High Speed Steel Taper Shank Core Drills
Right Hand

APPLICATIONS: FeATureS: TeChNICAL DATA:
• For enlarging existing punched or drilled holes. • Right hand (clockwise rotation) • Cylindrically ground.
• Taper shank is to be used in a taper socket and are sized by the standard cutting direction. • General purpose core drills.
morse taper sizes. • Since chiploads are spread over a • Bright finish.
• Work well for enlarging holes in greater number of cutting edges,
normal steels, cast iron, and a variety of other ferrous and non-ferrous metals reduce regular drill speed 25% and
and alloys. double feed rate.
• Used with portable or stationary machines with a taper socket spindle. • Standard 3 or 4 flute design.
• For optimal performance and extended tool life, use of suitable lubricating/ • Normal spiral - helical flutes. NoTe:
cutting oils or appropriate coolant fluids. • Standard Morse taper shanks that • Drills do not have a cutting point and
correspond to the drill diameter. are not Intended to drill initial holes.
• Normal length drills have flutes • 3 or 4 flute drills will be shipped
proportional to length. depending on our stock.
[A27] [A27] [A27]
MorSe FluTe overall orDer priCe MorSe FluTe overall orDer priCe MorSe FluTe overall orDer priCe
Size Size Size
Taper leNgTH leNgTH # eaCH Taper leNgTH leNgTH # eaCH Taper leNgTH leNgTH # eaCH
1/2" 2 4-3/8" 8-1/4" 01-128-032 $29.98 1-1/8" 4 7-1/8" 12-3/4" 01-128-072 $111.12 1-3/4" 5 10-1/8" 17-1/8" 01-128-112 $353.94
17/32 2 4-5/8 8-1/2 01-128-034 31.99 1-5/32 4 7-1/4 12-7/8 01-128-074 124.12 1-25/32 5 10-1/8 17-1/8 01-128-114 339.68
9/16 2 4-7/8 8-3/4 01-128-036 34.78 1-3/16 4 7-3/8 13 01-128-076 124.11 1-13/16 5 10-1/8 17-1/8 01-128-116 349.32
19/32 2 4-7/8 8-3/4 01-128-038 36.29 1-7/32 4 7-1/2 13-1/8 01-128-078 131.81 1-27/32 5 10-1/8 17-1/8 01-128-118 358.49
5/8 2 4-7/8 8-3/4 01-128-040 38.05 1-1/4 4 7-7/8 13-1/2 01-128-080 143.04 1-7/8 5 10-3/8 17-3/8 01-128-120 514.11
21/32 2 5-1/8 9 01-128-042 40.60 1-9/32 4 8-1/2 14-1/8 01-128-082 167.31 1-29/32 5 10-3/8 17-3/8 01-128-122 537.84
11/16 2 5-3/8 9-1/4 01-128-044 44.12 1-5/16 4 8-5/8 14-1/4 01-128-084 173.69 1-15/16 5 10-3/8 17-3/8 01-128-124 538.27
23/32 2 5-5/8 9-1/2 01-128-046 46.80 1-11/32 4 8-3/4 14-3/8 01-128-086 180.18 1-31/32 5 10-3/8 17-3/8 01-128-126 549.36
3/4 2 5-7/8 9-3/4 01-128-048 49.95 1-3/8 4 8-7/8 14-1/2 01-128-088 184.97 2 5 10-3/8 17-3/8 01-128-128 568.25
25/32 2 6 9-7/8 01-128-050 54.38 1-13/32 4 9 14-5/8 01-128-090 193.11 2-1/8 5 10-1/4 17-3/8 01-128-136 621.95
13/16 3 6-1/8 10-3/4 01-128-052 61.85 1-7/16 4 9-1/8 14-3/4 01-128-092 202.83 2-1/4 5 10-1/8 17-3/8 01-128-144 705.04
27/32 3 6-1/8 10-3/4 01-128-054 62.58 1-15/32 4 9-1/4 14-7/8 01-128-094 300.02 2-3/8 5 10-1/8 17-3/8 01-128-152 792.42
