Taper Shank • DRILLS
183
Taper Shank High Speed Steel Twist Drills (Cont.)
118° Point • Right Hand
♦ See Page 182 For Applications, Features And Technical Data.
FOR STEEL NoTe:
• Flute and overall length may vary
depending on supplier.
• Advise sales department when
[A25] [A26] [209] [S209] [L209] required use is multiple spindle
FLuTe
Size MorSe LeNgTH overaLL orDer priCe orDer priCe drilling & uniform overall length will
#
eaCH
LeNgTH
#
Taper
eaCH
be supplied.
1-7/16" 4 9-1/8" 14-3/4" 01-120-092 $92.62 — —
1-29/64 4 9-1/4 14-7/8 01-120-093 99.81 — — [A25] [A26]
1-15/32 4 9-1/4 14-7/8 01-120-094 98.76 01-317-394 $246.43 MorSe FLuTe overaLL orDer priCe
1-31/64 4 9-3/8 15 01-120-095 102.40 — — Size Taper LeNgTH LeNgTH # eaCH
1-1/2 4 9-3/8 15 01-120-096 99.53 01-317-396 243.24
1-33/64 4* 9-3/8 15 01-121-097 111.31 — — 1-29/32" 5 10-3/8" 17-3/8" 01-120-122 $185.31
1-17/32 4* 9-3/8 15 01-121-098 128.12 01-318-398 317.93 1-15/16 4* 10-5/8 16-5/8 01-121-124 173.40
1-17/32 5 9-3/8 16-3/8 01-120-098 121.03 01-317-398 282.83 1-15/16 5 10-3/8 17-3/8 01-120-124 185.51
1-35/64 4* 9-5/8 15-1/4 01-121-099 127.06 — — 1-31/32 4* 10-5/8 16-5/8 01-121-126 193.04
1-9/16 4* 9-5/8 15-1/4 01-121-100 127.14 01-318-400 340.92 1-31/32 5 10-3/8 17-3/8 01-120-126 189.58
1-9/16 5 9-5/8 16-5/8 01-120-100 126.56 — — 2 4* 10-5/8 16-5/8 01-121-128 207.13
1-37/64 4* 9-7/8 15-1/2 01-121-101 141.10 — — 2 5 10-3/8 17-3/8 01-120-128 199.79
1-19/32 4* 9-7/8 15-1/2 01-121-102 134.38 — — 2-1/32 5 10-3/8 17-3/8 01-120-130 207.85
1-19/32 5 9-7/8 16-7/8 01-120-102 143.73 — — 2-1/16 5 10-1/4 17-3/8 01-120-132 209.46
1-39/64 4* 10 15-5/8 01-121-103 143.60 — — 2-3/32 5 10-1/4 17-3/8 01-120-134 221.64
1-5/8 4* 10 15-5/8 01-121-104 138.34 01-318-404 371.57 2-1/8 5 10-1/4 17-3/8 01-120-136 221.64
1-5/8 5 10 17 01-120-104 139.93 — — 2-5/32 5 10-1/4 17-3/8 01-120-138 236.41
1-41/64 4* 10-1/8 15-3/4 01-121-105 158.49 — — 2-3/16 5 10-1/4 17-3/8 01-120-140 240.45
1-21/32 4* 10-1/8 15-3/4 01-121-106 150.18 — — 2-7/32 5 10-1/8 17-3/8 01-120-142 249.15
1-21/32 5 10-1/8 17-1/8 01-120-106 154.65 — — 2-1/4 5 10-1/8 17-3/8 01-120-144 255.42
1-43/64 4* 10-1/8 15-3/4 01-121-107 165.62 — — 2-5/16 5 10-1/8 17-3/8 01-120-148 267.99
1-11/16 4* 10-1/8 15-3/4 01-121-108 150.05 01-318-408 418.81 2-3/8 5 10-1/8 17-3/8 01-120-152 278.55
1-11/16 5 10-1/8 17-1/8 01-120-108 158.51 — — 2-7/16 5 11-1/4 18-3/4 01-120-156 351.78
1-45/64 4* 10-1/8 15-3/4 01-121-109 172.87 — — 2-1/2 5 11-1/4 18-3/4 01-120-160 342.73
1-23/32 4* 10-3/8 15-3/4 01-121-110 177.30 — — 2-9/16 5 11-7/8 19-1/2 01-120-164 367.14
1-23/32 5 10-1/8 17-1/8 01-120-110 166.38 — — 2-5/8 5 11-7/8 19-1/2 01-120-168 359.94
1-47/64 4* 10-3/8 16-1/4 01-121-111 162.41 — — 2-11/16 5 12-3/4 20-3/8 01-120-172 403.95
