DRILLS • Taper Shank
182

Taper Shank High Speed Steel Twist Drills NoTe:
118° Point • Right Hand • Flute and overall length may vary
depending on supplier.
• Advise sales department when
required use is multiple spindle
drilling & uniform overall length will
be supplied.

aPPlicatiOns: Features: technical Data:
• General purpose, normal duty drills designed for drilling holes in a variety or normal • Right hand (clockwise rotation) • Manufactured from high speed steel.
steels, cast iron, and other ferrous and non-ferrous metals and alloys. cutting direction. • Normal duty, general purpose drills.
• Have a normal 118° drill point angle suitable for a variety of drilling applications • Standard two flute design. • Black finish.
and conditions. • Normal spiral - helical flutes.
• Taper shanks to be used in a taper socket which are sized by the standard Morse • Standard 118° point angle.
taper sizes. • Standard morse taper shanks
• Used with either portable or stationary machines having a taper socket spindle. correspond to drill diameter.
• To achieve optimal performance and extended tool life, suitable lubricating/cutting • Flutes are proportional to length.
oils or coolant fluids are recommended for most drilling operations.

FOR STEEL FOR STEEL

[A25] [A26] [209] [S209] [L209] [A25] [A26] [209] [S209] [L209]
MorSe FluTe overall orDer price orDer price MorSe FluTe overall orDer price orDer price
Size Size
Taper leNgTH leNgTH # eacH # eacH Taper leNgTH leNgTH # eacH # eacH
1/8" 1 1-7/8" 5-1/8" 01-120-008 $7.46 — — 27/32" 2† 6-1/8" 10" 01-121-054 $39.97 — —
9/64 1 2-1/8 5-3/8 01-120-009 8.48 — — 27/32 3 6-1/8 10-3/4 01-120-054 30.80 01-317-354 $78.53
5/32 1 2-1/8 5-3/8 01-120-010 8.02 — — 55/64 2† 6-1/8 10 01-121-055 41.73 — —
11/64 1 2-1/2 5-3/4 01-120-011 9.58 — — 55/64 3 6-1/8 10-3/4 01-120-055 34.68 01-317-355 88.11
3/16 1 2-1/2 5-3/4 01-120-012 7.79 01-317-312 $14.01 7/8 2† 6-1/8 10 01-121-056 38.04 01-318-356 91.93
13/64 1 2-3/4 6 01-120-013 7.71 — — 7/8 3 6-1/8 10-3/4 01-120-056 29.65 01-317-356 82.35
7/32 1 2-3/4 6 01-120-014 7.71 01-317-314 15.20 57/64 2† 6-1/8 10 01-121-057 47.21 — —
15/64 1 2-7/8 6-1/8 01-120-015 10.05 01-317-315* 19.25 57/64 3 6-1/8 10-3/4 01-120-057 35.58 01-317-357 90.02
1/4 1 2-7/8 6-1/8 01-120-016 6.32 01-317-316 15.61 29/32 2† 6-1/8 10 01-121-058 43.02 — —
17/64 1 3 6-1/4 01-120-017 6.67 01-317-317 17.43 29/32 3 6-1/8 10-3/4 01-120-058 35.12 01-317-358 86.82
9/32 1 3 6-1/4 01-120-018 6.67 — — 59/64 3 6-1/8 10-3/4 01-120-059 35.60 01-317-359 90.66
19/64 1 3-1/8 6-3/8 01-120-019 9.30 01-317-319 21.58 15/16 3 6-1/8 10-3/4 01-120-060 31.30 01-317-360 82.35
5/16 1 3-1/8 6-3/8 01-120-020 6.83 01-317-320 16.76 61/64 3 6-3/8 11 01-120-061 33.61 — —
21/64 1 3-1/4 6-1/2 01-120-021 9.11 01-317-321 23.21 31/32 3 6-3/8 11 01-120-062 36.30 01-317-362 89.38
11/32 1 3-1/4 6-1/2 01-120-022 9.78 — — 63/64 3 6-3/8 11 01-120-063 37.40 01-317-363 98.96
23/64 1 3-1/2 6-3/4 01-120-023 11.84 — — 1 3 6-3/8 11 01-120-064 33.27 01-317-364 90.66
3/8 1 3-1/2 6-3/4 01-120-024 10.80 01-317-324 25.57 1-1/64 3 6-1/2 11-1/8 01-120-065 42.88 01-317-365 113.64
25/64 1 3-5/8 7 01-120-025 10.68 — — 1-1/32 3 6-1/2 11-1/8 01-120-066 44.57 01-317-366 98.96
13/32 1 3-5/8 7 01-120-026 10.76 01-317-326 25.83 1-3/64 3 6-5/8 11-1/4 01-120-067 47.84 01-317-367 118.75
27/64 1 3-7/8 7-1/4 01-120-027 11.12 01-317-327 29.59 1-1/16 3 6-5/8 11-1/4 01-120-068 45.58 01-317-368 104.70
7/16 1 3-7/8 7-1/4 01-120-028 11.70 01-317-328 28.57 1-5/64 3† 6-7/8 11-1/2 01-121-069 53.05 — —
