01-130-014 13.31 — — 19/32" 9" 01-130-038 34.77 — — 3/8" 13" 01-131-024 31.34 01-320-124 59.16
15/64" 9" 01-130-015 13.31 — — 39/64" 9" 01-130-039 37.10 — — 13/32" 13" 01-131-026 34.22 — —
1/4" 9" 01-130-016 13.31 01-319-116 28.34 5/8" 9" 01-130-040 37.10 01-319-140 61.39 7/16" 13" 01-131-028 35.51 01-320-128 69.93
17/64" 9" 01-130-017 15.21 — — 21/32" 9" 01-130-042 39.37 01-319-142 68.66 15/32" 13" 01-131-030 42.25 — —
9/32" 9" 01-130-018 15.21 — — 11/16" 9" 01-130-044 42.56 01-319-144 72.53 1/2" 13" 01-131-032 46.00 01-320-132 83.52
19/64" 9" 01-130-019 15.21 — — 23/32" 9" 01-130-046 47.22 — — 17/32" 13" 01-131-034 56.11 — —
5/16" 9" 01-130-020 15.51 01-319-120 30.51 3/4" 9" 01-130-048 50.78 01-319-148 80.92 9/16" 13" 01-131-036 60.16 01-320-136 101.66
21/64" 9" 01-130-021 17.54 — — 49/64" 9" 01-130-049 48.57 — — 19/32" 13" 01-131-038 66.23 — —
11/32" 9" 01-130-022 17.54 01-319-122 31.89 25/32" 9" 01-130-050 48.57 — — 5/8" 13" 01-131-040 71.15 — —
23/64" 9" 01-130-023 18.22 — — 13/16" 9" 01-130-052 51.73 — — 11/16" 13" 01-131-044 82.24 — —
3/8" 9" 01-130-024 18.22 01-319-124 32.74 27/32" 9" 01-130-054 54.90 — — 3/4" 13" 01-131-048 94.39 01-320-148 152.12
25/64" 9" 01-130-025 19.68 — — 7/8" 9" 01-130-056 56.98 — — 13/16" 14" 01-131-052 87.99 — —
13/32" 9" 01-130-026 19.68 01-319-126 36.77 29/32" 9" 01-130-058 58.07 — — 27/32" 14" 01-131-054 93.49 — —
27/64" 9" 01-130-027 20.24 — — 15/16" 9" 01-130-060 61.20 — — 7/8" 14" 01-131-056 96.79 — —
7/16" 9" 01-130-028 20.24 01-319-128 38.99 31/32" 9" 01-130-062 64.41 — — 15/16" 14" 01-131-060 97.89 — —
29/64" 9" 01-130-029 22.88 — — 63/64" 9" 01-130-063 72.85 — — 31/32" 14" 01-131-062 101.19 — —
15/32" 9" 01-130-030 22.88 01-319-130 42.82 1" 9" 01-130-064 72.85 — — 1" 14" 01-131-064 106.69 — —
31/64" 9" 01-130-031 23.74 — — 1-3/16" 14" 01-131-076 137.49 — —
Hole Hog 4 Flute Premium High Speed Steel Core Drills
Type 284-UB • 3 Flats On Shank

Eliminates the catching and hogging-in when breaking
through thinner materials such as truck frames

minimum
FLutE
SizE HOLE DiamEtEr LEngtH OvEraLL OrDEr PriCE APPLICATIONS: FeATureS:
• Designed for enlarging existing holes exclusively.
• Gold surface treated body and
LEngtH
#
EaCH
3/8" 1/4" 1-7/8" 4-5/16" 01-129-324 $25.10 • May replace tapered reamers in many applications. clearance for maximum lubricity.
1/2" 5/16" 1-7/8" 4-5/16" 01-129-332 32.79 • Although (UB) Ultra bore drills will substantially outperform • Special Hi- Molybdenum tool steel.
9/16" 3/8" 1-7/8" 4-5/16" 01-129-336 42.72 cobalt drills in most stainless steel, it is recommended that • Often improves the hole results when
5/8" 25/64" 1-7/8" 4-5/16" 01-129-340 47.65 cobalt drills be used in the machining of free machining compared to Silver & Deming drills.
11/16" 7/16" 1-7/8" 4-5/16" 01-129-344 53.25 stainless steels such as 400 series & 303 materials along
3/4" 15/32" 1-7/8" 4-5/16" 01-129-348 58.03 with titanium alloys.