7/8 3 6-1/8 10-3/4 01-128-056 66.58 1-1/2 4 9-3/8 15 01-128-096 302.55 2-1/2 5 11-1/4 18-3/4 01-128-160 732.75
29/32 3 6-1/8 10-3/4 01-128-058 69.37 1-17/32 5 9-3/8 16-3/8 01-128-098 348.11 2-5/8 5 11-7/8 19-1/2 01-128-168 1,121.05
15/16 3 6-1/8 10-3/4 01-128-060 72.59 1-9/16 5 9-5/8 16-5/8 01-128-100 371.58 2-3/4 5 12-3/4 20-3/8 01-128-176 1,272.51
31/32 3 6-3/8 11 01-128-062 79.14 1-19/32 5 9-7/8 16-7/8 01-128-102 275.59 2-7/8 5 13-3/8 21-1/8 01-128-184 1,053.13
1 3 6-3/8 11 01-128-064 83.70 1-5/8 5 10 17 01-128-104 324.76 3 5 14 21-3/4 01-128-192 1,671.82
1-1/32 3 6-1/2 11-1/8 01-128-066 94.36 1-21/32 5 10-1/8 17-1/8 01-128-106 295.55
1-1/16 3 6-5/8 11-1/4 01-128-068 94.37 1-11/16 5 10-1/8 17-1/8 01-128-108 339.35
1-3/32 4 6-7/8 12-1/2 01-128-070 105.54 1-23/32 5 10-1/8 17-1/8 01-128-110 341.10
High Speed Steel Straight Shank Core Drills
Right Hand

APPLICATIONS: FeATureS: TeChNICAL DATA:
• For enlarging existing punched or drilled holes. • Right hand (clockwise rotation) • Cylindrically ground.
• Straight shank is to be used in a chuck or collet and sized proportionally to the cutting direction. • Normal duty, general purpose core drills.
drill diameter. • Standard 3 or 4 flute design. • Bright finish.
• Used with either portable or stationary machines. • Normal spiral - helical flutes.
• For enlarging holes in normal steels, cast iron, and a variety of other ferrous and • Straight shanks that correspond NoTe:
non-ferrous metals and alloys. to the drill diameter. • Drills do not have a cutting point and
• For optimal performance and extended tool life, use of suitable lubricating/ • Normal length drills have flutes are not Intended to drill initial holes.
cutting oils or appropriate coolant fluids is recommended. proportional to length. • 3 or 4 flute drills will be shipped
depending on our stock.
[A27S] [A27S] [A27S]
FluTe
FluTe
FluTe
Size leNgTH overall orDer priCe Size leNgTH overall orDer priCe Size leNgTH overall orDer priCe
eaCH
leNgTH
eaCH
#
#
eaCH
#
leNgTH
leNgTH
1/4" 3-3/4" 6-1/8" 01-129-016 $44.43 17/32" 4-3/4" 8" 01-129-034 $31.99 13/16" 6-1/8" 10" 01-129-052 $62.57
9/32 3-7/8 6-1/4 01-129-018 20.03 9/16 4-7/8 8-1/4 01-129-036 34.78 27/32 6-1/8 10 01-129-054 62.58
5/16 4 6-3/8 01-129-020 21.24 19/32 4-7/8 8-3/4 01-129-038 36.29 7/8 6-1/8 10 01-129-056 66.58
11/32 4-1/8 6-1/2 01-129-022 26.46 5/8 4-7/8 8-3/4 01-129-040 38.05 29/32 6-1/8 10 01-129-058 69.37
3/8 4-1/4 6-3/4 01-129-024 26.46 21/32 5-1/8 9 01-129-042 40.60 15/16 6-1/8 10-3/4 01-129-060 72.59
13/32 4-3/8 7 01-129-026 25.25 11/16 5-3/8 9-1/4 01-129-044 44.12 31/32 6-3/8 11 01-129-062 83.69
7/16 4-5/8 7-1/4 01-129-028 26.52 23/32 5-5/8 9-1/2 01-129-046 46.80 1 6-3/8 11 01-129-064 83.70
15/32 4-3/4 7-1/2 01-129-030 28.10 3/4 5-7/8 9-3/4 01-129-048 49.95
1/2 4-3/4 7-3/4 01-129-032 29.98 25/32 6 9-7/8 01-129-050 54.38