29/64 1 4-1/8 7-1/2 01-120-029 14.13 — — 1-5/64 4 6-7/8 12-1/2 01-120-069 52.89 — —
15/32 1 4-1/8 7-1/2 01-120-030 13.43 01-317-330 32.81 1-3/32 3† 6-7/8 11-1/2 01-121-070 54.60 — —
31/64 1† 4-3/8 7-3/4 01-121-031 21.08 — — 1-3/32 4 6-7/8 12-1/2 01-120-070 53.20 01-317-370 122.57
31/64 2 4-3/8 8-1/4 01-120-031 15.27 — — 1-7/64 3† 7-1/8 11-3/4 01-121-071 55.68 — —
1/2 1† 4-3/8 7-3/4 01-121-032 16.67 — — 1-7/64 4 7-1/8 12-3/4 01-120-071 57.30 — —
1/2 2 4-3/8 8-1/4 01-120-032 13.99 01-317-332 32.56 1-1/8 3† 7-1/8 11-3/4 01-121-072 51.58 01-318-372 152.58
33/64 1† 4-5/8 8 01-121-033 19.27 01-318-333 46.86 1-1/8 4 7-1/8 12-3/4 01-120-072 56.72 01-317-372 128.96
33/64 2 4-5/8 8-1/2 01-120-033 15.94 01-317-333 39.08 1-9/64 3† 7-1/4 11-7/8 01-121-073 56.19 — —
17/32 1† 4-5/8 8 01-121-034 19.27 01-318-334 42.96 1-9/64 4 7-1/4 12-7/8 01-120-073 60.88 — —
17/32 2 4-5/8 8-1/2 01-120-034 15.63 01-317-334 36.39 1-5/32 3† 7-1/4 11-7/8 01-121-074 56.19 — —
35/64 1† 4-7/8 8-1/4 01-121-035 20.53 01-318-335 50.05 1-5/32 4 7-1/4 12-7/8 01-120-074 57.83 01-317-374 134.07
35/64 2 4-7/8 8-3/4 01-120-035 16.57 01-317-335 42.52 1-11/64 3† 7-3/8 12 01-121-075 56.79 — —
9/16 1† 4-7/8 8-1/4 01-121-036 20.96 01-318-336 46.99 1-11/64 4 7-3/8 13 01-120-075 61.51 — —
9/16 2 4-7/8 8-3/4 01-120-036 16.99 01-317-336 39.71 1-3/16 3† 7-3/8 12 01-121-076 56.76 01-318-376 169.82
37/64 2 4-7/8 8-3/4 01-120-037 17.66 01-317-337 45.07 1-3/16 4 7-3/8 13 01-120-076 60.88 01-317-376 139.18
19/32 2 4-7/8 8-3/4 01-120-038 17.29 01-317-338 42.71 1-13/64 3† 7-1/2 12-1/8 01-121-077 67.02 — —
39/64 2 4-7/8 8-3/4 01-120-039 17.22 01-317-339 47.18 1-13/64 4 7-1/2 13-1/8 01-120-077 72.35 — —
5/8 2 4-7/8 8-3/4 01-120-040 16.13 01-317-340 43.41 1-7/32 3† 7-1/2 12-1/8 01-121-078 60.27 — —
41/64 2 5-1/8 9 01-120-041 17.76 01-317-341 52.03 1-7/32 4 7-1/2 13-1/8 01-120-078 64.84 — —
21/32 2 5-1/8 9 01-120-042 17.89 01-317-342 48.39 1-15/64 3† 7-7/8 12-1/2 01-121-079 66.40 — —
43/64 2 5-3/8 9-1/4 01-120-043 19.56 01-317-343 55.87 1-15/64 4 7-7/8 13-1/2 01-120-079 71.82 — —
11/16 2 5-3/8 9-1/4 01-120-044 18.81 01-317-344 50.44 1-1/4 3† 7-7/8 12-1/2 01-121-080 66.09 01-318-380 200.47
45/64 2 5-5/8 9-1/2 01-120-045 20.65 01-317-345 58.10 1-1/4 4 7-7/8 13-1/2 01-120-080 68.47 01-317-380 157.69
23/32 2 5-5/8 9-1/2 01-120-046 20.91 01-317-346 54.01 1-17/64 4 8-1/2 14-1/8 01-120-081 79.30 — —
47/64 2 5-7/8 9-3/4 01-120-047 22.98 01-317-347 61.74 1-9/32 4 8-1/2 14-1/8 01-120-082 78.67 — —
3/4 2 5-7/8 9-3/4 01-120-048 21.91 01-317-348 58.73 1-19/64 4 8-5/8 14-1/4 01-120-083 84.45 — —
49/64 2 6 9-7/8 01-120-049 26.02 01-317-349 74.69 1-5/16 4 8-5/8 14-1/4 01-120-084 79.91 01-317-384 196.64
25/32 2 6 9-7/8 01-120-050 27.11 01-317-350 71.50 1-21/64 4 8-3/4 14-3/8 01-120-085 87.29 — —
51/64 2† 6-1/8 10 01-121-051 38.23 01-318-351 91.30 1-11/32 4 8-3/4 14-3/8 01-120-086 88.10 — —
51/64 3 6-1/8 10-3/4 01-120-051 28.46 01-317-351 82.35 1-23/64 4 8-7/8 14-1/2 01-120-087 86.10 — —
13/16 2† 6-1/8 10 01-121-052 37.43 01-318-352 84.92 1-3/8 4 8-7/8 14-1/2 01-120-088 88.74 01-317-388 210.68
13/16 3 6-1/8 10-3/4 01-120-052 29.47 01-317-352 72.78 1-25/64 4 9 14-5/8 01-120-089 91.67 01-317-389* 251.30
53/64 2† 6-1/8 10 01-121-053 39.97 — — 1-13/32 4 9 14-5/8 01-120-090 91.67 — —
53/64 3 6-1/8 10-3/4 01-120-053 32.66 01-317-353 85.55 1-27/64 4 9-1/8 14-3/4 01-120-091 100.32 — —
†[A26] - Smaller Shank, [A25] - Regular Shank CONTINUED ON NEXT PAGE.
*Limited Supply.