1-3/4 4* 10-3/8 16-1/4 01-121-112 152.95 01-318-412 404.77 2-3/4 5 12-3/4 20-3/8 01-120-176 440.72
1-3/4 5 10-1/8 17-1/8 01-120-112 154.59 — — 2-13/16 5 13-3/8 21-1/8 01-120-180 489.51
1-25/32 4* 10-1/8 16-1/4 01-121-114 163.35 — — 2-7/8 5 13-3/8 21-1/8 01-120-184 482.32
1-25/32 5 10-1/8 17-1/8 01-120-114 160.61 — — 2-15/16 5 14 21-3/4 01-120-188 508.37
1-13//16 4* 10-3/8 16-1/4 01-121-116 155.59 — — 3 5 14 21-3/4 01-120-192 534.74
1-13/16 5 10-1/8 17-1/8 01-120-116 164.82 — — 3-1/8 6 14-5/8 24-1/2 01-120-200 713.92
1-27/32 4* 10-3/8 16-1/4 01-121-118 183.75 — — 3-1/4 6 15-1/2 25-1/2 01-120-208 891.91
1-27/32 5 10-1/8 17-1/8 01-120-118 180.71 — — 3-3/8 6 15-1/2 25-1/2 01-120-216 928.10
1-7/8 4* 10-1/2 16-1/2 01-121-120 173.40 — — 3-1/2 6 16-1/4 26-1/2 01-120-224 1,170.77
1-7/8 5 10-3/8 17-3/8 01-120-120 172.43 — — 3-3/4 6 16-1/2 29 01-120-232 1,350.52
1-29/32 4* 10-1/2 16-1/2 01-121-122 175.00 — — 4 6 16-1/2 29 01-120-240 1,439.10
*[A26] - Smaller Shank, [A25] - Regular Shank. *[A26] - Smaller Shank, [A25] - Regular Shank.
High Speed Steel Stub Length Short Taper Shank Drills
118° Point • Right Hand
APPLICATIONS: FeATureS:
• For oversized hole drilling operations in screw machines or where a shorter overall drill length is needed. • Right hand (clockwise rotation) cutting direction.
• Used for drilling oversize holes (2.00" to 3.50") in a variety or normal steels, cast iron, and other ferrous • Standard two flute design.
and non-ferrous metals and alloys. • Normal spiral - helical flutes.
• Used in a #5 Morse taper socket. • Designed for drilling oversized holes.
• Used with either portable or stationary machines having a #5 Morse taper socket spindle.
• To achieve optimal performance and extended tool life, suitable lubricating/cutting oils or appropriate TeChNICAL DATA:
coolant fluids are recommended for most drilling operations. • Manufactured from high speed steel.
[A25 ST] [A25 ST] • Point angle ground to 118° included angle with
normal shaped point.
Size MorSe FLuTe overaLL orDer priCe Size MorSe FLuTe overaLL orDer priCe • Normal duty, general purpose drills.
eaCH
#
#
eaCH
Taper LeNgTH LeNgTH
Taper LeNgTH LeNgTH
2" 5 5" 12" 01-124-004 $167.58 2-5/8" 5 5" 12" 01-124-040 $299.23 • Black finish.
2-1/16 5 5 12 01-124-008 180.47 2-3/4 5 5 12 01-124-044 336.14
2-1/8 5 5 12 01-124-012 184.60 2-7/8 5 5 12 01-124-048 372.18
2-3/16 5 5 12 01-124-016 206.88 3 5 5 12 01-124-052 440.73
2-1/4 5 5 12 01-124-020 218.15 3-1/8 5 5 12 01-124-056 495.56 Shorter length provides increased
2-5/16 5 5 12 01-124-024 222.76 3-1/4 5 5 12 01-124-060 564.14 rigidity at reduced cost
2-3/8 5 5 12 01-124-028 237.57 3-3/8 5 5 12 01-124-064 581.29
2-7/16 5 5 12 01-124-032 232.26 3-1/2 5 5 12 01-124-068 677.30
2-1/2 5 5 12 01-124-036 286.45
